Power Windows: Other Honda Passport II

AMIGO & RODEO

COMPONENT LOCATIONS (AMIGO & RODEO)

TROOPER

COMPONENT LOCATIONS (TROOPER)

VEHICROSS

COMPONENT LOCATIONS (VEHICROSS)

Check for faulty circuit breaker or power window relay. Check for faulty master power window and lock switch. Inspect power window circuit for an open or short. Ensure ground connections are clean and tight.

Check for blown ELEC IGN fuse. Check for faulty circuit breaker or power window relay. Check for faulty master power window and lock switch. Inspect power window circuit for an open or short. Ensure ground connections are clean and tight.

Amigo

1. Check BACKUP/TURN (15-amp) fuse, located in dash fuse box. If fuse is blown, replace fuse and recheck system operation. If fuse is okay, go to next step.
2. Use DVOM to check continuity of POWER WINDOW (30-amp) circuit breaker, located in dash fuse box. If circuit breaker is okay, go to next step. If circuit breaker is bad, replace breaker and recheck system operation.
3. Ensure ground connection B-8 is secure. See «COMPONENT LOCATIONS»(ref-4258-S17429654182000061700000) . Repair if necessary. If ground connection is okay, go to next step.
4. Remove power window relay from dash fuse box. Use DVOM and measure voltage between ground and power window relay cavity terminal No. 2 (Green/White wire). If battery voltage is indicated, go to step 6 . If battery voltage is not indicated, go to next step.
5. Repair open in Green/White wire between power window relay and power window circuit breaker. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, recheck system operation.
6. Turn ignition switch to ON position. Use DVOM and measure voltage between ground and power window relay cavity terminal No. 3 (White/Green wire). If battery voltage is indicated, go to step 8 . If battery voltage is not indicated, go to next step.
7. Repair open in White/Green wire between power window relay and ELEC IG (15-amp) fuse. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, recheck system operation.
8. Use DVOM and check for continuity between power window relay cavity terminal No. 4 and ground B-8 (Black wire). If continuity is indicated, replace power window relay. If continuity is not indicated, go to next step.
9. Repair open in Black wire between power window relay and ground B-8. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, recheck system operation.

Rodeo

1. Check ELEC IG (15-amp) fuse, located in dash fuse box. If fuse is blown, replace fuse and recheck system operation. If fuse is okay, go to next step.
2. Use DVOM to check continuity of POWER WINDOW (30-amp) circuit breaker, located in dash fuse box. If circuit breaker is okay, go to next step. If circuit breaker is bad, replace breaker and recheck system operation.
3. Ensure ground connection B-8 is secure. See «COMPONENT LOCATIONS»(ref-4258-S17429654182000061700000) . Repair if necessary. If ground connection is okay, go to next step.
4. Remove power window relay from dash fuse box. Check power window relay for proper operation. Replace if necessary. If relay is okay, go to next step.
5. Measure voltage between ground and power window relay cavity terminal No. 2 (Green/White wire). See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . If battery voltage is indicated, go to next step. If battery voltage is not indicated, repair open in Green/White wire between power window relay and power window circuit breaker. After repairs, recheck system operation.
6. Turn ignition switch to ON position. Measure voltage between ground and power window relay cavity terminal No. 4 (White/Blue wire). If battery voltage is indicated, go to next step. If battery voltage is not indicated, repair open in White/Blue wire between power window relay and ELEC IG (15-amp) fuse. After repairs, recheck system operation.
7. Measure voltage between ground and door lock and side window switch connector terminal No. 4 (Green/Red wire). If battery voltage is indicated, go to next step. If battery voltage is not indicated, repair open in Green/Red wire between door lock and side window switch and power window relay. After repairs, recheck system operation.
8. Use DVOM to check for continuity between power window relay cavity terminal No. 4 and ground, and driver's door lock and side window switch connector terminal No. 7 and ground (Black wire). See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . If continuity is indicated, go to next step. If continuity is not indicated, repair open in Black wire.
9. Replace driver's door lock and side window switch. See «POWER WINDOW SWITCH»(ref-4258-S30897920342000061700000) under REMOVAL & INSTALLATION. After replacement, recheck system operation.

1. Check ELEC IGN (15-amp) fuse, located in dash fuse box. If fuse is okay, go to next step. If fuse is blown, replace fuse and recheck system operation.
2. Use DVOM to check continuity of C/B-2 (P/W, P/S, S/R) circuit breaker, located in dash fuse box. If circuit breaker is okay, go to next step. If circuit breaker is bad, replace breaker and recheck system operation.
3. Ensure ground connection B-19 is secure. See «COMPONENT LOCATIONS»(ref-4258-S17429654182000061700000) . Repair if necessary. If ground connection is okay, go to next step.
4. Disconnect power window relay located in dash fuse box. Measure voltage between ground and power window relay cavity terminal No. 2 (Black/Blue wire). If battery voltage is indicated, go to step 6 . If battery voltage is not indicated, go to next step.
5. Repair open in Black/Blue wire between C/B-2 circuit breaker and power window relay (located in dash fuse box). See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, go to back to step 4 .
6. Turn ignition switch to ON position. Measure voltage between ground and power window relay cavity terminal No. 1 (Blue/White wire). If battery voltage is indicated, go to step 8 . If battery voltage is not indicated, go to next step.
7. Repair open in Blue/White wire between ELEC IGN fuse and power window relay (located in dash fuse box). See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, repeat step 6 .
8. Use DVOM to check for continuity between ground and power window relay cavity terminal No. 3 (Black wire). If continuity is indicated, replace power window relay. If continuity is not indicated, go to next step.
9. Repair open in Black wire between ground connection B-19 and power window relay (located in dash fuse box). See «COMPONENT LOCATIONS»(ref-4258-S17429654182000061700000) . After repairs, recheck system operation.

1. Remove driver's power window and lock switch and disconnect. Use DVOM to check for continuity between driver's side power window and lock switch connector terminal No. 7 and ground (Black wire). If continuity is indicated, go to step 3 . If continuity is not indicated, go to next step.
2. Repair poor connection at ground terminal B-8 or open in Black wire. See «COMPONENT LOCATIONS»(ref-4258-S17429654182000061700000) . After repairs, repeat step 1 .
3. Turn ignition switch to ON position. Measure voltage between ground and driver's power window and lock switch connector terminal No. 4 (Green/Red wire). If battery voltage is indicated, go to step 5 . If battery voltage is not indicated, go to next step.
4. Repair open in Green/Red wire between power window relay and driver's power window and lock switch. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . after repairs, repeat step 3 .
5. Momentarily connect a fused jumper between battery voltage and driver's power window and lock switch connector terminal No. 3 (Brown/Red wire). Connect another jumper wire between ground and driver's power window and lock switch connector terminal No. 5 (Brown/White wire). Reverse connections. If power motor operates in both directions, replace driver's power window and door lock switch. See «POWER WINDOW SWITCH»(ref-4258-S30897920342000061700000) under REMOVAL & INSTALLATION. If power window motor does not operate in both directions, go to next step.
6. Disconnect power window motor connector. Momentarily connect a fused jumper between battery voltage and driver's power window motor connector terminal No. 1. Connect another jumper wire between ground and driver's power window motor connector terminal No. 2. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . Reverse connections. If power motor operates in both directions, go to next step. If power window motor does not operate in both directions, replace driver's power window motor. See «POWER WINDOW MOTOR»(ref-4258-S24278374052000061700000) under REMOVAL & INSTALLATION.
7. Repair open in Brown/Red wire or Brown/White wire between driver's power window and lock switch and power window motor. After repairs, recheck system operation.

1. Remove power window and lock switch. DO NOT remove connector. Use DVOM to measure voltage between ground and power window and lock switch connector terminal No. 4 (Green/Red wire). See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . If battery voltage is indicated, go to next step. If battery voltage is not indicated, repair open in Green/Red wire between power window and lock switch and power window relay. After repairs, recheck system operation.
2. Check for continuity between driver's side power window and lock switch connector terminal No. 7 and ground (Black wire). If continuity is indicated, go to next step. If continuity is not indicated, repair poor connection at ground B-8 or open in Black wire. See «COMPONENT LOCATIONS»(ref-4258-S17429654182000061700000) . After repairs, recheck system operation.
3. Disconnect driver's power window and lock switch. Momentarily connect a fused jumper between driver's power window and lock switch connector terminal No. 3 (Brown/Red wire). Connect another jumper wire between rear power window and lock switch connector terminal No. 5 (Brown/White wire). If power window motor does not move to up position, check for open wires or poor connections at switch. If circuits are okay, replace driver's power window motor. See «POWER WINDOW MOTOR»(ref-4258-S24278374052000061700000) under REMOVAL & INSTALLATION. If power window motor moves to up position, go to next step.
4. Momentarily connect a fused jumper between driver's power window and lock switch connector terminal No. 5 (Brown/White wire). Connect another jumper wire between rear power window and lock switch connector terminal No. 3 (Brown/Red wire). If power window motor does not move to down position, check for open wires or poor connections at switch. If circuits are okay, replace driver's power window motor. See «POWER WINDOW MOTOR»(ref-4258-S24278374052000061700000) under REMOVAL & INSTALLATION. If power window motor moves to down position, replace driver's power window and lock switch. See «POWER WINDOW SWITCH»(ref-4258-S30897920342000061700000) under REMOVAL & INSTALLATION.

1. Ensure ground connection B-18 is secure. See «COMPONENT LOCATIONS»(ref-4258-S17429654182000061700000) . Repair if necessary. If ground connection is okay, go to next step.
2. Disconnect driver's power window and lock switch. Use DVOM to check for continuity between ground and driver's power window and lock switch connector D-5 terminal No. 1 (Black wire). If continuity is indicated, go to step 4 . If continuity is not indicated, go to next step.
3. Repair open in Black wire between driver's power window and lock switch and ground. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, recheck system operation.
4. Turn ignition switch to ON position. Measure voltage between ground and driver's power window and lock switch connector D-5 terminal No. 7 (Blue/Black wire). If battery voltage is indicated, go to step 6 . If battery voltage is not indicated, go to next step.
5. Repair open in Blue/Black wire between power window relay and driver's power window and lock switch. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, recheck system operation.
6. Momentarily connect a fused jumper wire between battery voltage and driver's power window and lock switch connector D-5 terminal No. 5 (Blue/White wire). Connect another jumper wire between ground and driver's power window and lock switch connector D-5 terminal No. 6 (Blue wire). Reverse connections. If power window motor operates in both directions, replace driver's power window and lock switch. See «POWER WINDOW SWITCH»(ref-4258-S30897920342000061700000) under REMOVAL & INSTALLATION. If power window motor does not operate in both directions, go to next step.
7. Disconnect driver's power window motor connector. Momentarily connect a fused jumper between battery voltage and driver's power window motor connector Blue wire. Connect jumper wire between ground and driver's power window motor connector White wire. Reverse connections. If power window motor operates in both directions, go to next step. If power window motor does not operate in both directions, replace power window motor. See «POWER WINDOW MOTOR»(ref-4258-S24278374052000061700000) under REMOVAL & INSTALLATION.
8. Repair open in Blue/White wire or Blue wire between driver's power window and lock switch and power window motor. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, recheck system operation.

AUTO-DOWN FEATURE INOPERATIVE

Replace driver's power window and lock switch. See POWER WINDOW SWITCH under REMOVAL & INSTALLATION. After replacement, recheck system operation.

1. Disconnect driver's power window and door lock switch connector D-30. Disconnect passenger's power window and door lock switch connector. Use DVOM to check for continuity between driver's power window and door lock switch connector D-30 terminal No. 5 and passenger's power window and door lock switch connector terminal No. 2 (Red/Yellow wire). If continuity is indicated, replace driver's power window and door lock switch. See «POWER WINDOW SWITCH»(ref-4258-S30897920342000061700000) under REMOVAL & INSTALLATION. If continuity is not indicated, go to next step.
2. Repair open in Red/Yellow wire between driver's and passenger's power window and door lock switches. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, recheck system operation.

1. Remove and disconnect passenger's power window and lock switch. Use DVOM to check for continuity between passenger's side power window and lock switch connector terminal No. 3 and ground (Black wire). See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . If continuity is indicated, go to step 3 . If continuity is not indicated, go to next step.
2. Repair poor connection at ground B-8 or open in Black wire. See «COMPONENT LOCATIONS»(ref-4258-S17429654182000061700000) . After repairs, repeat step 1 .
3. Turn ignition switch to ON position. Measure voltage between ground and passenger's power window and lock switch connector terminal No. 2 (Green/Red wire). If battery voltage is indicated, go to step 5 . If battery voltage is not indicated, go to next step.
4. Repair open in Green/Red wire between power window relay and passenger's power window and lock switch. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, repeat step 3 .
5. Momentarily connect a fused jumper between battery voltage and passenger's power window and lock switch connector terminal No. 1 (Brown/Red wire). Connect another jumper wire between ground and passenger's power window and lock switch connector terminal No. 4 (Brown/White wire). Reverse connections. If power motor operates in both directions, replace passenger's power window and door lock switch. See «POWER WINDOW SWITCH»(ref-4258-S30897920342000061700000) under REMOVAL & INSTALLATION. If power window motor does not operate in both directions, go to next step.
6. Disconnect power window motor connector. Momentarily connect a fused jumper between battery voltage and passenger's power window motor connector terminal No. 1. Connect another jumper wire between ground and passenger's power window motor connector terminal No. 2. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . Reverse connections. If power motor operates in both directions, go to next step. If power window motor does not operate in both directions, replace passenger's power window motor. See «POWER WINDOW MOTOR»(ref-4258-S24278374052000061700000) under REMOVAL & INSTALLATION.
7. Repair open in Brown/Red or Brown/White wires between passenger's power window and lock switch and power window motor. After repairs, recheck system operation.

1. Remove passenger's power window and lock switch. DO NOT remove connector. Use DVOM to measure voltage between ground and power window and lock switch connector terminal No. 2 (Green/Red wire). See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . If battery voltage is indicated, go to next step. If battery voltage is not indicated, repair open in Green/Red wire between power window and lock switch and power window relay. After repairs, recheck system operation.
2. Check for continuity between passenger's side power window and lock switch connector terminal No. 3 and ground (Black wire). If continuity is indicated, go to next step. If continuity is not indicated, repair poor connection at ground B-8 or open in Black wire. See «COMPONENT LOCATIONS»(ref-4258-S17429654182000061700000) . After repairs, recheck system operation.
3. Disconnect passenger's power window and lock switch. Momentarily connect fused jumper between suspect rear power window and lock switch connector terminal No. 1 (Brown/Red wire). Connect jumper wire between rear power window and lock switch connector terminal No. 4 (Brown/White wire). If power window motor does not move to up position, check for open wires or poor connections at switch. If circuits are okay, replace passenger's power window motor. See «POWER WINDOW MOTOR»(ref-4258-S24278374052000061700000) under REMOVAL & INSTALLATION. If power window motor moves to up position, go to next step.
4. Momentarily connect a fused jumper between passenger's power window and lock switch connector terminal No. 4 (Brown/White wire). Connect another jumper wire between rear power window and lock switch connector terminal No. 1 (Brown/Red wire). If power window motor does not move to down position, check for open wires or poor connections at switch. If circuits are okay, replace passenger's power window motor. See «POWER WINDOW MOTOR»(ref-4258-S24278374052000061700000) under REMOVAL & INSTALLATION. If power window motor moves to down position, replace passenger's power window and lock switch. See «POWER WINDOW SWITCH»(ref-4258-S30897920342000061700000) under REMOVAL & INSTALLATION.

1. Ensure ground connection B-2 is secure. See «COMPONENT LOCATIONS»(ref-4258-S17429654182000061700000) . Repair if necessary. If ground connection is okay, go to next step.
2. Disconnect passenger's front power window and lock switch. Use DVOM to check for continuity between ground and passenger's front power window and lock switch connector terminal No. 7 (Black wire). If continuity is indicated, go to step 4 . If continuity is not indicated, go to next step.
3. Repair open in Black wire between ground connection B-2 and passenger's front power window and lock switch. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, repeat step 2 .
4. Turn ignition switch to ON position. Measure voltage between ground and passenger's front power window and lock switch connector terminal No. 5 (Blue/Black wire). If battery voltage is indicated, go to step 6 . If battery voltage is not indicated, go to next step.
5. Repair open in Blue/Black wire between power window relay and passenger's front power window and lock switch. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, repeat step 4 .
6. Momentarily connect a fused jumper between battery voltage and passenger's power window and lock switch connector terminal No. 1 (Brown/Yellow wire). Connect another jumper wire between ground and passenger's power window and lock switch connector terminal No. 10 (Blue/Yellow wire). Reverse connections. If power window motor operates in both directions, replace power window and lock switch. See «POWER WINDOW SWITCH»(ref-4258-S30897920342000061700000) under REMOVAL & INSTALLATION. If power window motor does not operate in both directions, go to next step.
7. Disconnect passenger's power window motor connector. Momentarily connect a fused jumper between battery voltage and passenger's power window motor Blue wire connector. Connect another jumper wire between ground and passenger's power window motor White wire connector. Reverse connections. If power window motor operates in both directions, go to next step. If power window motor does not operate in both directions, replace power window motor. See «POWER WINDOW MOTOR»(ref-4258-S24278374052000061700000) under REMOVAL & INSTALLATION.
8. Repair open in Blue/Yellow wire or Brown/Yellow wire between passenger's power window and lock switch and power window motor. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, recheck system operation.

1. Ensure driver's power window operates normally. If driver's power window is okay, go to next step. If driver's power window does not function properly, go to «DRIVER-SIDE WINDOW INOPERATIVE»(ref-4258-S16389217412000061700000) .
2. Disconnect suspect rear power window and lock switch. Momentarily connect fused jumper between suspect rear power window and lock switch connector terminal No. 5 (Brown/Red wire). Connect a jumper wire between rear power window and lock switch connector terminal No. 6 (Brown/White wire). If power window motor does not move to up position, check for open wires or poor connections at switch. If circuits are okay, replace suspect rear power window motor. See «POWER WINDOW MOTOR»(ref-4258-S24278374052000061700000) under REMOVAL & INSTALLATION. If power window motor moves to up position, go to next step.
3. Momentarily connect a fused jumper between suspect rear power window and lock switch connector terminal No. 6 (Brown/White wire). Connect another jumper wire between rear power window and lock switch connector terminal No. 5 (Brown/Red wire). See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . If power window motor does not move to down position, check for open wires or poor connections at switch. If circuits are okay, replace suspect rear power window motor. See «POWER WINDOW MOTOR»(ref-4258-S24278374052000061700000) under REMOVAL & INSTALLATION. If power window motor moves to down position, replace suspect power window and lock switch. See «POWER WINDOW SWITCH»(ref-4258-S30897920342000061700000) under REMOVAL & INSTALLATION.

1. Disconnect suspect rear power window and lock switch. Turn ignition switch to ON position. Use DVOM to measure voltage between ground and suspect rear power window and lock switch connector terminal No. 4 (Blue/Black wire). If battery voltage is indicated at suspect switch connector, go to step 3 . If battery voltage is not indicated at suspect switch connector, go to next step.
2. Repair open in Blue/Black wire between suspect switch and power window relay. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, repeat step 1 .
3. Check for continuity between ground connection B-26 and suspect rear power window and lock switch connector terminal No. 3 (Black wire). See «COMPONENT LOCATIONS»(ref-4258-S17429654182000061700000) . If continuity is indicated, go to step 5 . If continuity is not indicated, go to next step.
4. Repair open in Black wire between ground connection B-26 and suspect window rear power window and lock switch. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, repeat step 3 .
5. Momentarily connect a fused jumper between battery voltage and suspect rear power window and lock switch connector terminal No. 5 (Blue/Red wire). Connect another jumper wire between ground and suspect rear power window and lock switch connector terminal No. 6 (Brown/Red wire). Reverse connections. If power window motor operates in both directions, replace suspect rear power window and lock switch. See «POWER WINDOW SWITCH»(ref-4258-S30897920342000061700000) under REMOVAL & INSTALLATION. If power window motor does not operate in both directions, go to next step.
6. Disconnect suspect rear power window motor connector. Momentarily connect a fused jumper between battery voltage and rear power window motor connector Blue wire. Connect another jumper wire between ground and rear power window motor connector White wire. Reverse connections. If power window motor operates in both directions, go to next step. If power window motor does not operate in both directions, replace power window motor. See «POWER WINDOW MOTOR»(ref-4258-S24278374052000061700000) under REMOVAL & INSTALLATION.
7. Repair open in Blue/Red wire or Brown/Red wire between suspect rear power window and lock switch and rear power window motor. See «WIRING DIAGRAMS»(ref-4258-S08748591422000061700000) . After repairs, recheck system operation.

POWER WINDOW LOCK OUT SWITCH INOPERATIVE

If power window lock out switch fails to lock out passenger and rear windows, replace driver's power window and lock switch. See POWER WINDOW SWITCH under REMOVAL & INSTALLATION.

POWER WINDOW MOTOR

Front Doors (Amigo & Rodeo)

1. Disconnect negative battery cable. Remove power window switch. Pull out on inside door handle and remove screw. Remove speaker grille and speaker. Remove door mirror cover from front top of door panel. Remove door pull handle.
2. Disengage clips and remove door panel. Remove waterproof shield. Roll glass downward to access screws attaching glass to regulator. Remove screws attaching top and bottom of regulator to door. Remove screws attaching power window motor to door.
3. Disconnect electrical connector to motor and remove regulator assembly. Remove motor from regulator noting location of cables. To install, reverse removal procedures.

Rear Doors (Amigo & Rodeo)

1. Disconnect negative battery cable. Remove power window and lock switch. See «POWER WINDOW SWITCH»(ref-4258-S30897920342000061700000) . Remove rear lower corner garnish from door. Disengage clips attaching door panel to door, disconnect electrical connectors and remove door panel.
2. Remove bracket and waterproof sheet from door. Remove screw from top of door and inside of door and remove stationary glass. Roll glass downward to access screws attaching glass to regulator. remove glass from door. Remove screws attaching top and bottom of regulator to door. Remove screws attaching power window motor to door. Disconnect electrical connector to motor and remove regulator assembly.
3. Remove motor from regulator noting location of cables. To install, reverse removal procedures.

Front & Rear Doors (Trooper)

Remove door trim panel and waterproof shield. Roll glass down until glass retaining bolts can be accessed and removed. Disconnect power window motor. Remove window regulator screws and remove window regulator. Remove regulator assembly from access hole in lower portion of door. Remove power window motor retaining screws and remove motor from window regulator. To install, reverse removal procedure.

Front & Rear Doors (VehiCROSS)

1. Disconnect negative battery cable. Remove grip cover and disconnect switch connector. Remove 2 screws under grip cover. Remove door handle screw, then disconnect inside handle link. Remove screw cover, screw and tweeter.
2. Gently pull door panel away from door to release 9 door panel clips, then lift up to remove panel. Remove plastic sheet from door. Remove front speaker and speaker box, mirror assembly, rear glass run channel and outer waste seal.
3. Remove 2 glass retaining bolts. Tilt window forward, then remove from door. Remove glass run and inside handle link. Disconnect regulator motor electrical connector. Remove 4 regulator bolts and 3 window motor bolts. Remove window motor and regulator assembly. To install, reverse removal procedures.

Scheme 1

Disconnect negative battery cable. Pry out power window switch from door panel using a flat-blade screwdriver. Disconnect power window switch connectors and remove switch. To install, reverse removal procedure.

Rear Doors (Rodeo)

Disconnect negative battery cable. Remove screw attaching read door pull handle to door. Disconnect power window switch connectors and remove switch. To install, reverse removal procedure.

Disconnect negative battery cable. Pry out power window switch from door panel using a flat-blade screwdriver. Disconnect power window switch connectors and remove switch. To install, reverse removal procedure.

Disconnect negative battery cable. Pull out grip cover by depressing spring clip at front of cover. Disconnect switch connector. Remove 4 retaining screws and remove switch. To install, reverse removal procedure.

Power Window System Wiring Diagram (Acura SLX). Scheme 2

Power Window System Wiring Diagram (Honda Passport). Scheme 3

Power Window System Wiring Diagram (Amigo & Rodeo). Scheme 4

Power Window System Wiring Diagram (Hombre). Scheme 5

Power Window System Wiring Diagram (Trooper). Scheme 6

Power Window System Wiring Diagram (VehiCROSS). Scheme 7
