Charging System: Overhaul Honda Pilot I рестайлинг

Overhaul

Note. Refer to EXPLODED VIEW as needed during this procedure.

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

1. Test the alternator and regulator before you remove them (see «CHARGING SYSTEM INDICATOR CIRCUIT TROUBLESHOOTING»(ref-243303-S39337147452006082300000) ).
2. Remove the alternator (see «ALTERNATOR REMOVAL AND INSTALLATION»(ref-243303-S32825880642006082300000) ).
3. If the front bearing needs replacing, remove the pulley locknut with a 10 mm wrench (A) and a 22 mm wrench (B). If necessary, use an impact wrench.
4. Remove the three flange nuts.
5. Remove the end cover (A) and the insulator (B).
6. Remove the brush holder.
7. Remove the four bolts, then remove the rear housing assembly (A) and washer (B).
8. If you are not replacing the front bearing, go to step 13 . Remove the rotor from the drive end housing.
9. Inspect the rotor shaft for scoring, and inspect the bearing journal surface in the drive end housing for seizure marks. If the rotor is damaged, replace the rotor assembly. If the rotor is OK, go to step 10 .
10. Remove the front bearing retainer plate.
11. Drive out the front bearing with a brass drift and hammer.
12. With a hammer and special tools, install a new front bearing in the drive end housing. Alternator Brush Inspection
13. Measure the length of both brushes (A) with vernier caliper (B). If either brush is shorter than the service limit, replace the brush holder assembly. If the brush length is OK, go to step 14 . Alternator Brush Length Standard (New): 10.5 mm (0.41 in.) Service Limit: 1.5 mm (0.06 in.)
14. Check for continuity between the slip rings (A). If there is continuity, go to step 15 . If there is no continuity, replace the rotor assembly.
15. Check for continuity between each slip ring and the rotor (B) and the rotor shaft (C). If there is no continuity, replace the rear housing assembly, and go to step 16 . If there is continuity, replace the rotor assembly.
16. If you removed the pulley, put the rotor in the drive end housing, then torque it's locknut to 110N.m (11.2 kgf.m, 81.0 lbf.ft)
17. Remove any grease or any oil from the slip rings.
18. Put the rear housing assembly and drive end housing/rotor assembly together, torque the four through bolts.
19. Push the brushes (A) in, then insert a pin or drill bit (B) (about 1.6 mm (0.06 in.) diameter) to hold them there.
20. Install the brush holder, and pull out the pin.
21. Install the end cover.
22. After assembling the alternator, turn the pulley by hand to make sure the rotor smoothly and without noise.
23. Install the alternator (see «Installation»(ref-243303-S26620358592006082300000) ) and drive belt (see «Drive Belt Replacement»(ref-243303-S08207774762006082300000) ).
