TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor Mounting Bolt | 33 (44) |
| Camshaft Bearing Cap Bolt (1) | 17 (24) |
| Camshaft Sprocket Bolt | 67 (91) |
| Camshaft Thrust Cover Bolt | 16 (22) |
| Connecting Rod Cap Bolt (2) | 14 (20) |
| Crankshaft Pulley Bolt | 181 (245) |
| Cylinder Head Bolt (3) |
| Step 1 | 29 (39) |
| Step 2 | 51 (69) |
| Step 3 | 72 (98) |
| Engine Mount Bracket | 33 (44) |
| Exhaust Manifold |
| Self-Locking Nut | 23 (31) |
| Shroud Bolt | 16 (22) |
| Exhaust Pipe Flange Nut | 40 (54) |
| Flexplate Bolt (4) | 54 (74) |
| Front Mount Bracket Bolt | 28 (38) |
| Generator Bracket Bolt | 16 (22) |
| Idler Pulley Bolt | 33 (44) |
| Intake Manifold Bolt/Nut | 16 (22) |
| Main Bearing Cap Bolt (5) |
| 10-mm Side Bolt | 36 (49) |
| 11-mm Vertical Bolt | 56 (76) |
| Power Steering Pump |
| Lock Nut | 16 (22) |
| Mounting Bolt | 16 (22) |
| Rear Mount Bracket | 28 (38) |
| Throttle Body Bolt/Nut | 16 (22) |
| Transmission-to-Engine Bolt | 47 (64) |
| VTEC Solenoid Valve/Oil Filter Assembly Bolt | 16 (22) |
| INCH Lbs. (N.m) |
| Auto-Tensioner Mounting Bolt | 106 (12) |
| Coolant Passage Manifold Bolt | 106 (12) |
| Crankshaft Rear Seal Cover Bolt | 106 (12) |
| Cylinder Head Cover Bolt | 106 (12) |
| Oil Baffle Plate Bolt | 106 (12) |
| Oil Pan Bolt (6) | 106 (12) |
| Oil Pump Housing Bolts | 106 (12) |
| Timing Belt Cover Bolt | 106 (12) |
| Valve Cover Bolt | 106 (12) |
| Water Pump Bolt | 106 (12) |
| (1) Rocker arm shaft bolts. Tighten bolts 2 turns at a time in sequence until rocker is seated, then tighten to specification. (Scheme 3) (2) Tighten an additional 90 degrees. (3) Tighten in sequence, in 2-3 steps. see scheme 227. (4) Tighten in a crisscross pattern. (5) Tighten in sequence. see scheme 335. (6) Tighten in sequence. see scheme 336. |
| (1) | Rocker arm shaft bolts. Tighten bolts 2 turns at a time in sequence until rocker is seated, then tighten to specification. (Scheme 3) |
| (2) | Tighten an additional 90 degrees. |
| (3) | Tighten in sequence, in 2-3 steps. see scheme 227. |
| (4) | Tighten in a crisscross pattern. |
| (5) | Tighten in sequence. see scheme 335. |
| (6) | Tighten in sequence. see scheme 336 |
Scheme 1
Scheme 2
Scheme 3
