Electronic Throttle Control System: Diagnosis Honda Pilot I рестайлинг

Removal & Installation 3 illustrations ~357 words

Diagnostic Trouble Codes Troubleshooting

DTCDescription
DTC P0122TP Sensor A Circuit Low Voltage
DTC P0123TP Sensor A Circuit High Voltage
DTC P0222TP Sensor B Circuit Low Voltage
DTC P0223TP Sensor B Circuit High Voltage
DTC P0607Lost Communication with Electronic Throttle Control System (ETCS)
DTC P061FElectronic Throttle Control System (ETCS) Malfunction
DTC P1658Electronic Throttle Control System (ETCS) Control Relay ON Malfunction
DTC P1659Electronic Throttle Control System (ETCS) Control Relay OFF Malfunction
DTC P1683Throttle Valve Default Position Spring Performance Problem
DTC P1684Throttle Valve Return Spring Performance Problem
DTC P2101Electronic Throttle Control System (ETCS) Malfunction
DTC P2118Throttle Actuator Current Range/Performance Problem
DTC P2122APP Sensor A (Throttle Position Sensor D) Circuit Low Voltage
DTC P2123APP Sensor A (Throttle Position Sensor D) Circuit High Voltage
DTC P2127APP Sensor B (Throttle Position Sensor E) Circuit Low Voltage
DTC P2128APP Sensor B (Throttle Position Sensor E) Circuit High Voltage
DTC P2135TP Sensor A/B Voltage Incorrect Correlation
DTC P2138APP Sensor A/B (Throttle Position Sensor D/E) Incorrect Voltage Correlation
DTC P2176Throttle Actuator Control System Idle Position Not Learned

DIAGNOSTIC TROUBLE CODES (DTC) LIST

APP Sensor Signal Inspection

Note. This procedure checks the APP sensor in its fully closed position. In any other position, the APP sensor stores DTCs which are covered in other troubleshooting procedure. Check for Temporary DTCs or DTCs with the HDS before doing this procedure. If any DTCs are indicated, troubleshoot them first, then do this procedure. Press the accelerator pedal several times to check its movement. If it does not move smoothly, check the pedal, the throttle cable, and the APP sensor individually. If you find a problem in one of them, replace the part(s) that caused the problem.

Scheme 29

Scheme 29: APP Sensor Signal Inspection
Scheme 29: APP Sensor Signal Inspection
  1. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard
  2. Turn the ignition switch ON (II).
  3. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is below 2%, the APP sensor is OK. If it is above 2%, adjust the throttle cable (see «RESONATOR REMOVAL/INSTALLATION»(ref-243301-S20222944452006082300000) ), then go to step 4 .
  4. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is below 2%, the APP sensor is OK. If it is above 2%, update the PCM if it does not have the latest software (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-243311-S19790429062006082300000) ), or substitute a known-good PCM (see «HOW TO SUBSTITUTE THE PCM»(ref-243311-S24543735662006082300000) ), then go to step 5 .
  5. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is below 2%, the APP sensor is OK. If it is above 2%, replace the APP sensor (see «APP SENSOR REPLACEMENT»(ref-243329-S15068172982006082300000) ), then go to step 1 .

Scheme 30

Scheme 30: APP Sensor Replacement
Scheme 30: APP Sensor Replacement

Scheme 31

Scheme 31
Scheme 31
  1. Remove the bolts and the throttle cable cover (A).
  2. Remove the throttle cable (see «THROTTLE CABLE REMOVAL/INSTALLATION»(ref-243301-S24896655932006082300000) ).
  3. Disconnect the APP sensor 6P connector (A).
  4. Remove the bolts (B) and APP sensor (C).
  5. Install the parts in the reverse order of removal.
