Interior Lights Honda Pilot I рестайлинг

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Front Individual Map Light Test

With moonroof

Scheme 5

Scheme 6

1. Turn the light switch OFF.
2. Carefully pry off the lens (A) with a small screwdriver. MAP LIGHT: 5 W x 2
3. Remove the two mounting screws.
4. Disconnect the 3P and 10P connectors (B) from the housing (C).
5. Check for continuity between the terminals in each switch position according to the illustration.
6. If the continuity is not as specified, check the bulb(s). If the bulb(s) are OK, replace the light.

Without moonroof

Scheme 7

1. Turn the light switch OFF.
2. Carefully pry off the lenses (A) with a small screwdriver. MAP LIGHT: 4CP x 2
3. Remove the four mountings screws.
4. Disconnect the 3P connector (B) from the roof console (C).
5. Check for continuity between the terminals in each switch position according to the table.
6. if the continuity is not as specified, check the bulb(s). If the bulb(s) are OK, replace the light.

Scheme 8

Scheme 9

1. Turn the light switch OFF.
2. Carefully pry off the lenses (A) with a small screwdriver. MAP LIGHT: 5 W x 2
3. Remove the two mounting screws.
4. Disconnect the 3P connector (B) from the housing (C).
5. Check for continuity between the terminals in each switch position according to the illustration.
6. Install in the reverse order of removal.

Scheme 10

1. Open the tailgate.
2. Carefully pry off the lens (A) with a small screwdriver. TAILGATE LIGHT: 5 W x 2
3. Remove the two mounting screws.
4. Disconnect the 3P connector (B) from the housing (C).
5. Check for continuity between the terminals. There should be continuity between the No. 1 and No. 3 terminals with the switch ON.
6. If the continuity is not as specified, check the bulb(s). If the bulb(s) are OK, replace the light.

Scheme 11

1. Open the tailgate.
2. Remove the tailgate trim panel (see «TRIM REMOVAL/INSTALLATION - TAILGATE AREA»(ref-243321-S05562555492006082300000) ).
3. Disconnect the 2P connector from the tailgate latch.
4. Check for continuity between the No. 1 and No. 2 terminals. With the tailgate open, there should be continuity. With the tailgate closed, there should be no continuity.
5. If the continuity is not as specified, replace the tailgate latch switch.

Scheme 12

1. Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/honda/pilot/i-2005-2008/remont/exteriorinterior-trim/#dashboard__glove-box-removalinstallation) ).
2. Disconnect the 2P connector (A) from the glove box light (B). GLOVE BOX LIGHT: 3.4 W
3. Check for continuity between the No. 1 and No. 2 terminals. With the button (C) pressed, there should be no continuity. With the button (C) released, there should be continuity.
4. If the continuity is not as specified, check the bulb. If the bulb is OK, replace the light.

Scheme 13

1. Remove the center lower cover (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/honda/pilot/i-2005-2008/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ).
2. Disconnect the 2P connector (A) from the front console light (B). FRONT CONSOLE LIGHT: 1.4 W
3. Turn the bulb socket (C) 45° counterclockwise to remove it from the light.

Scheme 14

1. Open the sunvisor.
2. Remove the sunvisor (see «HEADLINER REMOVAL/INSTALLATION»(ref-243321-S11796070262006082300000) ).
3. Disconnect the 2P connector (A) from the vanity mirror light. VANITY MIRROR LIGHT: 1.1 W
4. Check for continuity between the No. 1 and No. 2 terminals. With the vanity mirror cover (B) opened, there should be continuity. With the vanity mirror cover closed, there should be no continuity.
5. If the continuity is not as specified, check the bulbs. If the bulbs are OK, replace the sunvisor.

Scheme 15

1. Carefully pry off the lens (A) with a small screwdriver. COURTESY LIGHT: 3.8 W
2. Remove the bulb (B) from the socket.

Scheme 16

Scheme 17

1. Remove the switch panel (see «DRIVER'S SWITCH PANEL REMOVAL/INSTALLATION»(/honda/pilot/i-2005-2008/remont/exteriorinterior-trim/#dashboard__drivers-switch-panel-removalinstallation) ).
2. Disconnect the 6P connector (A) from the interior lights switch (6).
3. Pull the interior lights switch out of the switch panel.
4. Check for continuity between the terminals in each switch position according to the illustration.
5. If the continuity is not as specified, replace the bulb (C) or the switch.

Scheme 18

1. Turn the combination light switch OFF.
2. Carefully pry off the lens (A) with a small screwdriver.
3. Remove the four mounting screws.
4. Disconnect the 3P and 10P connectors (B) from the housing (C).
5. Remove the ambient light module assembly (D).
6. The ambient light should come on when power is connected to the No. 4 terminal and ground is connected to the No. 1 terminal.
7. If the LED does not come on, replace the ambient light module assembly.
