Active Noise Control Unit Connector For Inputs And Outputs (2WD)
When replacing an active noise control unit connector, match the wires to the cavities listed in CONNECTOR TERMINAL REFERENCE TABLE .
Scheme 6
| Cavity | Wire | Connect to |
|---|---|---|
| 1 | GRY/YEL | Audio unit (ANC RR+) |
| 2 | BLK | Audio unit (ANC FR+) |
| 3 | ORN | Active noise control rear microphone (RR MIC+) |
| 4 | Not used | |
| 5 | Not used | |
| 6 | Not used | |
| 7 | BLK | Ground (G401) |
| 8 | YEL/BLK | ACC (main stereo power supply) |
| 9 | WHT | Audio unit (ANC RR-) |
| 10 | GRN | Audio unit (ANC FR-) |
| 11 | GRN | Active noise control rear microphone (RR MIC-) |
| 12 | RED/BLK | Audio unit (ANC CHK2) |
| 13 | Not used | |
| 14 | PNK | PCM (CCSAM) |
| 15 | BLU | PCM, VTM-4 control unit (NED) |
| 16 | BLK/WHT | Passenger's multiplex control unit (INTR LT) |
CONNECTOR TERMINAL REFERENCE TABLE
Active Noise Control Rear Microphone Connector for Inputs and Outputs (2WD)
When replacing an active noise control rear microphone connector, match the wires to the cavities listed in CONNECTOR TERMINAL REFERENCE TABLE .
Scheme 7
| Cavity | Wire | Connect to |
|---|---|---|
| 1 | ORN | Active noise control unit RR MIC+) |
| 2 | LT GRN | Active noise control unit (RRMIC-) |
| 3 | BLK | Ground (G 503) |
| 4 | YEL | ACC (main stereo power supply) |
| 5 | Not used |
CONNECTOR TERMINAL REFERENCE TABLE
Self-Diagnostic Function
The audio system has a self-diagnostic function. To run the self-diagnostic function, do the following
Scheme 8
- Turn the ignition switch to the ACC (I) or ON (II) position.
- Enter the anti-theft code.
- Turn off the audio unit.
- Push and hold the "1" and "DISC 6" buttons. While holding the buttons, push the "VOL push PWR" knob (A) to ON. Release the buttons and the self-diagnostic function will begin.
- "DIAGNOSTIC" will appear on the audio unit to indicate you have entered the self-diagnostic mode.
- By pressing a preset button while "DIAG" is displayed, the input will trigger the diagnostic mode that is assigned to that preset switch. "3" button Entire LCD lighting mode: Turns on the entire LCD to show the presence or absence of an LCD failure. "4" button Entire LCD light-out mode: Turns off the entire LCD to show the presence or absence of an LCD failure. "1" button (2WD) Active noise control system function check mode: How to check the active noise control system in this check mode With the engine stopped and while in "DIAGNOSTIC" mode, turn the ANC ON to OFF by pressing the No. 1 button, a low-Frequency hum (50 Hz) should sound for about a minute. If the hum does not sound, check for an open in the wire between the active noise control unit and the audio unit. If the hum does not sound for a minute, check for an open in the wire between the active noise control unit and the microphone. Start the engine while the hum is sounding, the hum should stop. If the hum does not stop, check for an open in the wire (NEP line) between the active noise control the unit and PCM. Test drive at 55 mph (88 km/h) and enter the "DIAGNOSTIC" mode, turn the active noise control system OFF and back to ON (II), the active noise control system should activate. NOTE: The active noise control system is cancelled when any of the doors is opened. "DISP/MODE" button DVD player unit region code display mode: Display region code for DVD player unit.
- The self-diagnostic function will end when the audio unit is turned off, or the ignition switch is turned off.
