TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Automatic Tensioner (Accord 3.0L) |
| Mounting Bolt | (1) |
| Pulley Bolt (2) | 28 (38) |
| Mounting Bolt/Nut |
| Lower |
| Accord |
| 2.3L | 16 (22) |
| 3.0L | 33 (45) |
| CR-V | 33 (45) |
| Odyssey, Oasis & Prelude | 16 (22) |
| Upper |
| Accord |
| 2.3L | 33 (45) |
| 3.0L | 16 (22) |
| CR-V | 17 (23) |
| Odyssey, Oasis & Prelude | 33 (45) |
| Pulley Lock Nut | 82 (111) |
| (1) 106 INCH lbs. (12 N.m). (2) Pulley bolt is a left-hand thread bolt. |
| (1) | 106 INCH lbs. (12 N.m). |
| (2) | Pulley bolt is a left-hand thread bolt. |
Charging System Wiring Diagram (Accord 2.3L). Scheme 1
Scheme 1: Charging System Wiring Diagram (Accord 2.3L)
Charging System Wiring Diagram (Accord 3.0L). Scheme 2
Scheme 2: Charging System Wiring Diagram (Accord 3.0L)
Charging System Wiring Diagram (CR-V). Scheme 3
Scheme 3: Charging System Wiring Diagram (CR-V)
Charging System Wiring Diagram (Odyssey & Oasis). Scheme 4
Scheme 4: Charging System Wiring Diagram (Odyssey & Oasis)
Charging System Wiring Diagram (Prelude). Scheme 5
Scheme 5: Charging System Wiring Diagram (Prelude)
