Interior Lights Systems: Overview Honda Pilot I

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. Turn the light switch OFF.
2. Carefully pry off the lens (A) with a small screwdriver.
3. Remove the four mounting screws.
4. Disconnect the 3P connector (B) from the housing (C)
5. Check for continuity between the terminals: There should be continuity between the No. 1 and No. 3 terminals with the switch ON. There should be continuity between the No. 1 and No. 2 terminals with the switch OFF.
6. If the continuity is not as specified, check the bulb(s). If the bulb(s) are OK, replace the light. MAP LIGHT: 6.2 W

Scheme 6

Scheme 7

1. Turn the interior light switch OFF.
2. If only replace the bulb (A), carefully pry off the lens (B) with a small screwdriver.
3. Remove the grab handle (see step 5 in «HEADLINER REMOVAL/INSTALLATION»(ref-174030-S37597567812005042500000) ).
4. Disconnect the 3P connector (A) from the light (B)
5. Carefully remove the heat shield from the light. Replace the bulb if necessary.
6. Check for continuity between the terminals: There should be continuity between the NO. 1 and No. 3 terminals with the switch ON. There should be continuity between the No. 1 and No. 2 terminals with the switch OFF.
7. If the continuity is not as specified, replace the light. MAP LIGHT: 12.4 W

Scheme 8

1. Open the tailgate.
2. Carefully pry off the lens (A) with a small screwdriver.
3. Remove the two mounting screws.
4. Disconnect the 3P connector (B) from the housing (C).
5. Check for continuity between the terminals. There should be continuity between the No. 1 and No. 3 terminals with the switch ON.
6. If the continuity is not as specified, check the bulb(s). If the bulb(s) are OK, replace the light. TAILGATE LIGHT: 5 W x 2

Scheme 9

1. Open the tailgate.
2. Remove the tailgate trim panel (see «TRIM REMOVAL/INSTALLATION - TAILGATE AREA»(ref-174030-S19310355362005042500000) ).
3. Disconnect the 2P connector from the tailgate latch.
4. Check for continuity between the No. 1 and No. 2 terminals: With the tailgate open, there should be continuity. With the tailgate closed, there should be no continuity.
5. If the continuity is not as specified, replace the tailgate latch switch.

Scheme 10

1. Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(ref-174030-S37812666562005042500000) ).
2. Disconnect the 2P connector (A) from the glove box light (B).
3. Check for continuity between the No. 1 and No. 2 terminals: With the button (C) pressed, there should be no continuity. With the button (C) released, there should be continuity.
4. If the continuity is not as specified, check the bulb. If the bulb is OK, replace the light. GLOVE BOX LIGHT: 3.4 W

Scheme 11

1. Remove the center lower cover (see «CENTER CONSOLE REMOVAL/INSTALLATION»(ref-174030-S31369994412005042500000) )
2. Disconnect the 2P connector (A) from the front console light (B).
3. Turn the bulb socket (C) 45° counterclockwise to remove it from the light. FRONT CONSOLE LIGHT: 1.4 W

Scheme 12

1. Open the sunvisor.
2. Remove the sunvisor (see page «HEADLINER REMOVAL/INSTALLATION»(ref-174030-S37597567812005042500000) ).
3. Disconnect the 2P connector (A) from the vanity mirror light.
4. Check for continuity between the No. 1 and No. 2 terminals: With the vanity mirror cover (B) opened, there should be continuity. With the vanity mirror cover closed, there should be no continuity.
5. If the continuity is not as specified, check the bulbs. If the bulbs are OK, replace the sunvisor. VANITY MIRROR LIGHT: 1.1 W

Scheme 13

1. Carefully pry off the lens (A) with a small screwdriver.
2. Remove the bulb (B) from the socket. COURTESY LIGHT: 3.8 W

Scheme 14

Scheme 15

1. Remove the switch panel (see «DRIVER'S SWITCH PANEL REMOVAL/INSTALLATION»(ref-174030-S01226226162005042500000) ).
2. Disconnect the 6P connector (A) from the interior lights switch (B).
3. Pull the interior lights switch out of the switch panel.
4. Check for continuity between the terminals in each switch position according to the table.
5. If the continuity is not as specified, replace the bulb (C) or the switch.

Scheme 16

1. Disconnect the noise condenser connector.
2. Use a commercially available condenser tester. Connect the condenser tester probes and measure the condenser capacity. Capacity: 0.47 microfarads
3. If not within the specifications, replace the noise condenser.

Scheme 17

Scheme 18
