Seat Belts: Other Honda Pilot I

Restraints Control Systems 13 illustrations ~674 words

Left Seat Belt Buckle & Center Seat Belt Detachable Anchor

Note. Take care not to tear the seams or damage the seat covers.

Scheme 35

Scheme 35: Left Seat Belt Buckle & Center Seat Belt Detachable Anchor
Scheme 35: Left Seat Belt Buckle & Center Seat Belt Detachable Anchor

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38
  1. Remove the left second row seat (see «SECOND ROW SEAT REMOVAL/INSTALLATION»(ref-174049-S19923431502005050300000) ).
  2. From the back of the seat, remove the screws (A), then remove the anchor cover (B).
  3. Remove the center anchor bolts (A).
  4. Release the hooks (A), then remove the seat belt buckle pocket (B).
  5. Remove the left second row seat belt buckle (A) and center second row seat belt detachable anchor (B) from the elastic straps (C), and remove them from the seat cushion.
  6. Install the buckle and the detachable anchor in the reverse order of removal, and apply liquid thread lock to the anchor bolts before reinstallation.

Center Seat Belt Buckle/Right Seat Belt Buckle

Note. The center seat belt buckle is shown, and the right seat belt buckle is similar.

Scheme 39

Scheme 39: Center Seat Belt Buckle/Right Seat Belt Buckle
Scheme 39: Center Seat Belt Buckle/Right Seat Belt Buckle

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43
  1. Remove the second row seat (see «SECOND ROW SEAT REMOVAL/INSTALLATION»(ref-174049-S19923431502005050300000) ).
  2. From both sides of the seat, release the hooks (A, B) in the sequence shown, then remove the pivot bolt cover (C). Using a Torx T30 bit, remove the pivot bolt (D).
  3. On the left second row seat: Remove the seat belt buckle pocket.
  4. On the left second row seat: Remove the left second row seat belt buckle (A) and center second row seat belt detachable anchor (B) from the elastic straps (C), then remove the buckle and detachable anchor under the seat cushion.
  5. Remove the center seat belt buckle (D) or right seat belt buckle from the elastic strap (E).
  6. Lift the seat cushion (A) up.
  7. Remove the screws (A), then remove the center cover (B).
  8. Remove the center anchor bolt (A), and remove the seat belt buckle (B).
  9. Install the buckle in the reverse order of removal, and apply liquid thread lock to the anchor bolt before reinstallation.

Seat Belt Buckle/Seat Belt Detachable Anchor

Note. The seat belt buckle is shown, and the seat belt detachable anchor is similar.

Scheme 44

Scheme 44: Seat Belt Buckle/Seat Belt Detachable Anchor
Scheme 44: Seat Belt Buckle/Seat Belt Detachable Anchor

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46
  1. Remove the third row seat (see «THIRD ROW SEAT REMOVAL/INSTALLATION»(ref-174049-S28205154032005050300000) ).
  2. Remove the screw (A), and release the hook (B), then remove the bracket cover (C).
  3. Remove the center anchor bolt (A), then remove the seat belt buckle (B).
  4. Install the buckle in the reverse order of removal. Assemble the washers, spring, bushing, bracket, and collar on the center anchor bolt as shown.

In-vehicle

  1. Check that the seat belt is not twisted or caught on anything.
  2. After installing the anchors, check for free movement on the anchor bolts. If necessary, remove the anchor bolts and check that the washers and other parts are not damaged or improperly installed.
  3. Check the seat belts for damage or discoloration. Clean with a shop towel if necessary. Use only soap and water to clean.
  4. Check that the seat belt does not lock when pulled out slowly. The seat belt is designed to lock only during a sudden stop or impact.
  5. Make sure that the seat belt will retract automatically when released.
  6. For each passenger's seat belt, check the seat belt retractor locking mechanism ALR (automatic locking retractor). This function is for securing child seats. Pull the seat belt all the way out to engage the ALR. The seat belt should retract, but not extend. This is normal. To disengage the ALR, release the seat belt and allow it to fully retract, then pull the seat belt out part-way. The seat belt should retract and extend normally.
  7. Replace the seat belt with a new assembly if there is any abnormality. Do not disassemble any part of the seat belt for any reason.

Scheme 47

Scheme 47: Third Row Child Seat Tether Anchor Replacement
Scheme 47: Third Row Child Seat Tether Anchor Replacement
  1. Remove the rear trim panel (see «TRIM REMOVAL/INSTALLATION - CARGO AREA»(ref-174030-S27688880142005042500000) ).
  2. Remove the screws (A), and remove the third row child seat tether anchors (B).
  3. Install the anchor in the reverse order of removal, and apply liquid thread lock to the threads of the child seat tether anchor screws.
