DESCRIPTION
The basic liquid cooling system consists of a radiator, water pump, thermostat, cooling fan, pressure cap, heater (if equipped), and various connecting hoses and cooling passages in the block and cylinder head. Vehicles use an electric fan with thermostatic control.
Some models may use a thermostatic vacuum switch to advance ignition timing in the event of overheating. All models use a coolant recovery system to prevent loss of anti-freeze.
DRAINING
Remove radiator cap and open heater control valve to maximum heat position. Open drain cocks or remove plugs in bottom of radiator and in engine block. In-line engines usually have one plug or cock, while "V" type engines will have two, one in each bank of cylinders.
CLEANING
A good cleaning compound removes most rust and scale. Follow manufacturer's instructions in the use of cleaner. If considerable rust and scale has to be removed, flushing should be used. Clean radiator air passages by blowing with compressed air from back to front of radiator.
FLUSHING
| CAUTION | Some manufacturers use an aluminum and plastic radiator on some models (identified by a note below the filler neck). Material used for cleaning and flushing must be compatible with aluminum, according to manufacturer's recommendations. |
- Back flushing is a very effective means of removing rust and scale from a cooling system. For best results, the radiator, engine and heater core should be flushed separately.
- To flush radiator, connect flushing gun to water outlet of radiator and disconnect water inlet hose. Use a leadaway hose, connected to radiator inlet, to prevent flooding engine. Use air in short bursts only, as this will prevent damage to radiator. Continue flushing until water runs clear.
- To flush engine, first remove thermostat and replace housing. Connect flushing gun to water outlet of engine. Disconnect heater hoses from engine. Flush using short air bursts until water runs clean. Flush heater core as described for radiator. Make sure heater valve is set to maximum heat position before flushing heater.
REFILLING
Engine should be running while refilling cooling system to prevent air from being trapped in the engine block. Use bleeder bolts, if equipped, to release air from system. After system is full, continue running engine until thermostat is open, then recheck fill level. Do not overfill system.
Scheme 1
- Visually inspect thermostat for corrosion and proper sealing of valve and seat. If satisfactory, suspend thermostat and a thermometer in a container with a 50/50 mixture of anti-freeze and water. (Scheme 1)
- Do not allow either thermostat or thermometer to touch bottom of container, as this concentration of heat could cause an incorrect reading. Heat water until thermostat just begins to open. (Scheme 1): Testing Thermostat in Anti-Freeze/Water Solution
- Read temperature on thermometer. This is the initial opening temperature and should be within specifications. Continue heating water until thermostat is fully open and note temperature. This is the fully opened temperature. If either reading is outside of specifications, replace thermostat.
PRESSURE TESTING
A pressure testing tool is used to test both radiator cap and complete cooling system. Test as follows, following tool manufacturer's instructions.
Radiator Cap
Visually inspect radiator cap, then dip cap in water and connect to tester. Pump tester to bring pressure to upper limit of cap specifications. If cap fails to hold pressure within specifications, replace cap.
Testing Radiator Pressure Cap. Scheme 2
- With engine off, wipe radiator filler neck seat clean. Fill radiator to correct level. Attach tester to radiator and pump until pressure is at upper limit of radiator rating.
- If pressure drops, inspect for external leaks. If no leaks are apparent, detach tester and run engine until normal operating temperature is obtained. Reattach tester and observe. If pressure builds up immediately, a possible leak exists from a faulty head gasket or crack in head or block. CAUTION: Pressure may build up quickly. Release any excess pressure or cooling system damage may result.
- If there is no immediate pressure build up, pump tester to within system pressure range (on radiator cap). Vibration of gauge pointer indicates compression or combustion leak into cooling system. Isolate leak by shorting each spark plug wire to cylinder block. Gauge pointer should stop or decrease vibration when leaking cylinder is shorted. CAUTION: Do not disconnect spark plug wires while engine is operating, or operate engine with spark plug shorted for more than 1 minute, as catalytic converter may be damaged.
- Remove engine and transmission (automatic only) oil dipsticks and check if water drops appear in oil. If so, a serious internal leak is indicated. If all checks are negative and system holds pressure for 2 minutes, there are no serious leaks in system.
Pressure Testing Cooling System. Scheme 3
ANTI-FREEZE CONCENTRATION
Note. On models using aluminum engines or cooling system components, refer to Owners Manual for anti-freeze requirements and recommendations. Aluminum components require a different formulation of anti-freeze to prevent corrosion.
On all cooling systems, test anti-freeze concentration using anti-freeze tester. Tester should have a temperature-compensating feature, as failing to take temperature into consideration could cause an error as large as 30°F (16°C). Follow tester manufacturer's instructions for correct use of tester.
A coolant recovery system differs from other cooling systems in that an overflow bottle is connected to the radiator overflow hose. Overflow bottle is transparent or translucent to permit checking of coolant level without removing radiator cap. No adjustment or test is required except keeping vent hole or hose clean and checking pressure relief of radiator cap.
Operation
As coolant temperature rises and pressure in system exceeds pressure relief valve of radiator cap, excess coolant flows into overflow bottle. As engine cools and coolant contracts, vacuum is formed in the system. Vacuum draws coolant, stored in overflow bottle, back into radiator. In a properly maintained cooling system, the only coolant losses will be through evaporation.
Overflow bottle captures and releases coolant according to temperature. (Scheme 4)
Typical Coolant Recover System. Scheme 4
Electrically-driven fans are actuated by thermal relay switches. Thermal switches turn fan motor on when necessary and shut fan motor off when not needed. Air conditioned vehicles are equipped with over-ride switches. These switches turn fan motor on whenever air conditioning system is operating. When system is turned off, fan motor control is returned to thermal relay.
Typical Thermostatically Controlled Electric Fan. Scheme 5
Fan Motor Test
Disconnect fan motor wire connector and connect it with 14 gauge wire to a good 12-volt battery. If fan runs, motor is okay. This indicates car battery, thermal switch, radiator fan switch, coolant relay, timer relay, coolant temperature switch, or A/C relay may be defective. If fan motor does not run when connected directly to a good battery, replace fan motor.
Temperature Switch Test (Accord)
On all models, the radiator fan timer/temperature switch is located at the top of the motor, near upper radiator hose. Switch should have continuity when coolant temprature is 226°F (108°C) or more.
On A/C equipped models, the radiator fan temperature switch is located in the lower radiator tank. Switch should have continuity when coolant temprature is 194°F (90°C) or more.
Fan Controller/Timer & Relays (Accord)
A solid-state fan controller/timer, located under right front seat, uses input from radiator fan timer/temperature switch to operate radiator fan relay. The fan controller/timer also uses input from radiator fan temperature switch to operate A/C condenser fan relay. Both relays are located in underhood fuse box. No testing is available from manufacturer. Do not check resistance of fan controller/timer.
COOLING SYSTEM SPECIFICATIONS
Note. For specifications, see COOLING SYSTEM SPECIFICATIONS article.
