Rear Differential: Removal & Installation Honda Pilot I

VTM-4 Control Unit Replacement

Note. The VTM-4 control unit must be initialized (see Initialization of the VTM-4 Control Unit ) after replacement, otherwise the 4WD system will not function.

Scheme 74

1. Remove the jack cover and jack (see «TRIM REMOVAL/INSTALLATION - REAR SIDE PILLAR»(ref-174030-S33722278092005042500000) ).
2. Loosen the three nuts (A).
3. Disconnect the VTM-4 control unit connectors (B).
4. Remove the VTM-4 control unit (C).
5. Install the VTM-4 control unit in the reverse order of removal.

Scheme 75

1. Remove the left side instrument panel lid (see «DRIVER'S PANEL REMOVAL/INSTALLATION»(ref-174030-S09392897132005042500000) ).
2. Remove the bolt (A) and VTM-4 relay (B).
3. Install the VTM-4 relay in the reverse order of removal.

Scheme 76

Scheme 77
