TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Amigo & Rodeo (2.2L Engine) |
| Long Bolt | 26 (35) |
| Short Bolt | 15 (20) |
| Pulley Nut | 30 (40) |
| Amigo, Rodeo (3.2L Engine), Trooper & VehiCROSS |
| Long Bolt | 30 (41) |
| Short Bolt | 15 (21) |
| Pulley Nut | 82 (111) |
Charging System Wiring Diagram (Amigo & Rodeo - 2.2L Engine). Scheme 1
Scheme 1: Charging System Wiring Diagram (Amigo & Rodeo - 2.2L Engine)
Charging System Wiring Diagram (Amigo, Rodeo & Passport - 3.2L Engine). Scheme 2
Scheme 2: Charging System Wiring Diagram (Amigo, Rodeo & Passport - 3.2L Engine)
Charging System Wiring Diagram (Trooper). Scheme 3
Scheme 3: Charging System Wiring Diagram (Trooper)
Charging System Wiring Diagram (VehiCROSS). Scheme 4
Scheme 4: Charging System Wiring Diagram (VehiCROSS)
