Power Windows: Diagnosis Honda Pilot II

Power Window Master Switch Input Test

Note. Before testing, troubleshoot the multiplex integrated control unit first, using B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 44

1. Turn the ignition switch to LOCK (0), and remove the power window master switch (see «POWER WINDOW MASTER SWITCH REPLACEMENT»(ref-333619-S07541619552009072100000) ).
2. Disconnect the 37P connector (A) from the power window master switch (B).
3. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary and recheck the system. If the terminals look OK, go to step 4 .
4. With the connector still disconnected from the power window master switch, do the following input tests. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 5 . TEST CONDITION TABLE Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 27 BRN Disconnect the front passenger's power window switch 37P connector Check for continuity between terminal No. 27 and front passenger's power window switch 37P connector terminal No. 29: There Should be continuity. An open in the UART wire 12 RED Connect terminals No. 25 and No. 24 (or No. 12), and terminal No. 12 (or No. 24) with jumper wires. Check driver's power window motor operation: The driver's power window should open (or close). Faulty driver's power window motor Blown No. 26 (20 A) fuse in the under-dash fuse/relay box An open or high resistance in the wire 24 GRN 23 BLU Connect terminals No. 25 and No. 36 (or No. 23) with jumper wires. Connect No. 13 terminal and the left rear power window switch 14P connector terminal No. 8 Check left rear power window motor operation: The left rear power window should open (or close). Poor ground (G503) or an open in the ground wire Faulty left rear power window switch Faulty left rear power window motor An open or high resistance in the wire 36 GRY 21 GRY Connect terminals No. 25 and No. 34 (or No. 21) with jumper wires. Connect No. 13 terminal and the left rear power window switch 14P connector terminal No. 8 Check right rear power window motor operation: The right rear power window should open (or close). Poor ground (G503) or an open in the ground wire Faulty right rear power window switch Faulty right rear power window motor An open or high resistance in the wire 34 GRN 26 LT BLU Connect terminals No. 25 and No. 26 with jumper wires. Check left and right rear power window switch lights: The left and right rear power window switch lights should come on. Faulty LED Poor ground (G502, G503) or an open in the ground wire Faulty left and right rear power window switch An open or high resistance in the wire
5. Reconnect the connector to the door multiplex control unit, turn the ignition switch to ON (II), and do the following input tests. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the door multiplex control unit is faulty; replace the power window master switch (see «POWER WINDOW MASTER SWITCH REPLACEMENT»(ref-333619-S07541619552009072100000) ). NOTE: After replacing the power window master switch, «RESETTING THE POWER WINDOW CONTROL UNIT»(ref-333619-S14437456172009072100000) . TEST CONDITION TABLE Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 32 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G401) An open or high resistance in the ground wire 37 13 WHT Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 23 (10 A) fuse in the under-hood fuse/relay box Faulty under-dash fuse/relay box A short to ground in the wire An open or high resistance in the wire 14 YEL Ignition switch ON (II) Measure the voltage to ground: There should be battery voltage. Blown No. 36 (10 A) fuse in the under-dash fuse/relay box Faulty IG2 cut relay Faulty under-dash fuse/relay box A short to ground in the wire An open in the wire 25 WHT Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 26 (20 A) fuse in the under-dash fuse/relay box Faulty under-dash fuse/relay box A short to ground in the wire An open or high resistance in the wire 3 RED Ignition switch ON (II) Measure the voltage to ground: There should be battery voltage Faulty door multiplex control unit A short to ground in the wire 20 BRN Ignition switch ON (II), and driver's power window moving up or down Measure the voltage between terminals No. 20 and No. 37: An analog meter should alternate between 0 V-about 5 V (a digital voltmeter should read about 2.5 V while the window moves). Faulty door multiplex control unit Poor ground (G401) or an open in ground wire Faulty driver's power window motor An open or high resistance in the wire A short to ground in the wire 22 LT BLU Ignition switch ON (II), and driver's power window moving up or down Measure the voltage between terminals No. 22 and No. 37: An analog meter should alternate between 0 V and about 5 V (a digital voltmeter should read about 2.5 V while the window moves). Faulty door multiplex control unit Poor ground (G401) or an open in the ground wire Faulty driver's power window motor An open or hight resistance in the wire A short to ground in the wire

Scheme 45

1. Turn the ignition switch to LOCK (0), and remove the front passenger's power window switch (see «FRONT PASSENGER'S POWER WINDOW SWITCH REPLACEMENT»(ref-333619-S12915818722009072100000) ).
2. Disconnect the 37P connector (A) from the front passenger's power window switch (B).
3. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary and recheck the system. If the terminals look OK, go to step 4 .
4. With the connector still disconnected, do these input tests at the following connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 5 . TEST CONDITION TABLE Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 12 BLU Under all conditions, connect terminals No. 25 and No. 24 (or No. 12), and terminals No. 37 and No. 12 (or No. 24) with jumper wires. Check front passenger's power window motor operation: The driver's power window should open (or close). Poor ground (G404) or an open int he ground wire Faulty front passenger's power window motor An open or high resistance in the wire 24 RED 29 BRN Under all conditions, disconnect the power window master switch 37P connector Check for continuity between terminal No. 29 and the power window master switch 37P connector terminal No. 27: There Should be continuity. An open in the UART wire
5. Reconnect the connector to the front passenger's power window switch, turn the ignition switch to ON (II), and do these input tests. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, replace the front passenger's power window switch (see «FRONT PASSENGER'S POWER WINDOW SWITCH REPLACEMENT»(ref-333619-S12915818722009072100000) ). NOTE: With the front passenger's power window AUTO UP/AUTO DOWN function, «RESETTING THE POWER WINDOW CONTROL UNIT»(ref-333619-S14437456172009072100000) . TEST CONDITION TABLE Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 37 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G404) An open or hight resistance in the ground wire 25 GRN Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 4 (P/W) (40 A) fuse in the under-hood fuse/relay box Blown No. 30 (20 A) fuse in the under-dash fuse/relay box Faulty under-dash fuse/relay box Faulty under-hood fuse/relay box An open or high resistance in the wires 26 WHT Ignition switch ON (II) Measure the voltage to ground: There should be battery voltage. Faulty front passenger's power window switch A short to ground in the wire 27 PNK Ignition switch ON (II), and the front passenger's power window moving up or down. Measure the voltage between terminals No. 27 and No. 37: An analog between should 0 V & about 5 V (a digital voltmeter should read about 2.5 V while the window moves). Faulty front passenger's power window switch Faulty front passenger's power window motor An open or high resistance in the wire A short to ground in the wire Short to ground in the wire Poor ground (G404) or an open in the ground wire 28 GRN Ignition switch ON (II), and the front passenger's power window moving up or down. Measure the voltage between terminals No. 28 and No. 35: An analog meter should alternate between 0 V and about 5 V (a digital voltmeter should read about 2.5 V while the window moves). Faulty front passenger's power window switch Faulty front passenger's power window motor An open or high resistance in the wire A short to ground in the wire Poor ground (G404) or an open in the ground wire 36 BLK Under all conditions, disconnect the front passenger's power window motor 6P connector. Check for continuity to ground: There should be continuity. Poor ground (G404) An open or high resistance in the wire

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

1. Remove the power window master switch (see «POWER WINDOW MASTER SWITCH REPLACEMENT»(ref-333619-S07541619552009072100000) ).
2. Test the motor in each direction by connecting battery power and ground to the power window master switch 37P connector (A) according to the table below.
3. If the motor does not run or fails to run smoothly, go to step 4 , if the motor runs smoothly, go to step 8 .
4. Remove the door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-333581-S09178406072009072100000) ).
5. Disconnect the 6P connector (A) from the driver's power window motor (B).
6. Check for continuity between power window master switch 37P connector terminals No. 12 and No. 24 and driver's power window motor 6P connector terminals No. 1 and No. 4 respectively. There should be continuity. CONNECTOR TERMINAL REFERENCE TABLE POWER WINDOW MASTER SWITCH 37P CONNECTOR DRIVER'S POWER WINDOW MOTOR 6P CONNECTOR Terminal No. 12 Terminal No. 4 Terminal No. 24 Terminal No. 1
7. If there is not continuity, repair an open or high resistance in the wires If the wire harness in OK, replace the driver's power window motor (see «FRONT DOOR GLASS AND REGULATOR REPLACEMENT»(ref-333581-S08181453192009072100000) ). Hall IC (Pulser) Test
8. Check for continuity between driver's power window motor 6P connector terminal No. 2 and body ground. There should be continuity. If there is continuity, go to step 9 . If there is no continuity, check for an open in the BLK wire or poor ground (G401).
9. Do the power window master switch input test at terminals No. 3, No. 20 and No. 22 (see «POWER WINDOW MASTER SWITCH INPUT TEST»(ref-333619-S33118904272009072100000) ).

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

1. Remove the front passenger's power window switch (see «FRONT PASSENGER'S POWER WINDOW SWITCH REPLACEMENT»(ref-333619-S12915818722009072100000) ).
2. Test the motor in each direction by connecting battery power and ground to the front passenger's power window switch 37P connector (A) according to the table below.
3. If the motor does not run or fails to run smoothly, go to step 4 , if the motor runs smoothly, go to step.
4. Remove the door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-333581-S09178406072009072100000) ).
5. Disconnect the 6P connector (A) from the front passenger's power window motor (B).
6. Check for continuity between front passenger's power window switch 37P connector terminals No. 12 and No. 24 and front passenger's power window motor 6P connector terminals No. 1 and No. 4 respectively. There should be continuity. CONNECTOR TERMINAL REFERENCE TABLE FRONT PASSENGER'S POWER WINDOW SWITCH 37P CONNECTOR FRONT PASSENGER'S POWER WINDOW MOTOR 6P CONNECTOR Terminal No. 12 Terminal No. 4 Terminal No. 24 Terminal No. 1
7. If there is no continuity, repair an open or high resistance in the wires. If the wire harness in OK, replace the front passenger's power window motor (see «FRONT DOOR GLASS AND REGULATOR REPLACEMENT»(ref-333581-S08181453192009072100000) ).
8. Check for continuity between front passenger's power window motor 6P connector terminal No. 2 and body ground. There should be continuity. If there is continuity, go to step 9. If there is no continuity, check for an open or high resistance in the BLK wire or poor ground (G404).
9. Do the front passenger's power window switch input test at terminals No. 26, No. 27, No. 28 and No. 36 (see «FRONT PASSENGER'S POWER WINDOW SWITCH INPUT TEST»(ref-333619-S07935294352009072100000) ).

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. Remove the door panel (see «FRONT DOOR SIDE SILL SEAL REPLACEMENT»(ref-333581-S16384579282009072100000) ), and disconnect the rear door wire harness 13P connector (A) from the rear door sub harness.
2. At the rear door wire harness 13P connector, test the power window motor in each direction by connecting battery power and ground according to the table below. When the motor stops running, disconnect one lead immediately.
3. If the motor does not run or fails to run smoothly, go to step 4 .
4. Disconnect the 2P connector (A) from the rear power window motor (B).
5. Check for continuity between rear power window motor 2P connector terminals No. 1 and No. 2 and the door wire harness 13P connector terminals No. 1 and No. 7 respectively. There should be continuity.
6. If there is no continuity, repair an open or high resistance in the wires. If the wire harness is OK, replace the power window motor.

Scheme 60

Scheme 61

1. Remove the rear door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(ref-333581-S31806712062009072100000) .
2. Remove the screws and disconnect the connector (A) from the rear power window switch (B), them remove the switch assembly from the door panel.
3. Remove the three screws and the rear power window switch (A).
4. Swap the rear power window switch with an other known-good rear power window switch and test. If the original power window switch is faulty; replace it.
5. Install the switch in the reverse order of removal.

Scheme 62

Scheme 63

1. Carefully remove the power window switch panel (A).
2. Disconnect the 37P connector (B) from the power window master switch, and the 13P connector (C) from the power mirror switch.
3. Remove the four screws and the power window master switch (A).
4. Install the switch in the reverse order of removal.
5. «RESETTING THE POWER WINDOW CONTROL UNIT»(ref-333619-S14437456172009072100000) .

Scheme 64

Scheme 65

1. Carefully remove the front passenger's power window switch panel (A).
2. Disconnect the 37P connector (B) from the front passenger's power window switch.
3. Remove the four screws and the front passenger's power window switch (A).
4. Install the switch in the reverse order of removal.
5. «RESETTING THE POWER WINDOW CONTROL UNIT»(ref-333619-S14437456172009072100000) .
