FUSE PANEL LOCATION

Note. Replacing a fuse with one of a greater rating greatly increases chances of damaging electrical system. If replacement fuse with proper rating for circuit is not available, install one with a lesser rating.

Fuse box is located under dashboard on driver's side. Underhood relay panel is located on right side of engine compartment next to battery. A list of protected circuits and fuse ratings for each is found on a chart inside fuse box and on fuse panel cover.

DASH FUSE PANEL IDENTIFICATION (1988-91)

Note. Replacing a fuse with one of a greater rating greatly increases chances of damaging electrical system. If replacement fuse with proper rating for circuit is not available, install one with a lesser rating.

Scheme 1

1. 1 - 7.5 Amp Warning Display, Starter (Manual Transmission), Neutral Safety Switch (Automatic Transmission), PGM-FI ECU, PGM-FI Main Relay, Control Box (PGM-CARB)
2. 2 - 10 Amp Stereo Radio Cassette Player, Cigarette Lighter Relay
3. 3 - 7.5 Amp Warning Display, Starter Solenoid, PGM-FI Electronic Control Unit, PGM-FI Main Relay
4. 4 - 15 Amp (4WS) Power Door Lock Control Unit
5. 5 - 15 Amp (Si Model) Passenger's Power Window Switch
6. 6 - 15 Amp (Si Model) Power Window Control Unit, Driver's Power Window Switch
7. 7 - 20 Amp Automatic Seat Belt Retractors
8. 8 - 15 Amp Trunk Light, Dome & Ashtray Lights, Ignition Key Switch, Integrated Control Unit, Cigarette Lighter, Driver's Door Outer Handle Switch
9. 9 - 15 Amp (Si Model Only) Foglight Relay
10. 10 - 7.5 Amp (Si Model Only) Cruise Control Main Switch
11. 11 - 20 Amp Sun Roof Relay, Power Windows, Windshield Wipers, Integrated Control Unit, Combination Switch
12. 12 - 10 Amp Warning Display, Speed Sensor Amplifier, Automatic Transmission, Engine Controls
13. 13 - 10 Amp Integrated Control Unit, Back-Up Light Switch, Combination & Shift Position Console Switches, Seat Belt Beeper/Reminder Assembly, Gauge Assembly, Shift Lever Position & Safety Indicators, Clock
14. 14 - 30 Amp Sun Roof Motors
15. 15 - 15 Amp Combination Switch
16. 16 - 7.5 Amp Daytime Running Lights Relay
17. 17 - 15 Amp Power Mirrors, Condenser Fan Relay (PGM-CARB), Radiator Fan Relay, Cooling Fan Timer Unit (PGM-FI)
18. 18 - 10 Amp Rear Window Defogger, Heater Controls, A/C Controls

UNDERHOOD FUSE & RELAY PANELS IDENTIFICATION (1988-91)

Note. Replacing a fuse with one of a greater rating greatly increases chances of damaging electrical system. If replacement fuse with proper rating for circuit is not available, install one with a lesser rating.

Scheme 2

1. 19 - 70 Amp Power Distributor
2. 20 - 40 Amp Power Distributor (Ignition Switch)
3. 21 - 40 Amp Power Distributor (Ignition Switch)
4. 22 - 40 Amp Dash Fuse Box
5. 23 - 30 Amp Rear Window Defogger Relay
6. 24 - 40 Amp Power Window Relay, Dash Fuse Box
7. 25 - 40 Amp ALB Motor Relay
8. 26 - 15 Amp Antilock Brake Control Unit
9. 27 - 15 Amp Antilock Brake Control Unit
10. 28 - 15 Amp Antilock Brake Control Unit
11. 29 - 15 Amp Right Headlight Retractor Relay, Headlight Retractor Switch
12. 30 - 15 Amp Left Headlight Retractor Relay, Headlight Retractor & Combination Switches
13. 31 - 15 Amp Turn Signals/Hazard Relay, Hazard Switch
14. 32 - 20 Amp Horns, Brakelight Switch, Key Interlock Switch
15. 33 - 15 Amp Right Headlight
16. 34 - 15 Amp Left Headlight
17. 35 - 10 Amp PGM-FI Electronic Control Unit, Power Antenna, Cooling Fan Timer Unit, Radio Cassette Player, Automatic Transmission Control Unit, Stereo, Clock
18. 36 - 15 Amp Condenser Fan Relay
19. 37 - 10 Amp Alternator
20. 38 - 10 Amp PGM-CARB Control Unit, PGM-FI Main Relay
21. 39 - 20 Amp Radiator Fan Relay

RADIATOR FAN & CAP

REPLACING BLOWN FUSE

Before replacing a blown fuse, remove ignition key and turn off all lights and accessories to avoid damaging electrical system. Be sure to use fuse with correct amperage rating. Use of an incorrect fuse may result in a dangerous electrical system overload.
