Power Windows: Diagnosis Honda Pilot I рестайлинг

Windows 8 illustrations ~360 words

Driver's Window Motor Test

Motor Test

Scheme 3

Scheme 3: Driver's Window Motor Test
Scheme 3: Driver's Window Motor Test

Scheme 4

Scheme 4
Scheme 4
  1. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-243346-S33342185312006082300000) ).
  2. Disconnect the 6P connector (A) from the window motor.
  3. Test the motor in each direction by connecting battery power and ground according to (Scheme 4). When the motor stops running, disconnect one lead immediately.
  4. If the motor does not run or does not run smoothly, replace it.
  5. Reconnect the 6P connector to the window motor.
  6. Check for voltage between the terminals. There should be battery voltage between the No. 6 (+) and No. 4 (-) terminals when the ignition switch is ON (II). Connect an analog voltmeter between the No. 5 (+) and No. 4 (-) terminals, and run the window motor at down or up. The voltmeter needle should move back and forth alternately (a digital voltmeter should show the average voltage between 0-5 V). Connect an analog voltmeter between the No. 3 (+) and No. 4 (-) terminals, and run the window motor at down or up. The voltmeter needle should move back and forth alternately (a digital voltmeter should show the average voltage between 0-5 V).

Scheme 5

Scheme 5: Passenger's Window Motor Test
Scheme 5: Passenger's Window Motor Test

Scheme 6

Scheme 6
Scheme 6
  1. Remove the passenger's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-243346-S33342185312006082300000) ).
  2. Disconnect the 2P connector from the window motor.
  3. Test the motor by connecting battery power and ground according to (Scheme 6). When the motor stops running, disconnect one lead immediately.
  4. If the motor does not run or fails to run smoothly, replace it.

Scheme 7

Scheme 7: Power Window Master Switch Replacement
Scheme 7: Power Window Master Switch Replacement

Scheme 8

Scheme 8
Scheme 8
  1. Carefully pry off the driver's door switch trim (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-243346-S33342185312006082300000) ).
  2. Disconnect the power mirror and power window switch connectors (A).
  3. Remove the four mounting screws, then remove the master switch (A) from the panel (B).

Scheme 9

Scheme 9: Passenger's Power Window Switch Test/Replacement
Scheme 9: Passenger's Power Window Switch Test/Replacement

Scheme 10

Scheme 10
Scheme 10
  1. Carefully pry off the door switch trim (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-243346-S33342185312006082300000) ).
  2. Disconnect the 6P connector (A) from the power window switch (B), then remove the three mounting screws and the power window switch from the switch trim (C). Front Passenger's: Rear
  3. Swap the window switch with another known-good switch and test. If the original window switch is faulty, replace it.
