Starter - 3.2L: Specifications Honda Passport I

Starter 4 illustrations

STARTER SPECIFICATIONS

ApplicationSpecification
Carbon Brush
New Length.63" (14 mm)
Minimum Length.44" (11.0 mm)
Commutator
Diameter1.26-1.30" (32-33 mm)
Runout.004" (0.1 mm)
Armature Core Runout.004" (0.1 mm)
Bench Testing (No Load)
Minimum Volts11.0
Maximum Amps90
Minimum RPM2700

STARTER SPECIFICATIONS

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Exhaust Pipe Front Nuts49 (67)
Exhaust Pipe Front Bolts & Nuts20 (27)
Starter-To-Block Bolt30 (40)

TORQUE SPECIFICATIONS

Starting System Wiring Diagram (A/T - Early Production). Scheme 9

Scheme 9: Starting System Wiring Diagram (A/T - Early Production)
Scheme 9: Starting System Wiring Diagram (A/T - Early Production)

Starting System Wiring Diagram (A/T - Late Production). Scheme 10

Scheme 10: Starting System Wiring Diagram (A/T - Late Production)
Scheme 10: Starting System Wiring Diagram (A/T - Late Production)

Starting System Wiring Diagram (M/T - Early Production). Scheme 11

Scheme 11: Starting System Wiring Diagram (M/T - Early Production)
Scheme 11: Starting System Wiring Diagram (M/T - Early Production)

Starting System Wiring Diagram (M/T - Late Production). Scheme 12

Scheme 12: Starting System Wiring Diagram (M/T - Late Production)
Scheme 12: Starting System Wiring Diagram (M/T - Late Production)
