Driver Position Memory System (Dpms): Other Honda Odyssey IV

Memorizing a Seat and a Mirrors ('08-10 Touring models) Position

Move the seat and the mirrors to the desired position. Turn the ignition switch ON (II).

Press and hold the MEMO button on the driver's position memory switch. A single beep will be heard and both of the green LEDS will begin to flash. Press No. 1 or No. 2 to match the remote that is to be used. There will be two more beeps confirming that the seat and the mirrors ('08-10 Touring models) positions have been memorized. The LED will remain lit, unless the seat and the mirrors ('08-10 Touring models) are moved from the memorized position.

Memorized Position Recall with the Remotes

Make sure that the remotes are LINKED. Press and hold the LOCK and UNLOCK button at the same time. The red LED on the remote will flash ONE time when the remote has been LINKED and will flash TWO times when the remote has been UNLINKED. After the seat and the mirrors ('08-10 Touring models) positions have been memorized, the seat and the mirrors ('08-10 Touring models) will move to the position when the appropriate remote UNLOCK is pressed and the driver's door is opened. When the seat and mirrors ('08-10 Touring models) get to the memorized position, the green LED corresponding with that remote will stay lit until the position is changed or the key is turned OFF.

Scheme 21

Power Seat Position Sensors

Each motor has a sensor that detects motor rotation and sends a pulse to the power seat control unit when the motor rotates. The control unit stores the number of pulses in its memory, and the seat position is memorized.

Power Mirror Position Sensors ('08-10 Touring models)

By means of a tilt position sensor and swing position sensor, the power mirror control circuit in the power mirror control unit detects the voltage changes caused by the movements of the mirrors. These voltage changes are stored in memory, and the power mirror positions are memorized for each stored driving position.

Reverse Mirror Control ('08-10 Touring models)

When the vehicle is shifted to Reverse (shift lever in R position) with the power mirror selector switch in Left (or Right) position, the driver's (or passenger's) side mirror tilts down automatically to help the driver's view. The mirror will return to the previous position when the shift lever is shifted out of R position. The reverse mirror control is cancelled if the power mirror selector switch is in the center position.

Using the HDS (preferred method)

1. Go to B-CAN System Diagnostic Test Mode A to check for "Connected Units" and DTCs (see «TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A»(ref-294731-S03650631412008081300000) ).
2. If no DTCs are retrieved, go to B-CAN System Diagnosis Test Mode C (see «TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE C»(ref-294731-S23548620932008081300000) ) or Test Mode D (see «TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE D»(ref-294731-S37107684632008081300000) ).

Without the HDS (use only if HDS is not available)

The self-diagnostic function of the driving position memory system detects system problems. If a system problem is detected, the buzzer built into the power seat control unit sounds for 5 seconds. This information can be retrieved through the driving position memory switch indicators.

Scheme 22

1. Turn the ignition switch to LOCK (0), and move the seat to a non-memorized position.
2. Press and hold the MEMO button (A) and both position buttons (B) at the same time.
3. Turn the ignition switch to ON (II), and wait at least 1 second, then release the three buttons.
4. After 1 second, the position button indicators (C) will blink to show the DTC.

No System Problem

If there is no DTC stored, the indicators blink only once (3 seconds).

Scheme 23

System Problem

If a system problem occurs and a DTC is stored, the indicators will show the DTC. The first digit is indicated by the number of long (1 second) blinks, and the second digit is indicated by the number of short (0.26 second) blinks. There is a 3 second break between each DTC when there are multiple DTCs.

Scheme 24

Erasing the Driving Position from Memory

1. Press and hold all three driving position memory switch buttons.
2. Turn the ignition switch to ON (II).
3. Continue to hold all three driving position memory switches for more than 5 seconds, and release them in less than 10 seconds.
4. The buzzer will sound for 0.5 seconds to confirm that all driving position data is erased.

'08-10 Touring models

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. Clear the DTC with the HDS.
2. Turn the ignition switch to LOCK (0), and then back to ON (II).
3. Operate the left power mirror in each direction with the power mirror switch.
4. Check for DTCs with the HDS. Is DTC B1830 indicated? YES - Go to step 5. NO - Intermittent failure, the system is OK at this time.
5. Turn the ignition switch to LOCK (0).
6. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-294740-S24092112312008081300000) ).
7. Disconnect the power mirror control unit 24P connector.
8. Disconnect the left power mirror 13P connectors.
9. Check for continuity between the left power mirror connector (13P) No. 3 terminal and body ground. Is there continuity? YES - Repair short to ground in the ORN wire. NO - Go to step 10.
10. Connect the power mirror control unit connector (24P) No. 7 terminal to body ground with a jumper wire.
11. Check for continuity between the left power mirror connector (13P) No. 3 terminal and body ground. Is there continuity? YES - Go to step 12. NO - Repair open in the ORN wire.
12. Check for continuity between the left power mirror connector (13P) No. 5 and No. 10 terminals and body ground. Is there continuity? YES - Repair short to ground in the WHT and/or GRN wire. NO - Go to step 13.
13. Connect the power mirror control unit connector (24P) No. 4 and No. 5 terminals to body ground with a jumper wire.
14. Check for continuity between the left power mirror connector (13P) No. 5 and No. 10 terminals and body ground. Is there continuity? YES - Go to step 15. NO - Repair open in the WHT and/or GRN wire.
15. Check for continuity between the power mirror control unit connector (24P) No. 6 terminal and body ground. Is there continuity? YES - Repair short to ground in the BLU wire. NO - Go to step 16.
16. Connect the power mirror control unit connector (24P) No. 6 terminal to body ground with a jumper wire.
17. Check for continuity between the left power mirror connector (13P) No. 4 terminal and body ground. Is there continuity? YES - Go to step 18. NO - Repair open in the BLU wire.
18. Reconnect the power mirror control unit connector (24P).
19. Turn the ignition switch to ON (II).
20. Measure the voltage between the power mirror control unit connector (24P) No. 6 and No. 7 terminals. Is there about 5 V? YES - Faulty left power mirror position sensor; replace the power mirror actuator (see «POWER MIRROR ACTUATOR REPLACEMENT»(ref-294778-S02677075612008081300000) ). NO - Substitute a known-good power mirror control unit, and recheck. If DTC is gone, the original power mirror control unit is faulty; replace it.

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. Clear the DTC with the HDS.
2. Turn the ignition switch to LOCK (0), and then back to ON (II).
3. Operate the right power mirror in each direction with the power mirror switch.
4. Check for DTCs with the HDS. Is DTC B1832 indicated? YES - Go to step 5. NO - Intermittent failure, the system is OK at this time.
5. Turn the ignition switch to LOCK (0).
6. Remove the front passenger's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-294740-S24092112312008081300000) ).
7. Disconnect the power mirror control unit 24P connector.
8. Disconnect the right power mirror 13P connectors.
9. Check for continuity between the right power mirror connector (13P) No. 3 terminal and body ground. Is there continuity? YES - Repair short to ground in the ORN wire. NO - Go to step 10.
10. Connect the power mirror control unit connector (24P) No. 7 terminal to body ground with a jumper wire.
11. Check for continuity between the right power mirror connector (13P) No. 3 terminal and body ground. Is there continuity? YES - Go to step 12. NO - Repair open in the ORN wire.
12. Check for continuity between the right power mirror connector (13P) No. 5 and No. 10 terminals and body ground. Is there continuity? YES - Repair short to ground in the PUR and/or YEL wire. NO - Go to step 13.
13. Connect the power mirror control unit connector (24P) No. 19 and No. 20 terminals to body ground with a jumper wire.
14. Check for continuity between the right power mirror connector (13P) No. 5 and No. 10 terminals and body ground. Is there continuity? YES - Go to step 15. NO - Repair open in the PUR and/or YEL wire.
15. Check for continuity between the power mirror control unit connector (24P) No. 6 terminal and body ground. Is Mere continuity? YES - Repair short to ground in the BLU wire. NO - Go to step 16.
16. Connect the power mirror control unit connector (24P) No. 6 terminal to body ground with a jumper wire.
17. Check for continuity between the right power mirror connector (13P) No. 4 terminal and body ground. Is there continuity? YES - Go to step 18. NO - Repair open in the BLU wire.
18. Reconnect the power mirror control unit connector (24P).
19. Turn the ignition switch to ON (II).
20. Measure the voltage between the power mirror control unit connector (24P) No. 6 and No. 7 terminals. Is there about 5 V? YES - Faulty right power mirror position sensor; replace the power mirror actuator (see «POWER MIRROR ACTUATOR REPLACEMENT»(ref-294778-S02677075612008081300000) ). NO - Substitute a known-good power mirror control unit, and recheck. If DTC is gone, the original power mirror control unit is faulty; replace it.

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 45

Scheme 46

Scheme 47

Scheme 48

1. Clear the DTC with the HDS.
2. Turn the ignition switch to LOCK (0), and then back to ON (II).
3. Operate the power seat with the driving position memory switch.
4. Check for DTCs with the HDS. Is DTC B1843 indicated? YES - Go to step 5. NO - Intermittent failure, the system is OK at this time.
5. Turn the ignition switch to LOCK (0).
6. Disconnect the power seat control unit connectors and power mirror control unit connector (24P).
7. Check for continuity between power seat control unit connector A (40P) No. 39 terminal and power mirror control unit connector (24P) No. 13 terminal. Is there continuity? YES - Go to step 8. NO - Repair open in the wire between the power mirror control unit connector (24P) and power seat control unit connector A (40P).
8. Check for continuity between power seat control unit connector A (40P) No. 39 terminal and body ground. Is there continuity? YES - Repair short to ground in the wire. NO - Go to step 9.
9. Measure the voltage between the No. 24 terminal of the power mirror control unit connector (24P) and body ground. Is there battery voltage? YES - Go to step 10. NO - Check No. 7 (7.5 A) fuse in the driver's under-dash fuse/relay box. If the fuse is OK, repair open in the WHT/RED wire.
10. Check for continuity between the No. 22 terminal of the power mirror control unit connector (24P) and body ground. Is there continuity? YES - Repair open in the wire between the power mirror control unit and G601. If the wire is OK, repair G601. NO - Replace the power mirror control unit.
