Audio System: Other Honda Odyssey III

Audio Unit Connector for Inputs and Outputs

When replacing an audio unit connector, match the wires to the cavities listed in the table (Scheme 32), with navigation/with entertainment system & (Scheme 33), without navigation/with rear entertainment system.

Scheme 32

Scheme 33

When replacing an audio unit connector, match the wires to the cavities listed in the table (Scheme 34), without navigation/without rear entertainment system/1CD type & (Scheme 35), without navigation/without rear entertainment system/6CD type.

Scheme 34

Scheme 35

WITH REAR ENTERTAINMENT SYSTEM/WITH PREMIUM SOUND SYSTEM

WITH REAR ENTERTAINMENT SYSTEM/WITHOUT PREMIUM SOUND SYSTEM

Without rear entertainment system

WITHOUT REAR ENTERTAINMENT SYSTEM

With rear entertainment System

WITH REAR ENTERTAINMENT SYSTEM (1 OF 2)

WITH REAR ENTERTAINMENT SYSTEM (2 OF 2)

With navigation

WITH NAVIGATION

Without navigation/with XM radio

WITHOUT NAVIGATION/WITH XM RADIO

ANTENNA LEAD 3P CONNECTOR

ANTENNA LEAD 3P CONNECTOR

DIGITAL AUDIO 2P CONNECTOR

DIGITAL AUDIO 2P CONNECTOR

CD Changer Connector for Inputs and Outputs (With Navigation System)

When replacing a CD changer connector, match the wires to the cavities listed in the table (Scheme 36)

Scheme 36

Stereo Amplifier Connector for Inputs and Outputs (With Premium Sound System)

When replacing a stereo amplifier connector, match the wires to the cavities listed in the table (Scheme 37)

Scheme 37

XM Receiver Connector for Inputs and Outputs

When replacing a XM receiver connector, match the wires to the cavities listed in the table (Scheme 38)

Scheme 38

Error Codes

The audio system displays error codes when a problem is detected with the disc changer, the disc, the XM radio, or the anti-theft code.

ERROR CODES

Poor radio reception or interference

Note. Check the radio reception in an open area. Poor reception/interference can be caused by the following: The radio station is far away. Atmospheric conditions are unfavorable. Tall buildings, mountains, or high-voltage power lines are nearby.

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

1. Do the seek stop test (see SEEK STOP TEST ). Is the test vehicle within 10% of the known-good vehicle? YES - Multipath interference or weak station. Operation is normal. NO - Go to step 2.
2. Check if the radio reception/interference is the same in several locations. Is the reception/interference the same? YES - Go to step 3. NO - Multipath interference or weak station. Operation is normal.
3. Check the reception/interference while the engine is running. Is there noise (static or whine) only with the engine running? YES - Check the antenna and radio grounds. If OK, check the charging system and the ignition system. NO - Go to step 4.
4. Wrap aluminum foil (A) around the tip of a tester probe (B) (Scheme 39)
5. Touch one tester probe to the rear window antenna terminal (A), and move the other tester probe along the antenna wires to check that continuity exists. Repair it continuity does not exist.
6. Remove the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ). Check that antenna lead is properly connected. Is the antenna lead connected properly? YES - Go to step 7. NO - Reconnect the connector, and recheck the function.
7. Remove the dashboard center lower (see DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION ). Check that the antenna sub-lead connector is properly connected. Is the antenna sub-lead connected properly? YES - Go to step 8. NO - Reconnect the antenna sub-lead connector, and recheck the function.
8. Disconnect the antenna cable 3P connector from the antenna module (see ANTENNA MODULE REPLACEMENT ).
9. Measure the voltage between the antenna cable connector No. 3 terminal at the antenna module lead and body ground. Is there battery voltage? YES - Go to step 10. NO - Faulty antenna cable.
10. Remove the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ).
11. Check for continuity between the audio unit antenna cable 3P connector No. 3 terminal and the antenna module 3P connector No. 3 terminal. Is there continuity? YES - Go to step 12. NO - Repair the open in the wire between the audio unit and the antenna module.
12. Check for continuity between the audio unit antenna cable 3P connector No. 1 terminal and the antenna module 3P connector No. 1 terminal. Is there continuity? YES - Go to step 13. NO - Replace the antenna lead.
13. Check for continuity between the audio unit antenna cable 3P connector No. 1 terminal and body ground. Is there continuity? YES - Replace the antenna lead. NO - Go to step 14.
14. Check for continuity between the audio unit antenna cable 3P connector No. 2 terminal and the antenna module 3P connector No. 2 terminal. Is there continuity? YES - Replace the antenna lead. NO - Go to step 15.
15. Check for continuity between the audio unit antenna cable 3P connector No. 1 and No. 2 terminals. Is there continuity? YES - Replace the antenna lead. NO - Replace the antenna module, and recheck. If the reception is still poor, replace the audio unit.

Scheme 47

Scheme 48

1. With the ignition switch ON (II), push the power switch ON to see if audio unit turns ON. Does the audio unit display operate and sound properly? YES - Intermittent failure, the system is OK at this time. NO - Go to step 2.
2. Turn the ignition switch OFF.
3. Check the No. 5 (10 A) fuse and No. 32 (10 A) fuse in the driver's under-dash fuse/relay box. Are the fuses OK? YES - Go to step 4. NO - Replace the fuse, and recheck.
4. Remove the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ). Check that the audio unit is properly connected. Is the audio unit connected properly? YES - Go to step 5. NO - Reconnect the connector, and recheck the function.
5. Disconnect the audio unit connector A (20P).
6. Turn the ignition switch ON (II).
7. Measure the voltage between the No. 2 and No. 10 terminals of the audio unit connector A (20P) and body ground. Is there battery voltage? YES - Go to step 8. NO - Repair any open in the wire(s) between the No. 5 (10 A) fuse and No. 32 (10 A) in the driver's under-dash fuse/relay box and the audio unit.
8. Check for voltage between audio unit connector A (20P) No. 20 terminal and body ground. Is there less than 1.0 V? YES - Replace the audio unit. NO - Repair an open in the wire between the audio unit connector A (20P) No. 20 terminal and body ground (G503).

Scheme 49

1. With the ignition switch ON (II), push the power switch OFF or turn the ignition switch OFF to see if the audio unit turns OFF. Does the audio unit turn OFF? YES - Operation is normal. NO - Go to step 2.
2. Turn the ignition switch OFF.
3. Remove the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ). Disconnect the audio unit connector A (20P).
4. Measure the voltage between the No. 2 terminal of the audio unit connector A (20P) and body ground. Is there voltage? YES - Check for short to power on YEL/RED wire. NO - Replace the audio unit.

No sound is heard from speakers (display is normal)

Note. Set the fader and balance positions to the center. Before performing symptom troubleshooting, check for power switch will not turn ON troubleshooting (see POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) ).

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

1. Check that the volume button is not set to min level. Is the volume at MIN level? YES - Raise the volume level, and recheck the function. NO - With navigation: Go to step 2. Without navigation: Go to step 3 .
2. Check the NAVIGATION MUTE MODE. Is the NAVIGATION MUTE MODE set? YES - Cancel the NAVIGATION MUTE MODE by depressing the voice command button, and recheck the function. NO - Go to step 3.
3. Check to see if there is a specific speaker that has no sound. Is there a specific one? YES - Go to step 4. NO - Go to step 7 .
4. Turn the ignition switch OFF.
5. Check the speaker with sound for any damage. Is there any damage? YES - Substitute the speaker and recheck. NO - Go to step 6.
6. Remove the speaker(s) with no sound (see ACTIVE NOISE CONTROL UNIT REMOVAL/INSTALLATION ), and disconnect its connector.
7. Check the speaker 2P connector for a loose or poor connection. Reconnect the speaker 2P connector and recheck the symptom; does it still fail? YES - Go to step 8. NO - Operation is normal.
8. Measure the resistance between the No. 1 and No. 2 terminals of the speaker connector. Is there about 4 ohm? YES - With premium sound system: Go to step 13 . Without premium sound system: Go to step 9. NO - Faulty speaker(s).
9. Remove the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ). Disconnect the audio unit connector A (20P).
10. Check the resistance between the following terminals of audio unit connector A (20P). SPEAKER TERMINAL SPECIFICATION Speaker Terminal Wire color Driver's door speaker, Left tweeter A8 (+) GRN/BLK A18 (-) LT GRN Front passenger's door speaker, Right tweeter A7 (+) GRN/YEL A17 (-) GRY/RED Left rear speaker A6 (+) BLU/WHT A16 (-) BLU/BLK Right rear speaker A5 (+) PNK A15 (-) BLU/YEL Is there more than 4 ohm? YES - Go to step 11. NO - Repair an open in the wire between the audio unit and speaker.
11. Disconnect the speaker 2P connector.
12. Check for continuity between body ground and audio unit connector A (20P) terminals No. 5, 6, 7, 8, 15, 16, 17 and 18 individually. Is there continuity? YES - Repair short in the wire between the audio unit and speaker. NO - Substitute a known-good audio unit and recheck. If the symptom/indication goes away, replace the original audio unit.
13. Check the voltage between stereo amplifier connector A (20P) No. 10 terminal and body ground. Is there battery voltage? YES - Go to step 14. NO - Repair an open in the wire between fuse No. 5 (20 A) auxiliary under-hood fuse box and the stereo amplifier connector A (20P) No. 10 terminal.
14. Turn the ignition switch ON (II), and push the PWR button on the audio unit.
15. Check the voltage between stereo amplifier connector A (20P) No. 9 terminal and body ground. Is there battery voltage? YES - Go to step 16. NO - Repair an open in the wire between fuse No. 32 (10 A) driver's under-dash fuse/relay box and the stereo amplifier connector A (20P) No. 9 terminal.
16. Check the voltage between stereo amplifier connector B (14P) No. 7 terminal and body ground. Is there battery voltage? YES - Go to step 17. NO - Repair an open in the wire between the stereo amplifier connector B (14P) No. 7 terminal and the audio unit connector A (20P) No. 1 terminal.
17. Check for voltage between stereo amplifier connector A (20P) No. 20 terminal and connector B (14P) No. 14 terminal and body ground. Is there less than 1.0 V? YES - Go to step 18. NO - Repair an open in the wire between the stereo amplifier connector A (20P) No. 20 terminal or connector B (14P) No. 14 terminal and body ground (G504).
18. Disconnect the stereo amplifier connector A (20P) and B (14P).
19. Check for continuity between the stereo amplifier connector A (20P) terminals and body ground according to the table shown in STEREO AMPLIFIER CONNECTOR A (20P) TERMINALS AND BODY GROUND . STEREO AMPLIFIER CONNECTOR A (20P) TERMINALS AND BODY GROUND Speaker Terminal Wire color Driver's door speaker A3 (+) WHT A13 (-) GRN Left tweeter A4 (+) BLU/ORN A14 (-) GRY/BLU Front passenger's door speaker A2 (+) RED/BLU A12 (-) BRN Right tweeter A1 (+) BLK/RED A11 (-) PNK/BLK Left rear speaker A8 (+) PNK A18 (-) PUR Right rear speaker A7 (+) BLU/RED A17 (-) BLU/ORN Subwoofer A5 (+) GRN A15 (-) RED Is there continuity? YES - Repair short in the wire between the stereo amplifier and speaker. NO - Go to step 20.
20. Reconnect the 2P connector(s) to the speaker(s).
21. Disconnect the audio unit connector A (20P).
22. Check for continuity between the stereo amplifier connector B (14P) and body ground according to the table shown in STEREO AMPLIFIER CONNECTOR B (14P) AND BODY GROUND . STEREO AMPLIFIER CONNECTOR B (14P) AND BODY GROUND Amplifier connector Wire color B1 BLU B3 LT BLU B4 GRN B6 BRN B8 PNK B10 PUR B11 RED B13 YEL Is there continuity? YES - Repair a short in the wire between the stereo amplifier and the audio unit. NO - Go to step 23.
23. Check for continuity between the audio unit connector A and stereo amplifier connector B according to the table shown in AUDIO UNIT CONNECTOR A AND STEREO AMPLIFIER CONNECTOR B . AUDIO UNIT CONNECTOR A AND STEREO AMPLIFIER CONNECTOR B Audio unit connector Amplifier connector Wire color A5 B6 BRN A6 B3 LT BLU A7 B4 GRN A8 B1 BLU A15 B13 YEL A16 B10 PUR A17 B11 RED A18 B8 PNK Is there continuity? YES - Substitute a known-good audio unit and recheck. If the symptom/indication goes away, replace the original audio unit. If symptom is still present, substitute a known-good stereo amplifier and recheck. If the symptom/indication goes away, replace the original stereo amplifier. NO - Repair an open in the wire between the audio unit and stereo amplifier.

Poor or no sound with XM radio (Audio unit does display XM channels)

Note. Check the radio reception in an open area. Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines are nearby.

1. Turn the ignition switch to ACC (I).
2. Turn on the audio unit and select XM radio.
3. Check for an error message on the display. Are there any messages displayed? YES - Go to error code list (see ERROR CODES ). NO - With navigation: Go to step 7 . Without navigation: Go to step 4.
4. Disconnect audio unit connector D (14P) and XM receiver connector A (14P).
5. Check for continuity between XM receiver connector A (14P) and body ground according to the table shown in XM RECEIVER CONNECTOR A (14P) AND BODY GROUND . Then check for continuity between the same terminals listed in the table and audio unit connector D (14P) No. 4 terminal (the harness shield). XM RECEIVER CONNECTOR A (14P) AND BODY GROUND XM receiver connector Wire color A6 BLK A14 GRN A5 RED A13 WHT A2 BLU/RED Is there continuity? YES - Repair a short in the wire between the audio unit and the XM receiver, or replace the appropriate shielded harness. NO - Go to step 6.
6. Check for continuity between XM receiver connector A (14P) and audio unit connector D (14P) according to the table shown in XM RECEIVER CONNECTOR A (14P) AND AUDIO UNIT CONNECTOR D (14P) . XM RECEIVER CONNECTOR A (14P) AND AUDIO UNIT CONNECTOR D (14P) XM receiver connector Audio unit connector Wire color A6 D6 BLK A14 D14 GRN A5 D5 RED A13 D13 WHT A9 D9 LT BLU A10 D10 PUR A11 D11 WHT/BLK A2 D2 BLU/RED Is there continuity? YES - Substitute a known-good XM receiver, then reconnect all connector and recheck. If the symptom/indication goes away, replace the original XM receiver. If symptom/indication is still present, replace the audio unit. NO - Repair open in the wire between audio unit and XM receiver.
7. Disconnect CD changer connector B (14P) and XM receiver connector A.
8. Check for continuity between XM receiver connector A (14P) and body ground according to the table shown in XM RECEIVER CONNECTOR A (14P) AND BODY GROUND . Then check for continuity between the same terminals listed in the table and CD changer connector B (14P) No. 4 terminal (the harness shield). XM RECEIVER CONNECTOR A (14P) AND BODY GROUND XM receiver connector Wire color A6 BLK A14 GRN A5 RED A13 WHT A2 BLU/RED Is there continuity? YES - Repair a short in the wire between the CD changer and the XM receiver, or replace the appropriate shielded harness. NO - Go to step 9.
9. Check for continuity between XM receiver connector A (14P) and CD changer connector B (14P) according to the table shown in XM RECEIVER CONNECTOR A (14P) AND CD CHANGER CONNECTOR B (14P) . XM RECEIVER CONNECTOR A (14P) AND CD CHANGER CONNECTOR B (14P) XM receiver connector CD changer connector Wire color A6 B6 BLK A14 B14 GRN A5 B5 RED A13 B13 WHT A11 B11 WHT/BLK A2 B2 BLU/RED Is there continuity? YES - Go to step 10. NO - Repair open in the wire between CD changer and XM receiver.
10. Disconnect CD changer connector A (18P) and audio unit connector D (14P).
11. Check for continuity between CD changer connector A (18P) and body ground according to the table shown in CD CHANGER CONNECTOR A (18P) AND BODY GROUND , then check for continuity between the same terminals listed in the table and CD changer connector A (18P) No. 11 terminal (the harness shield). CD CHANGER CONNECTOR A (18P) AND BODY GROUND CD changer connector Wire color A9 BLK A1 GRN A10 RED A2 WHT Is there continuity? YES - Repair a short in the wire between the CD changer and the audio unit, or replace the appropriate shielded harness. NO - Go to step 12.
12. Check for continuity between CD changer connector A (18P) and audio unit connector D (14P) according to the table shown in CD CHANGER CONNECTOR A (18P) AND AUDIO UNIT CONNECTOR D (14P) . CD CHANGER CONNECTOR A (18P) AND AUDIO UNIT CONNECTOR D (14P) CD changer connector Audio unit connector Wire color A9 D6 BLK A1 D14 GRN A10 D5 RED A2 D13 WHT Is there continuity? YES - Substitute a known-good XM receiver, then reconnect all connectors and recheck. If the symptom/indication goes away, replace the original XM receiver. If the symptom/indication is still present, replace the audio unit. NO - Repair open in the wire between CD changer and the audio unit.

XM radio display is blank and no station information is displayed

Note. Do not do this procedure if the CD changer and navigation display buttons are inoperative. Refer to the navigation system troubleshooting.

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

1. Check fuse No. 7 (7.5 A) in the under-dash fuse/relay box. Is the fuse OK? YES - Go to step 2. NO - Replace the fuse, and recheck.
2. Turn the ignition switch to ACC (I).
3. Check the voltage between XM receiver connector A (14P) No. 1 terminal and body ground. Is there battery voltage? YES - Go to step 4. NO - Repair an open in the wire between fuse No. 7 (7.5 A) under-dash fuse/relay box and XM receiver connector A (14P) No. 1 terminal.
4. Check for voltage between XM receiver connector A (14P) No. 11 terminal and body ground. Is there less than 0.1 V? YES - With navigation: Go to step 12 . Without navigation: Go to step 16 . NO - With navigation: Repair an open in the wire between XM receiver connector A (14P) No. 11 terminal and CD changer connector B (14P) No. 11 terminal. Without navigation: Repair an open in the wire between XM receiver connector A (14P) No. 11 terminal and audio unit connector D (14P) No. 11 terminal.
5. Turn the ignition switch to LOCK (0).
6. Check the voltage between audio unit connector D (14P) No. 2 terminal and body ground. Is there 10 V or more present? YES - Go to step 7. NO - Go to step 10 .
7. Turn the ignition switch ON (II).
8. Check the voltage between audio unit connector D (14P) No. 2 terminal and body ground. Is there less than 0.5 V? YES - Go to step 9. NO - Substitute a known-good audio unit and recheck. If less than 0.5 V or present, replace the original audio unit.
9. Turn the ignition switch to LOCK (0).
10. Disconnect audio unit connector D (14P) and XM receiver connector A (14P).
11. Check for continuity between XM receiver connector A (14P) and body ground according to the table shown in XM RECEIVER CONNECTOR A (14P) AND BODY GROUND . Then check for continuity between the same terminals listed in the table and XM receiver connector A (14P) No. 3 terminal (the harness shield). XM RECEIVER CONNECTOR A (14P) AND BODY GROUND XM receiver connector Wire color A9 LT BLU A10 PUR A2 BLU/RED Is there continuity? YES - Repair a short in the wire between the audio unit and the XM receiver, or replace the appropriate shielded harness. NO - Go to step 12.
12. Check for continuity between XM receiver connector A (14P) and audio unit connector D (14P) according to the table shown in XM RECEIVER CONNECTOR A (14P) AND AUDIO UNIT CONNECTOR D (14P) . XM RECEIVER CONNECTOR A (14P) AND AUDIO UNIT CONNECTOR D (14P) XM receiver connector Audio unit connector Wire color A9 D9 LT BLU A10 D10 PUR A2 D2 BLU/RED Is there continuity? YES - Substitute a known-good XM receiver, then reconnect all connector and recheck. If the symptom/indication goes away, replace the original XM receiver. If symptom/indication is still present, replace the audio unit. NO - Repair an open in the wire between audio unit and XM receiver.
13. Turn the ignition switch to LOCK (0).
14. Check the voltage between CD changer connector B (14P) No. 2 terminal and body ground. Is there 10 V or more present? YES - Go to step 15. NO - Go to step 21 .
15. Turn the ignition switch ON (II).
16. Check the voltage between CD changer connector B (14P) No. 2 terminal and body ground. Is there less than 0.5 V? YES - Go to step 17. NO - Substitute a known-good CD changer and recheck. If 0.5 V or less are present, replace the original CD changer.
17. Turn the ignition switch to LOCK (0).
18. Disconnect CD changer connector B (14P) and XM receiver connector A (14P).
19. Check for continuity between XM receiver connector A (14P) and body ground according to the table shown in XM RECEIVER CONNECTOR A (14P) AND BODY GROUND . XM RECEIVER CONNECTOR A (14P) AND BODY GROUND XM receiver connector Wire color A2 BLU/RED Is there continuity? YES - Repair a short in the wire between the CD changer and the XM receiver, or replace the appropriate shielded harness. NO - Go to step 20.
20. Check for continuity between XM receiver connector A (14P) and CD changer connector B (14P) according to the table shown in XM RECEIVER CONNECTOR A (14P) AND CD CHANGER CONNECTOR B (14P) . XM RECEIVER CONNECTOR A (14P) AND CD CHANGER CONNECTOR B (14P) XM receiver connector CD changer connector Wire color A2 B2 BLU/RED Is there continuity? YES - Go to step 21. NO - Repair an open in the wire between CD changer and XM receiver.
21. Disconnect the navigation control unit connector B (14P).
22. Check for continuity between XM receiver connector A (14P) and body ground according the table shown in XM RECEIVER CONNECTOR A (14P) AND BODY GROUND . Then check same terminals for continuity to XM receiver connector A (14P) terminal No. 3 (the harness shield). XM RECEIVER CONNECTOR A (14P) AND BODY GROUND XM receiver connector Wire color A9 LT BLU A10 PUR Is there continuity? YES - Repair a short in the wire between the XM receiver and the navigation unit, or replace the appropriate shielded harness. NO - Go to step 23.
23. Check for continuity between XM receiver connector A (14P) and navigation unit connector B (14P) according to the table shown in XM RECEIVER CONNECTOR A (14P) AND NAVIGATION UNIT CONNECTOR B (14P) . XM RECEIVER CONNECTOR A (14P) AND NAVIGATION UNIT CONNECTOR B (14P) XM receiver connector Navigation unit Wire color A9 B2 LT BLU A10 B8 PUR Is there continuity? YES - Substitute a known-good XM receiver and reset. NO - Repair open in the wire between the XM receiver and the navigation unit.

1. Check for sound in each mode (AM, FM, XM, and tape/disc). Is there sound from the speakers, and is the sound quality normal in each mode? YES - Intermittent failure. The system is OK at this time. Check for loose connections at the audio unit, amplifier, and each speaker. NO - Speakers all work, sound quality is poor. If sound is poor only with XM radio, or the XM radio does not function, go to poor or no sound with XM radio (see POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) ). If the sound is poor only with AM or FM, go to poor radio reception or interference (see POOR RADIO RECEPTION OR INTERFERENCE ). If sound is poor in all modes, go to sound quality diagnosis (see SOUND QUALITY DIAGNOSIS ).

Scheme 62

Scheme 63

1. Turn the ignition switch to ON (II).
2. Turn the combination lighting switch to the parking light position.
3. Check the illumination of the audio unit buttons. Are the buttons illuminated? YES - Intermittent problem: the audio unit is OK at this time. Check for loose or poor connections at audio unit connector A (20P). NO - Go to step 4.
4. Check the illumination of several other buttons not related to the audio system. Are the buttons illuminated? YES - Go to step 5. NO - Troubleshoot the interior lights. Start by checking the No. 7 (7.5 A) fuse in the passenger's under-dash fuse/relay box. If the fuse is OK, check for open in the wire between the passenger's under-dash fuse/relay box and the audio unit.
5. Turn the ignition switch to LOCK (0).
6. Disconnect audio unit connector A (20P).
7. Disconnect gauge control module connector A (30P).
8. Check for continuity between audio unit connector A (20P) No. 19 terminal and gauge control module connector A (30P) No. 9 terminal. Is there continuity? YES - Go to step 9. NO - Repair an open in the wire between the gauge control module and the audio unit.
9. Turn the ignition switch to ON (II).
10. With the headlight switch still on, check for voltage between audio unit connector A (20P) No. 9 terminal and body ground. Is there battery voltage? YES - Check the connections at the audio unit connector A (20P). If all connections are OK, replace the audio unit. NO - Repair an open in the wire between the passenger's under-dash fuse/relay box and the audio unit.

Radio preset memory is lost

Note. If only XM stations are lost, go to XM radio preset memory is lost (see XM RADIO PRESET MEMORY IS LOST ).

1. Set each of the radio station preset buttons. Do each of the buttons set properly? YES - Go to step 2. NO - Replace the audio unit.
2. Turn the ignition switch OFF for 1 minute, then turn it back to ON (II).
3. Test the preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES - System is normal at this time. Check connections at the audio unit. NO - Replace the audio unit.

Scheme 64

Scheme 65

1. Set each of the XM radio channel preset buttons. Do each of the XM radio channel preset buttons set properly? YES - Go to step 2. NO - Replace the XM receiver.
2. Turn the ignition switch OFF for 1 minute, then turn it back to ON (II).
3. Test all of the XM radio channel preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES - System is normal at this time. Check connections at the XM receiver. NO - Go to step 4.
4. Turn the ignition switch to LOCK (0).
5. Measure voltage between XM receiver connector A (14P) No. 1 terminal and body ground. Is there battery voltage? YES - Go to step 6. NO - Repair an open in the wire between the driver's under-dash fuse/relay box and XM receiver connector A (14P) No. 1 terminal.
6. Check for voltage between XM receiver connector A (14P) No. 11 terminal and body ground. Is there less than 1.0 V? YES - Replace the XM receiver. NO - With navigation: Repair an open in the wire between XM receiver connector A (14P) No. 20 terminal and CD changer connector B (14P) No. 11 terminal. Without navigation: Repair an open in the wire between XM receiver connector A (14P) No. 11 terminal and audio unit connector D (14P) No. 11 terminal.

Audio disc does not eject

Note. Disc labels should not be used in the audio unit. They may damage the player mechanism.

1. Turn on the audio system. Does the system turn on? YES - Go to step 2. NO - Go to power switch will not turn ON (see POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) ).
2. Check to see if the disc ejects correctly with no binding by pushing the EJECT button. Is it normal? YES - Operation is normal. NO - With navigation: Replace the CD changer. Without navigation: Replace the audio unit.

Disc changer does not load all six discs

Note. Disc labels should not be used in the audio unit. They may damage the player mechanism.

1. Try loading six discs into the audio unit. Does the audio unit accept all six discs? YES - Intermittent failure, the audio unit is OK at this time. NO - Go to step 2.
2. Try loading the disc player with six known-good discs. Does the audio unit accept all six discs? YES - At least one of the original discs is faulty. NO - With navigation: Replace the CD changer. Without navigation: Replace the audio unit.

Disc changer does not move between discs

Note. Disc labels should not be used in the audio unit. They may damage the player mechanism.

1. Insert six discs into the audio unit and see if the changer moves between discs. Does the changer operate normally? YES - Intermittent failure, the disc changer is OK at this time. NO - Go to step 2.
2. Insert six known-good disks into the audio unit. Does the changer operate normally? YES - At least one of the original discs is faulty. NO - With navigation: Replace the CD changer. Without navigation: Replace the audio unit.

Volume does not change

Note. Set the fader and balance positions to the center.

1. Listen for sound from the speakers. Is the sound normal? YES - Go to step 2. NO - Go to audio system sound is weak or distorted, or no sound is heard from speakers (see NO SOUND IS HEARD FROM SPEAKERS (DISPLAY IS NORMAL) ).
2. Operate the volume knob to see if the volume changes. Does the volume change? YES - Operation is normal. NO - Replace the audio unit.

Radio tuner does not change stations

1. Check the audio information on the display panel. Does the audio information display properly? YES - Go to step 2. NO - Go to power switch will not turn ON (see POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) ).
2. Operate the tuning knob to see if the radio station changes. Does the radio station change? YES - Intermittent failure, the turning knob is OK at this time. NO - Replace the audio unit.

Audio disc does not load

Note. Disc labels should not be used in the audio unit. They may damage the player mechanism. Make sure the CD disc is compatible with the system (refer to the owner's manual for more information).

1. Insert a known-good disc to see if the symptom can be duplicated. Does the disc load? YES - Operation is normal. If the disc loads normally. But will not play, go to disc does not play (see AUDIO DISC DOES NOT PLAY ). NO - Go to step 2.
2. Insert another disc. Does the disc load? YES - The original disc is faulty. NO - With navigation: Replace the CD changer. Without navigation: Replace the audio unit.

Special Tools Required

Diagnostics CD 07AAZ-SDBA100

Audio disc does not play

1. Try loading a disc. Does the disc load? YES - Go to step 2. NO - Go to disc does not load (see AUDIO DISC DOES NOT LOAD ).
2. Insert another disc to see if the symptom can be duplicated. Does the disc play? YES - Operation is normal. NO - Go to step 3.
3. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) in the audio unit. Does the disc play? YES - The original disc is faulty or has an unreadable format. NO - With navigation: Replace the CD changer. Without navigation: Replace the audio unit.

Special Tools Required

Diagnostics CD 07AAZ-SDBA100

Skip test CD 07AAZ-SDBA200 (ABEX TCD 725B)

Skip test CD 07AAZ-SDBA300 (ABEX TCD 721)

Audio disc skips

1. Confirm the vehicle tires are properly inflated.
2. Check the customer's CD for scratches, fingerprints, and marks. NOTE: The following test should be performed with audio unit bass and treble set to customer's listening performance. When comparing to a known-good vehicle, comparison should be performed on same model and trim level.
3. Test drive to identify when the customer's CD skipping occurs. The audio diagnostic CD (T/N: 07AAZ-SDBA100) can be used if the customer's CD is not available. Use tracks 10-12. Does the skipping occur? YES - Go to step 4. NO - Operation is normal.
4. Compare the customer's CD that is skipping to a known-good vehicle under the same conditions. Does the CD skip in the known-good vehicle under the same conditions? YES - Operation is normal. NO - Go to step 5. NOTE: The following test should be performed with the vehicle parked and engine running.
5. Insert the diagnostic skip test CD (07AAZ-SDBA300) (ABEX TCD 721). Play tracks 2-11 and note the track number(s) the CD starts skipping. Do the same test on a known-good vehicle. Does the CD skip on same track(s) number as the known-good vehicle? YES - Operation is normal. NO - Go to step 6.
6. Insert the diagnostic skip test CD (07AAZ-SDBA200) (ABEX TCD 725B) play tracks 7-11 and tracks 13-15 and note the track number(s) the CD starts skipping. Perform the same test on a known-good vehicle. Does the CD skip on same track(s) number as the known-good vehicle? YES - Operation is normal. NO - With navigation: Replace the CD changer. Without navigation: Replace the audio unit.

Scheme 66

Scheme 67

1. Test the radio remote switch (see RADIO REMOTE SWITCH TEST ). Is the radio remote switch OK? YES - Go to step 2. NO - Replace the radio remote switch.
2. Check the audio unit operation (volume up, volume down, CH (-), CH (+), MODE). Is the audio unit operation OK? YES - Go to step 3. NO - Replace the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ), and recheck.
3. Remove the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ).
4. Measure resistance between the audio unit connector (20P) A3 and A11 terminals as specified in the table shown in AUDIO UNIT CONNECTOR (20P) A3 AND A11 . AUDIO UNIT CONNECTOR (20P) A3 AND A11 Button held down VOL DOWN VOL UP CH (-) CH (+) MODE (NONE) Resistance about 100 ohm about 370 ohm about 770 ohm about 1.7 Kohm about 3.7 Kohm 10 k ohm Is resistance OK? YES - Go to step 5. NO - Repair open or high resistance in the circuit between the audio unit and the radio remote switch. If the wires are OK, replace the cable reel (see CABLE REEL REPLACEMENT ).
5. Check for continuity between the No. 3 and No. 11 terminals of the audio unit connector A (20P) and body ground. Is there continuity? YES - Repair the short to body ground in the circuit between the audio unit and the radio remote switch. If the wires are OK, replace the cable reel (see CABLE REEL REPLACEMENT ). NO - Replace the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ).

Radio displays error code: XM NO SIGNAL or XM ANTENNA

Note. Check the XM radio reception in an open area. Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines.

1. Park the vehicle outside with a clear view of the southern horizon. Does the XM radio receive a signal? YES - Reception interference operation is normal. NO - Go to step 2.
2. Check XM antenna connector B (2P) at XM receiver. Is XM antenna connector B connected? YES - Go to step 3. NO - Reconnect XM connector B, recheck the XM radio operation. If the signal is restored, operation is normal. If signal not restored go to step 3.
3. Substitute a known-good XM antenna. Does the XM radio receiver a signal? YES - Replace the XM antenna. NO - Substitute a known-good XM antenna subharness. If the XM radio receives signal, replace the original XM antenna subharness.

Left/Right Channel ID

Do this test to confirm proper channel routing.

1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the CD player.
2. Play the track No. 1 (left, both, right channel ID) at a normal, or slightly higher than normal, volume level.
3. The voice should be audible only from the channel or channels when indicated. If the channel ID is correct for each side, go to PHASE TEST . If the channel ID is not correct, check for - Shorted speaker wire - Faulty amplifier - Faulty audio unit

Special Tools Required

Diagnostics CD 07AAZ-SDBA100

Frequency sweep

Do this test to find rattles or reverberation that may cause a perception of poor sound quality.

1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the CD player.
2. Play the track No. 13 (sweep from 500 Hz to 35 Hz) at a normal, or slightly higher than normal, volume level.
3. Listen to each speaker for poor sound quality or reverberations caused by specific frequencies. Use the voice-over to estimate the frequency that causes the vibration. Use the audio unit's fader and balance settings to help isolate the channel with the problem. If vibrations or poor sound quality is heard, go to step 4. If no vibrations or poor sound quality is heard, go to SOUND JUDGING .
4. Choose the appropriate track from No. 14 to 25 (small range frequency sweep) or 26 to 53 (single frequencies) to recreate the frequency that caused the poor sound quality or vibration located in step 3 : this aids in diagnosis of the cause. NOTE: When you get to the track that recreates the problem, select the repeat function on the audio unit, this will help you isolate the cause.
5. Replace or insulate the source of the vibration or, if the speaker is the source of the poor sound quality, replace it.

Special Tools Required

Diagnostics CD 07AAZ-SDBA100

Sound judging

Do this test to compare overall sound quality, imaging, and dynamics between the client's vehicle and a known-good vehicle. Only use a vehicle of the same model and trim level for this test.

1. In the client's vehicle, set the bass, treble, fader, and balance settings to the client's normal settings that were written down before beginning testing.
2. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the CD player.
3. Play the tracks No. 7 to 12 (sound quality, midland, dynamics, and imaging demonstration tracks) at a normal, or slightly higher than normal, volume level. Write down the volume setting being used.
4. Listen to areas of the track that stand out as being either real clear or poorer than other areas of the track.
5. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the CD player of a known-good vehicle.
6. Play the tracks at the same volume level and the same bass, treble, balance, and fader settings as used in step 3 in the client's vehicle.
7. Listen to the same area of the track that stood out as being either real clear or poorer than other areas of the track.
8. Compare the client's vehicle's sound quality results with the known-good vehicle's results. If the sound quality in the client's vehicle is comparable to the sound quality in the known-good vehicle, then the client's vehicle is operating as designed. If the sound quality is not comparable, check these items in order. - Loose or improperly installed speakers or other hardware that may become excited by the vibrations generated by the speakers - Poor power or ground to the stereo amplifier - Damaged speaker(s) - Faulty amplifier - Faulty audio unit

Window Antenna Repair

Note. To make an effective repair, the broken section must be no longer than one inch.

Scheme 68

Scheme 69

1. Lightly rub the area around the broken section (A) with fine steel wool, then clean it with alcohol.
2. Carefully mask above and below the broken portion of the window antenna wire (B) with cellophane tape (C).
3. Mix the silver conductive paint thoroughly. Using a small brush, apply a heavy coat of paint (A) extending about 1/8" on both sides of the break. Allow 30 minutes to dry.
4. Check for continuity in the repaired wire.
5. Apply a second coat of paint in the same way. Let it dry 3 hours before removing the tape.
