Moonroof: Adjustments Honda Pilot I рестайлинг

Glass Height Adjustment

The roof panel (A) should be even with the glass weatherstrip (B), to within 0+1/-1 mm (0+0.04/ -0.04 in.) all the way around. If not, make the following adjustment

Scheme 2

Scheme 3

1. Remove the bracket cover from each side (see step 3 ).
2. Using a T25 Torx bit, loosen the bolts on each side, and adjust the glass (A).
3. If necessary, repeat on the opposite side.

Scheme 4

Scheme 5

1. Close the glass fully.
2. Slide the sunshade all the way back.
3. Pry out the lid (A), remove the screws (B), and release the hooks (C), then remove both bracket covers (D).
4. Using a T25 Torx bit, remove the bolts (E) from both glass brackets (F).
5. Remove the glass (A) by lifting it up. Do not damage the roof panel.
6. Install the glass in the reverse order of the removal, and adjust the glass height alignment.
7. Check for water leaks. Use free-flowing water from a hose without a nozzle. Do not use high-pressure water. NOTE: It is normal for some water to seep past the moonroof into the moonroof frame, and exit out through the drains.

Scheme 6

Scheme 7

Scheme 8

1. Open the glass fully.
2. Remove the links (A) from both sides.
3. Remove the wind deflector (A).
4. Pry up on the deflector bases (A) and release the hooks (B), then remove the bases with springs (C) from both sides.
5. Install the deflector in the reverse order of removal.

Scheme 9

Scheme 10

Scheme 11

1. Fully close the moonroof, then place it in the full tilt-up position.
2. Remove the glass (see «GLASS REPLACEMENT»(ref-243351-S12172647042006082300000) ).
3. Disconnect the rod clips (A), then remove the drain channel rods (B) on both sides.
4. Slide the drain channel (A) forward.
5. Pull the rear edge of the drain channel (A) up while pushing both clips (B), and release the channel from both hooks (C) of the drain channel slider by pulling it rearward.
6. Remove the drain channel.
7. Install the channel in the reverse order of removal, and note these items: Push the clip portions into place securely. Full close the moonroof and check the glass height adjustment (see «GLASS HEIGHT ADJUSTMENT»(ref-243351-S04682139842006082300000) ).
8. Check for water leaks. Let the water run freely from a hose without a nozzle. Do not use a high-pressure spray.

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. Remove the drain channel (see «DRAIN CHANNEL REPLACEMENT»(ref-243351-S37233430822006082300000) ).
2. Slide the sunshade (A) until you can see both sunshade slider spacers (B).
3. Remove the screws, then remove both spacers.
4. While lifting the front portion of the sunshade (A), move the sunshade forward until you can see both sunshade rear hooks (B). Do not damage the sunshade and hooks.
5. Remove the screws, then remove both hooks.
6. Remove the sunshade (A).
7. Remove both front sunshade base sliders (A) and both rear sunshade base sliders (B).
8. Install the sunshade in the reverse order of removal, and check the glass height adjustment (see «GLASS HEIGHT ADJUSTMENT»(ref-243351-S04682139842006082300000) ).
9. Check for water leaks. Let the water run freely from a hose without a nozzle. Do not use a high-pressure spray.

Scheme 16

1. Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(ref-243321-S11796070262006082300000) ).
2. Put on gloves to protect your hands. Disconnect the connector (A), and remove the bolts, then remove the motor (B).
3. Install the motor in the reverse order of removal, and note these items: Make sure the connector is plugged in properly. Check the motor operation.
