1980-87 (Ported EGR Valve)
Check vacuum hoses for correct routing. Disconnect vacuum hose from EGR valve. Run engine to operating temperature. Apply 6 in. Hg to EGR valve. Ensure engine runs roughly or dies. Reconnect vacuum hose.
Vacuum Control
EGR valve is controlled by a combination of either coolant temperature switch, speed sensor, vacuum solenoid, vacuum valves and computer. If further testing is required, see appropriate IMPORTED CARS, LIGHT TRUCKS & VANS ENGINE PERFORMANCE SERVICE & REPAIR manual.
- Disconnect vacuum hose from EGR valve and connect vacuum gauge to hose. Push a voltmeter positive probe into the terminal at the control box connector (Blue/Yellow on Accord). Connect the negative probe to ground. Jack up the front of the vehicle.
- Support with safety stands, block rear wheels, and set hand brake. Start and warm up engine (cooling fan must come on). On Accord, remove control box from firewall and remove cover attaching screws. On all models, vacuum and voltage should be as follows: EGR SYSTEM TEST Condition EGR Valve Vacuum Specified Voltage Idle None None 4500 RPM Yes None 4500 RPM (Blocked EGR Bleed) Less Than 2 in. Hg None Hard Acceleration over 15 MPH (1) Yes None Deceleration over 15 MPH (1) None Yes (1) In second gear or "2".
- If voltage is available in the first 3 conditions, check thermosensor for continuity. There should be no continuity. If it has continuity, replace and retest. If there is no continuity, remove the control switch, disconnect the lower hose from control switch and connect a vacuum gauge to the hose. There should be no vacuum at idle.
- If there is no vacuum, replace the control switch and retest. If there is vacuum, check for voltage at the Yellow/Black wire to the control switch solenoid valve (ignition ON). If there is no voltage, replace the control switch solenoid valve and retest. If there is voltage, replace the speed sensor and retest.
- If there is no voltage available but there is vacuum for the first condition or vacuum is is greater than 2 in.Hg (50 mmHg) for the third condition, replace the EGR control valve and check vacuum hose routing. If voltage is available for the fourth condition replace the control switch. If there is no voltage available for the fifth condition, check control switch.
- With speed sensor jumpered and engine at idle, remove vacuum line at control switch and check for vacuum. If vacuum is available, reconnect line and check for voltage at Blue/Yellow wire at EGR solenoid valve A. There should be no voltage. If there is no voltage, replace control switch and retest.
- If there is no vacuum available and no voltage for the second and fourth conditions, check for ported vacuum at 4500 RPM at EGR control solenoid valve A inlet. If vacuum is not available, check vacuum line routing and carburetor port. Clean and retest.
- If vacuum is available, replace EGR control solenoid valve A. If vacuum and voltage are available for the fifth condition, replace EGR control solenoid valve A.
Exhaust Gas Recirculation System (Accord). Scheme 3
Exhuaust Gas Recirculation System (Civic). Scheme 4
Exhaust Gas Recirculation System (Prelude). Scheme 5
1988-96 (Ported EGR Valve)
- Warm engine to normal operating temperature. Operate engine at idle. Attach a vacuum gauge to EGR vacuum hose. Locate EGR vacuum solenoid.
- Using a jumper wire, ground signal wire from ECM to EGR vacuum solenoid. Vacuum should be present at EGR vacuum hose. On some models, engine speed may have to be increased 3000-4000 RPM.
- Connect a hand-held vacuum pump to EGR valve. Start engine. Apply vacuum to EGR valve. If engine runs rough or stalls, and gauge holds vacuum, EGR valve is functioning properly.
