Design Specifications
| Item | Measurement | Qualification | Specification |
|---|---|---|---|
| DIMENSIONS | Overall length | 5,110 mm (201.2 in.) | |
| Overall width | 1,920 mm (75.6 in.) | ||
| Overall height | VAN, LX | 1,740 mm (68.5 in.) | |
| EX, EXL | 1,770 mm (69.7 in.) | ||
| Wheelbase | 3,000 mm (118.1 in.) | ||
| Track | Front | 1,680 mm (66.1 in.) | |
| Rear | 1,680 mm (66.1 in.) | ||
| Ground clearance | 163 mm (6.4 in.) | ||
| Seating capacity | Seven (7) | ||
| WEIGHT (U.S.A.) | Gross Vehicle Weight Rating (GVWR) | 1999-2001 models | 5,567 lbs |
| 2002-2004 models | 5,665 lbs | ||
| WEIGHT (CANADA) | Gross Vehicle Weight Rating (GVWR) | 1999-2001 models | 2,525 kg |
| 2002-2004 models | 2,570 kg | ||
| ENGINE | Type | Water-cooled, 4-stroke SOHC VTEC V6 gasoline engine | |
| Cylinder arrangement | 60°V6-cylinder, transverse | ||
| Bore and stroke | 89.0 x 93.0 mm (3.50 x 3.66 in.) | ||
| Displacement | 3,471 cm 3 (m l ) (222 cu in.) | ||
| Compression ratio | 1999-2001 models | 9.4 | |
| 2002-2004 models | 10.0 | ||
| Valve train | Belt driven, SOHC VTEC 4 valves per cylinder | ||
| Lubrication system | Forced, wet sump, with trochoid pump | ||
| Oil pump displacement | At 6,000 rpm | 58.4 l (61.7 US qt)/minute | |
| Water pump displacement | At 6,000 rpm | 172 l (182 US qt)/minute | |
| Fuel required | UNLEADED gasoline with Pump Octane Number of 86 or higher | ||
| STARTER | Type | Gear reduction | |
| Normal output | 1.6 kW | ||
| Normal voltage | 12 V | ||
| Hour rating | 30 seconds | ||
| Direction of rotation | Clockwise as viewed from gear end | ||
| 4-speed AUTOMATIC TRANSMISSION (1999-2001 models) | Type | Electronically controlled automatic, 4-speed forward, 1 reverse | |
| Primary reduction | Direct 1:1 | ||
| Gear ratio | 1st | 2.534 | |
| 2nd | 1.502 | ||
| 3rd | 0.947 | ||
| 4th | 0.608 | ||
| Reverse | 1.846 | ||
| Final reduction | Type | Single helical gear | |
| Gear ratio | 3.941 | ||
| 5-speed AUTOMATIC TRANSMISSION (2002-2004 models) | Type | Electronically controlled automatic, 5-speed forward, 1 reverse | |
| Primary reduction | Direct 1:1 | ||
| Gear ratio | 1st | 2.563 | |
| 2nd | 1.552 | ||
| 3rd | 1.021 | ||
| 4th | 0.727 | ||
| 5th | 0.520 | ||
| Reverse | 1.846 | ||
| Final reduction | Type | Single helical gear | |
| Gear ratio | 4.200 | ||
| STEERING | Type | Power-assisted rack and pinion | |
| Overall ratio | 16.57 | ||
| Turns, lock-to-lock | 3.44 | ||
| Steering wheel diameter | 380 mm (15.0 in.) | ||
| SUSPENSION | Type | Front | Strut |
| Rear | Double wishbone | ||
| Shock absorber | Front and rear | Telescopic, hydraulic, nitrogen gas-filled | |
| WHEEL ALIGNMENT | Camber | Front | 0° |
| Rear | 0°30' | ||
| Caster | Front | 2°07' | |
| Total toe | Front | 0 mm (0 in.) | |
| Rear | 0 mm (0 in.) | ||
| BRAKES | Type of service brake | Front | Power-assisted self-adjusting ventilated disc |
| Rear (1999-2001 models) | Power-assisted self-adjusting drum | ||
| Rear (2002-2004 models) | Power-assisted self-adjusting solid disc | ||
| Type of parking brake | Mechanical actuating, rear wheels | ||
| Pad friction surface area | Front (1999-2001 models) | 55 cm 2 x 4 (8.5 sq in. x 4) | |
| Front (2002-2004 models) | 51 cm 2 x 4 (7.9 sq in. x 4) | ||
| Rear (2002-2004 models) | 22 cm 2 x 4 (3.4 sq in. x 4) | ||
| Shoe friction surface area | Rear (1999-2001 models) | 109 cm 2 x 4 (16.9 sq in. x 4) | |
| Rear (2002-2004 models) | 58 cm 2 x 4 (9.0 sq in. x 4) | ||
| TIRES | Size of front and rear tires | 1999-2001 models | P215/65R16 96T |
| 2002-2004 models | P225/60R16 98T | ||
| Size of spare tires | T135/80D16 101M | ||
| AIR CONDITIONING | Cooling capacity | Front | 4,375 Kcal/h (17,300 BTU/h) |
| Rear | 3,565 Kcal/h (14,100 BTU/h) | ||
| Compressor | Type/Manufacturer | Swash plate/DENSO | |
| Number of cylinders | 10 | ||
| Capacity | 210 m l /rev. (12.81 cu in./rev.) | ||
| Maximum speed | 7,600 rpm | ||
| Lubricant capacity | 210 m l (6 fl oz) | ||
| Lubricant type | ND-OIL 8 | ||
| Condenser | Type | Corrugated fin | |
| Evaporator | Type | Corrugated fin | |
| Blower | Type | Sirocco fan | |
| Motor input (Front) | 225 W/12 V | ||
| Motor input (Rear) | 180 W/12 V | ||
| Speed control (Front) | Manual A/C: 4-speed, Auto A/C: Infinite variable | ||
| Speed control (Rear) | 3 speed | ||
| Maximum capacity (Front) | 490 m 3 /h (17,300 cu ft/h) | ||
| Maximum capacity (Rear) | 375 m 3 /h (13,200 cu ft/h) | ||
| Temperature control | Air-mix type | ||
| Compressor clutch | Type | Dry, single plate, Poly-V belt drive | |
| Electrical power consumption at 68°F (20°C) | 40 W maximum at 12 V | ||
| Refrigerant | Type | HFC-134a (R-134a) | |
| Quantity (Dual) | 850-900 g (29-32 fl oz) | ||
| Quantity (Single) | 600-650 g (21-23 fl oz) | ||
| ELECTRICAL | Battery | 12 V - 20/5 HR 65A | |
| RATINGS | Starter | 12 V - 1.6 kW | |
| Alternator | 12 V - 130A | ||
| Fuses | Under-hood fuse/relay box | 120A, 50A, 40A, 30A, 20A, 15A, 7.5A | |
| Under-dash driver's fuse/relay box | 30A, 15A, 10A, 7.5A | ||
| Under-dash passenger's fuse/relay box | 20A, 15A, 10A, 7.5A | ||
| Multi-fuse/relay box (1999-2002 models) | 40A, 30A, 20A | ||
| Under-hood subfuse box (2003-2004 models) | 40A, 30A, 20A | ||
| Light bulbs | Headlights high/low | 12 V - 60/55 W | |
| Front turn signal/Front side marker lights | 12 V - 21 W/5 W (two filaments) | ||
| Rear turn signal lights | 12 V - 21 W | ||
| Brake/Taillights | 12 V - 21/5 W | ||
| Inner Taillights | 12 V - 5 W | ||
| High mount brake light | 12 V - 18 W | ||
| Back-up lights | 12 V - 21 W | ||
| License plate light | 12 V - 5 W | ||
| Cargo area light | 12 V - 8 W | ||
| Vanity mirror lights | 12 V - 1.8 W | ||
| Center pocket light | 12 V - 3.4 W | ||
| Front individual map lights | 12 V - 4 cp | ||
| Rear individual map lights | 12 V - 10 W | ||
| Gauge lights | 12 V - 3.0 W, 3.4 W, 1.4 W | ||
| Indicator lights | 12V LED, 14V - 0.84 W, 1.4 W | ||
| Panel and pilot lights | 14 V - 0.7 W | ||
| Front heater control panel lights | 8 V - 1.2 W, 14 V - 1.12 W, 1.4 W | ||
| Rear heater control panel lights | 14 V - 1.4 W |
Design Specifications Table
