Multi-information Display
The maintenance minder is an important feature of the multi-information display (TOURING model). Based on engine operating conditions and accumulated engine revolutions, the Pilot's onboard computer (PCM) calculates the remaining engine oil and automatic transmission fluid life. The system also displays the codes for other scheduled maintenance items needing service.
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Scheme 28
- The remaining engine oil life (A) is shown as a percentage on the multi-information display. To see the current engine oil life, turn the ignition switch to ON (II), then push and release the Sel/Reset button repeatedly until the engine oil life is displayed.
- When the ignition switch is ON (II), and the remaining engine oil life is 6% to 15%, the remaining engine oil life and other scheduled maintenance item(s) needing service are displayed. The maintenance system message "SERVICE DUE SOON" (A) also comes on. To cancel the message, press the Info button. The display continues to show the remaining engine oil life (B) and the message indicator (C) until it is reset. Complete list of maintenance main items (D) (see «MAINTENANCE MAIN ITEMS»(ref-333543-S23745298982009072100000) ). Complete list of maintenance sub items (E) (see «MAINTENANCE SUB ITEMS»(ref-333543-S27982213462009072100000) ).
- When the ignition switch is ON (II), and the remaining engine oil life is 1% to 5%, the maintenance system message "SERVICE DUE NOW" is displayed along with the same maintenance item code(s). If the maintenance system message display is cancelled, a "SERVICE" message appears.
- When the ignition switch is ON (II), and the remaining engine oil life is 0%, the maintenance system message "SERVICE PAST DUE" is displayed along with the same maintenance item code(s).
- If the indicated maintenance is not done, the "SERVICE PAST DUE" message shows a negative mileage, for example "-10," on the display. If the negative mileage is between 0 and -9, the message is displayed for only a few seconds when the ignition switch is turned to ON (II). The negative mileage (A) remains displayed after the vehicle is driven more than 10 miles (for USA models) or 10 km (for Canada models) after 0% oil life is reached, and the display cannot be cancelled. This means the indicated maintenance item(s) should have been done more than 10 miles (or 10 km) ago.
Note. The vehicle must be stopped to reset the display. If a required service is done and the display is not reset, or if the maintenance display is reset without doing the service, the system will not show the proper maintenance timing. This can lead to serious mechanical problems because there will be no accurate record of when the required maintenance is needed. The engine oil life and the maintenance items can be reset independently only with the HDS.
Scheme 29
Scheme 30
- Turn the ignition switch to ON (II).
- If system message(s) are displayed, press the Info button to cancel the display.
- Push and release the Sel/Reset button repeatedly until the engine oil life indicator is displayed.
- Press and hold the Sel/Reset button for about 10 seconds, the "OIL LIFE RESET" mode display appears. NOTE: If you are resetting the display when the engine oil life is more than 15%, make sure any maintenance item(s) requiring service are done before resetting the display. To cancel the "OIL LIFE RESET" mode, press the Info button repeatedly until the "CANCEL" indicator is displayed, then press the Sel/Reset button.
- Press Info button repeatedly until the "RESET" indicator is displayed, then press the Sel/Reset button. The maintenance item code(s) will disappear, and the engine oil life will reset to "100%".
- Connect the Honda Diagnostic System (HDS) to the data link connector (DLC).
- Turn the ignition switch to ON (II).
- Make sure the HDS communicates with the vehicle and the powertrain control module (PCM). If it doesn't communicate, troubleshoot the DLC circuit.
- Select GAUGES in the BODY ELECTRICAL with the HDS.
- Select ADJUSTMENT in the GAUGE MENU with the HDS.
- Select MAINTENANCE INFORMATION in the ADJUSTMENT with the HDS.
- Select RESET in the MAINTENANCE INFORMATION with the HDS.
- Select the individual maintenance item you wish to reset.
If the message "SERVICE" or SERVICE DUE NOW" does not appear more than 12 months after the display is reset, change the engine oil every year.
Note. Independent of the maintenance messages in the in the multi information display, replace the brake fluid every 3 years. Inspect idle speed every 160,000 miles (256,000 km). Adjust the valves during services A, B, 1, 2 or 3 if they are noisy.
| Symbol | Maintenance Main Items |
|---|---|
| A | Replace engine oil (see ENGINE OIL REPLACEMENT ) Engine oil capacity without oil filter: 4.0 L (4.2 US qt) |
| B | Replace engine oil and oil filter (see ENGINE OIL FILTER REPLACEMENT ) Engine oil capacity with oil filter: 4.3 L (4.5 US qt) |
| Check front and rear brakes (see COMPONENT LOCATION INDEX ) Check pads and discs for wear (thickness), damage, and cracks. Check calipers for damage, leaks, and tightness of mounting bolts. Check brake linings for cracking, glazing, wear and for oil grease contamination. | |
| Check parking brake adjustment (see PARKING BRAKE INSPECTION AND ADJUSTMENT ) Number of clicks 8 to 10 when the parking brake pedal is pressed with 294 N (30 kgf, 66 lbf) of force. | |
| Inspect tie-rod ends, steering gearbox, and gearbox boots (see STEERING LINKAGE AND GEARBOX INSPECTION ) Check steering linkage. Check boots for damage and leaking grease. Check fluid lines for damage or leaks. | |
| Inspect suspension components (see COMPONENT LOCATION INDEX ) Check bolts for tightness. Check condition of ball joint boots for deterioration and damage. | |
| Inspect driveshaft boots (see DRIVESHAFT INSPECTION ) Check boots for cracks and boot bands for tightness. | |
| Inspect brake hoses and lines including VSA lines (see BRAKE HOSE AND LINE INSPECTION ) Check the master cylinder and VSA modulator for damage and leakage. | |
| Inspect all fluid levels and condition of fluids Engine coolant (see COOLANT CHECK ). Automatic transmission fluid (ATF) (see ATF LEVEL CHECK ). Transfer fluid (FWD Models) (see TRANSFER ASSEMBLY FLUID REPLACEMENT ). Rear differential fluid (4WD Models) (see DIFFERENTIAL FLUID INSPECTION AND REPLACEMENT ). Power steering fluid (see FLUID LEAKAGE INSPECTION ). Brake fluid (see BRAKE SYSTEM BLEEDING ). Windshield washer fluid (see WASHER RESERVOIR REPLACEMENT ). | |
| Inspect exhaust system* (see EXHAUST PIPE AND MUFFLER REPLACEMENT ) Check catalytic converter heat shields, exhaust pipes, and mufflers for damage, leaks, and tightness. | |
| Inspect fuel lines* (see FUEL LINE INSPECTION ), and connections* (see FUEL LINE/QUICK-CONNECT FITTING PRECAUTIONS ) Check for loose connections, cracks, and deterioration; retighten loose connections and replace damaged parts. | |
| NOTE: According to state and federal regulations, failure to do the maintenance items marked with an asterisk (*) will not void the client's emissions warranties. However, Honda recommends that all maintenance services be done at the recommended interval, to ensure long-term reliability. | |
| NOTE |
|---|
| According to state and federal regulations, failure to do the maintenance items marked with an asterisk (*) will not void the client's emissions warranties. However, Honda recommends that all maintenance services be done at the recommended interval, to ensure long-term reliability. |
MAINTENANCE MAIN ITEMS REFERENCE TABLE
| Number | Maintenance Sub Items |
|---|---|
| 1 | Rotate tires, and check tire inflation and condition. Follow the pattern shown in the Owner's Manual. |
| 2 | Replace air cleaner element (see AIR CLEANER ELEMENT INSPECTION/REPLACEMENT ). If the vehicle is regularly driven in dusty conditions, replace every 15,000 miles (24,000 km). |
| Replace dust and pollen filter (see HVAC CONTROL UNIT REMOVAL/INSTALLATION ) If the vehicle is driven mostly in areas that have high concentrations of dust, pollen, or soot in the air, replace the filter at 15,000 miles (24,000 km). Replace the filter whenever airflow from the heating and air conditioning system is less than normal. | |
| Inspect drive belt (see DRIVE BELT INSPECTION ). Look for cracks and damage, and inspect auto tensioner; no adjustment is needed. | |
| 3 | Replace automatic transmission fluid (see ATF REPLACEMENT ) and transfer fluid, (see TRANSFER ASSEMBLY FLUID REPLACEMENT ) Automatic transmission fluid capacity: 2.8 L (3.0 US qt), use Honda ATF-Z1. Transfer fluid capacity: 0.43 L (0.45 US qt), use hypoid gear oil GL4 or GL5. |
| 4 | Replace spark plugs (see SPARK PLUG INSPECTION ) Use ILZKR7B-11 |
| Replace timing belt (see TIMING BELT REPLACEMENT ) and inspect water pump, (see WATER PUMP INSPECTION ) If the vehicle is regularly driven in very high temperatures (over 110°F, 43°C), or in very low temperatures (under -20°F, -29°C), replace every 60,000 miles (USA)/100,000 km (Canada). | |
| Inspect the valve clearance (cold) (see VALVE CLEARANCE ADJUSTMENT ). Otherwise adjust only if noisy. Intake: 0.20-0.24 mm (0.008-0.009 in), Exhaust: 0.28-0.32 mm (0.011-0.013 in). | |
| 5 | Replace engine coolant (see COOLANT CHECK ). Capacity (including the reserve tank): 7.5 L (1.98 US gal), use Honda Long Life Antifreeze/Coolant Type 2. |
| 6 | Replace VTM-4 rear differential fluid (4WD models) (see DIFFERENTIAL FLUID INSPECTION AND REPLACEMENT ). Driving in mountainous areas at very low vehicle speeds or trailer towing results in higher level of mechanical (shear) stress to fluid. This requires differential fluid changes more frequently than recommended by the maintenance minder. If the vehicle is regularly driven in these conditions, have the differential fluid changed at 7,500 miles (12,000 km), then every 15,000 miles (24,000 km). Capacity: Clutch chambers 2.64 L (2.79 US qt), use Honda VTM-4 Differential Fluid. |
MAINTENANCE SUB ITEMS REFERENCE TABLE
