RELAYS & TIMERS
| Component | Location |
|---|---|
| A/C Compressor Clutch Relay | In left front corner of engine compartment. |
| A/C-Heater Blower Motor Relay | Below right side of dash. |
| Condenser Fan Relay | In left front corner of engine compartment. |
| Fuel Cut-Off Relay | In fuse and relay block under left side of dash. (Scheme 1) |
| Headlight Retract Relays (2) | In left front corner of engine compartment. (Scheme 1) |
| Interior Light Timer | Behind left side of dash. (Scheme 1) |
| Intermittent Wiper Relay | Behind instrument cluster. (Scheme 1) |
| Oil Pressure Alarm Unit | Below left side of dash. (Scheme 1) |
| Rear Window Defogger Relay | In fuse and relay block under left side of dash. (Scheme 1) |
| Seat Belt/Key Timer | Near fuse and relay block under left side of dash. (Scheme 1) |
| Side Marker Relay | Under left side of dash. (Scheme 1) |
| Turn Signal/Hazard Flasher | In fuse and relay block. (Scheme 1) |
RELAYS & TIMERS LOCATION
CONTROL UNITS
| Component | Location |
|---|---|
| Emission Control Unit | Behind right kick panel. |
| Headlight Retract Control Unit | On left kick panel. (Scheme 1) |
| Solenoid Control Valve Unit | Near the back seat. (Scheme 1) |
CONTROL UNITS LOCATION
SENDING UNITS/SENSORS
| Component | Location |
|---|---|
| Brake Fluid Level Sensor | In brake master cylinder. |
| Coolant Temperature Sending Unit | On front of intake manifold. (Scheme 3) |
| Coolant Thermosensor | On side of block above oil filter. (Scheme 4) |
| Cooling Fan Thermosensor | On bottom right corner of radiator. (Scheme 3) |
| Fuel Gauge Sending Unit | In top rear of fuel tank. (Scheme 2) |
| Intake Air Temperature Sensor | In air cleaner housing. (Scheme 5) |
| Oil Pressure Sending Unit | On top of oil filter adapter. (Scheme 4) |
| Speed Sensor | In speedometer gear housing. |
SENDING UNITS/SENSORS LOCATION
MOTORS
| Component | Location |
|---|---|
| A/C-Heater Blower Motor | Under right side of dash. |
| Condenser Fan Motor | On back left side of radiator. |
| Front Washer Motor | Right side of engine compartment near battery. |
| Front Wiper Motor | On left side of cowl. |
| Fuel Pump | At left side of fuel tank. (Scheme 2) |
| Headlight Retractor Motors | Behind each headlight assembly. |
| Radiator Cooling Fan Motor | On back of radiator. |
| Sunroof Motor | At front of sunroof under headliner. |
MOTORS LOCATION
SOLENOIDS/SOLENOID VALVES
| Component | Location |
|---|---|
| Air Suction Control Solenoid Valve | In emission control box No. 1. (Scheme 6) |
| Air Vent Cut-Off Solenoid Valve | Under air cleaner assembly. (Scheme 6) |
| Anti-Afterburn Control Solenoid Valve | In emission control box No. 2. (Scheme 6) |
| Auxiliary Slow Fuel Cut-Off Solenoid | On side of carburetor. |
| Control Switch Solenoid Valve | In emission control box No. 1. (Scheme 6) |
| Cranking Leak Solenoid Valve | In emission control box No. 1. (Scheme 6) |
| EGR Control Solenoid Valve "A" | In emission control box No. 1. (Scheme 6) |
| EGR Control Solenoid Valve "B" | In emission control box No. 1. (Scheme 6) |
| Idle Control Solenoid Valve | On bracket near emission control box No. 2. (Scheme 6) |
| Inner Vent Solenoid Valve | Under air cleaner assembly. (Scheme 6) |
| Main Air Jet Solenoid Valve | On bottom of air cleaner housing. (Scheme 6) |
| Primary Slow Fuel Cut-Off Solenoid | On fuel inlet side of carburetor. |
| Recirculation Solenoids | Under right side of dash. |
SOLENOIDS/SOLENOID VALVES LOCATION
SWITCHES
| Component | Location |
|---|---|
| A/C Low Pressure Switch | In high pressure line near receiver-drier. |
| A/C Thermostatic Switch | On evaporator housing. |
| Air Suction Vacuum Switch | In emission control box No. 2. (Scheme 6) |
| Back-Up Light Switch (M/T) | On side of transaxle near speedometer holder. |
| Brake/Stoplight Switch | On brake pedal bracket. |
| EGR Vacuum Switch (A/T) | In emission control box No. 1. (Scheme 6) |
| Inhibitor Switch (A/T) | Under selector lever console. |
| Main Air Jet Vacuum Switch (M/T) | In emission control box No. 1. (Scheme 6) |
| Parking Brake Switch | Under rear of parking brake lever. |
| Vacuum Switches "A", "B" & "C" | In emission control box No. 1. (Scheme 6) |
SWITCHES LOCATION
MISCELLANEOUS COMPONENTS
| Component | Location |
|---|---|
| Fuse & Relay Block | Under left side of dash. (Scheme 1) |
| Headlight Warning Chime | On left kick panel. (Scheme 1) |
| Low Fuel Thermistor | In fuel tank on fuel gauge sending unit. (Scheme 2) |
| Speed Sensor Amplifier | On back of speedometer. |
MISCELLANEOUS COMPONENTS LOCATION
COMPONENT LOCATION GRAPHICS
Note. Figures may show multiple component locations. Refer to appropriate table for proper figure references.
