Fuses & Flasher Location. Scheme 1
Scheme 1: Fuses & Flasher Location
| Manufacturer & Models | (1) Component Location |
|---|
| Accord |
| Fuse Locations | (2), (9) |
| Flasher Locations | N/A |
| Relay Locations |
| A/C, Compressor Clutch, Brake Check, Cooling Fan | (9) |
| Wiper/Washer, Lighting, Fuel Pump Cut-off, Turn Signal | (2) |
| Civic |
| Fuse Locations | (2) |
| Flasher Locations | N/A |
| Relay Locations |
| A/C, Condenser, A/C Clutch, A/C Diode Cooling Fan | (9) |
| Break Check/Warning Light, Fuel Injection | (1), (2) |
| Intermittent Wiper/Washer,Sunroof | (1), (2) |
| Rear Defogger, Turn Signal/Hazard | (1), (2) |
| Seat Belt Timer | (2) |
| Prelude |
| Fuse Locations | (2), (9) |
| Flasher Locations | N/A |
| Relay Locations |
| Headlight Door (2 Relays); 9 Cooling Fan | (9) |
| Interior Light, Seat Belt | (2) |
| Intermittent Wiper/Washer | (3) |
| Lighting, Sunroof (2 Relays), Headlight Dimmer | (9) |
| Rear Window Defogger, Fuel Cut-Off | (2) |
| Turn Signal/Hazard Side Marker Lights | (2) |
| (1) For component views (Scheme 1) |
