Engine Lubrication System: Component Locations Honda Odyssey III

Special Tools Required

Oil filter wrench 07HAA-PJ70100

Scheme 9

Scheme 10

Scheme 11

1. Using the oil filter wrench, remove the oil filter.
2. Inspect the engine block seating surface to be sure all of the old filter gasket has been removed.
3. Inspect the threads (A) and rubber seal (B) on the new filter. Clean the seat on the engine block, then apply a light coat of new engine oil to the filter rubber seal. Use only filters with a built-in bypass system.
4. Install the oil filter by hand.
5. After the rubber seal seats, tighten the oil filter clockwise with the oil filter wrench. Tighten: 3/4 Turn Clockwise Tightening Torque: 12 N-m (1.2 kgf-m, 8.7 lbf-ft)
6. If four numbers or triangle(s) are printed around the outside of the filter, you can use the following procedure to tighten the filter ) . Spin the filter on until its seal lightly seats against the block, and note which number or mark is at the bottom. Tighten the filter by turning it clockwise three numbers or triangle(s) from the one you noted. For example, if triangle(s) is at the bottom when the seal is lightly seated, tighten the filter until the triangle comes around to the bottom .
7. After installation, fill the engine with oil up to the specified level, run the engine for more than 3 minutes, then check for oil leakage.
8. Reset the maintenance minder or multi-information display (see «RESETTING THE ENGINE OIL LIFE INDICATOR»(ref-245061-S24648068942006101100000) ).

Scheme 12

Scheme 13

1. Remove the oil filter (see «ENGINE OIL FILTER REPLACEMENT»(ref-220941-S04878099012006022100000) ).
2. Remove the oil filter feed pipe.
3. Install two 20 x 1.5 mm nuts (A) onto the new oil filter feed pipe, and hold one nut with a wrench, then tighten the other nut.
4. Tighten the oil filter feed pipe to 49 N-m (5.0 kgf-m, 36 lbf-ft), then remove the nuts from the oil filter feed pipe.
5. Install the oil filter (see «ENGINE OIL FILTER REPLACEMENT»(ref-220941-S04878099012006022100000) ).

Scheme 14

1. Remove the crankshaft from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-220940-S39187594552006022100000) ).
2. Remove the oil jet bolt (A), then remove and discard the oil jet (B).
3. Carefully install the new oil jet and tighten the oil jet bolt.
4. Install the crankshaft (see «CRANKSHAFT AND PISTON INSTALLATION»(ref-220940-S37568737972006022100000) ).
