Special Tools Required
- P/S joint adapter (pump) 07VAK-P8A011A
- P/S joint adapter plate (pump) 07VAK-P8A012B
- P/S joint adapter (hose) 07RAK-S040122
- P/S pressure gauge 07406-0010001
Check the fluid pressure as follows to determine whether the trouble is in the pump or gearbox.
Scheme 87
Scheme 88
- Check the power steering fluid level (see «Fluid Replacement»(ref-171165-S30156302182005012800000) ) and pump belt tension (see «Pump Belt Inspection and Adjustment»(ref-171165-S40639405972005012800000) ).
- Disconnect the pump outlet hose (A) from the pump outlet with care so as not to spill the power steering fluid on the frame and other parts. Wipe off any spilled fluid at once. Install the P/S joint adapter (pump) on the pump outlet (B) with the P/S joint outlet plate.
- Connect the P/S joint adapter (hose) to the P/S pressure gauge, then connect the pump outlet hose (A) to the P/S joint adapter (hose).
- Install the P/S pressure gauge to the P/S joint adapter (pump).
- Fully open the shut-off valve (A).
- Fully open the pressure control valve (B).
- Start the engine and let it idle.
- Turn the steering wheel from lock-to lock several times to warm the fluid to operating temperature at 158°F (70°C).
- Measure steady state fluid pressure while the engine is idling If the pump is in good condition the gauge should read less than 1,500 kPa (15kgf/cm2 213 psi). If it reads high, check for Clogged of deformed feed of return line between the pump and gearbox Clogged valve body unit
- Close the shut-off valve, then close the pressure control valve gradually until the pressure gauge needle is stable Read the pressure. NOTE: Do not keep the pressure control valve closed more than 5 seconds or the pump could be damaged by over heating.
- Immediately open the shut off valve fully If the pump is in good condition, the gauge should read at least 8,300-8,800 kPa (85-90 kgf/cm2 1,210-1,280 psi). A low reading means pump output is too low for full assist. Repair or replace the pump.
- P/S joint adapter (pump) 07VAK-P8A011A
- P/S joint adapter plate (pump) 07VAK-P8A012B
- P/S joint adapter (hose) 07RAK-S040122
- P/S pressure gauge 07406-001000A
Check the fluid pressure as follows to determine whether the trouble is in the pump or gearbox.
Scheme 89
Scheme 90
- Check the power steering fluid level (see «Fluid Replacement»(ref-171165-S30156302182005012800000) ) and pump belt tension (see «Pump Belt Inspection and Adjustment»(ref-171165-S40639405972005012800000) ).
- Disconnect the pump outlet hose (A) from the pump outlet with care so as not to spill the power steering fluid on the frame and other parts. Wipe off any spilled fluid at once. Install the P/S joint adapter (pump) on the pump outlet (B) with the P/S joint outlet plate.
- Connect the P/S joint adapter (hose) to the P/S pressure gauge, then connect the pump outlet hose (A) to the P/S joint adapter (hose).
- Install the P/S pressure gauge to the P/S joint adapter (pump).
- Open the pressure control valve (A) fully.
- Start the engine and let it idle.
- Turn the steering wheel from lock-to-lock several times to warm the fluid to operating temperature at 158°F(70°C).
- Measure steady-state fluid pressure while the engine is idling. If the pump is in good condition, the gauge should read less than 1,500 kPa (15kgf/cm2, 213 psi). If it reads high, check for: Clogged of deformed feed of return line between the pump and gearbox. Clogged valve body unit.
- Close the pressure control valve gradually and read the pressure. NOTE: Do not keep the pressure control valve closed more than 5 seconds or the pump could be damaged by over-heating.
- Immediately open the pressure control valve fully. If the pump is in good condition, the gauge should read at least 8,300-8,800 kPa (85-90 kgf/cm2, 1,210-1,280 psi). A low reading means pump output is too low for full assist. Repair or replace the pump.
Scheme 91
- Belt tension gauge set 07JGG-001000A
- Belt tension gauge 07JGG-001010A
Scheme 92
- Attach the belt tension gauge to the belt with the gauge face toward the engine, and measure the tension of the belt. Follow the manufacture's instructions. If the belt is worn or damaged, replace it. NOTE: Remove the belt tension gauge carefully to avoid hitting the gauge reset lever. Tension: Used Belt: 390 - 540 N (40-55 kgf, 88 - 120 lbf) New Belt: 740 - 880 N (75 - 90 kgf, 170 - 200 lbf)
- If you installed a new belt, run the engine for 5 minutes, then readjust the belt to the used belt specifications.
Scheme 93
- Loosen the power steering pump mounting nut (A) and bolt (B).
- Turn the adjusting nut (C) to get the proper belt tension, then retighten the mounting nut and bolt.
- Start the engine and turn the steering wheel from lock-to-lock several times, then stop the engine and recheck the tension of the belt.
Scheme 94
- Apply a force of 98 N (10 kgf, 22 lbf) and measure the deflection between the power steering pump pulley (A) and the crankshaft pulley (B). Deflection: Used Belt 13.0 - 16.5 mm (0.51 - 0.65 in ) New Belt - 8.5 - 11.0 mm (0.33 - 0.43 in )
- If you installed a new belt, run the engine for 5 minutes, then readjust the belt to the used belt specifications.
Scheme 95
- Loosen the power steering pump mounting nut (A) and bolt (B).
- Turn the adjusting nut (C) to get the proper belt tension, then retighten the mounting nut and bolt.
- Start the engine and turn the steering wheel from lock-to-lock several times, then stop the engine and recheck the tension of the belt.
Universal holder 07725-0030000
locknut wrench, 43 mm 07MAA-SL00200
Scheme 96
Scheme 97
- Set the wheels in the straight ahead position.
- Loosen the rack guide screw locknut (A) with a special tool, then remove the rack guide screw (B).
- Remove the old sealant from the rack guide screw threaded section, and apply new sealant around the first three threads (A). Loosely install the rack guide screw on the steering gearbox.
- Tighten the rack guide screw to 25 N.m (2.5 kgf.m, 18 lbf Ft), then loosen it.
- Retighten the rack guide screw to 3.9 N.m (0.4 kgf.m, 2.9 lbf Ft), then back it off to the specified angle. Specified Return Angle: 20°
- Tighten the locknut while holding the rack guide screw.
- Check for unusual steering effort through the complete turning travel.
- Check the steering wheel rotational play (see «Steering Wheel Rotational Play Check»(ref-171165-S40834807862005012800000) ) and power assist (see «Power Assist Check»(ref-171165-S14941423092005012800000) ).
- Ball joint remover, 28 mm 07MAC-SL00200
- Engine support fixture 07XAA-001030A
- Cable eyebolt assembly 07ZAA-S0XA100
Note these items during removal
- Using solvent and a brush, wash any oil and dirt off of the valve body unit its lines, and the end of the gearbox. Blow dry with compressed air.
- Make sure to remove the steering wheel before disconnecting the steering joint. Damage to the cable reel can occur.
- Lower the front subframe 30 mm (1.18 in.) from the body and remove/install the steering gearbox through the gap produced by lowering the front subframe.
Scheme 98
Scheme 99
Scheme 100
Scheme 101
Scheme 102
Scheme 103
Scheme 104
Scheme 105
Scheme 106
Scheme 107
Scheme 108
Scheme 109
Scheme 110
Scheme 111
Scheme 112
Scheme 113
- Dram the power steering fluid (see step 1 on «Fluid Replacement»(ref-171165-S30156302182005012800000) ).
- Record the customer's radio station presets.
- Remove the driver's airbag assembly (see AIR BAG RESTRAINT SYSTEMS article ).
- Remove the steering wheel (see «Steering Wheel Removal»(ref-171165-S23766756552005012800000) ).
- Remove the steering joint cover.
- Remove the steering joint bolts (A) and disconnect the steering joint (B) by moving it toward the column.
- Raise the vehicle, and make sure it is securely supported.
- Remove the front wheels.
- Remove the cotter pin (A) from the 12 mm nut (B), and loosen the nut.
- Separate the tie-rod ball joint and knuckle using the special tool (see BALL JOINT REMOVAL ).
- Remove the following parts. Exhaust pipe (A) (see «EXHAUST PIPE AND MUFFLER REPLACEMENT»(ref-171095-S26145169572005012600000) ) Three way catalytic converter (TWC) (B) (see «EXHAUST PIPE AND MUFFLER REPLACEMENT»(ref-171095-S26145169572005012600000) ) Splash shield (C)
- Remove the feed line mounting brackets (A) from front subframe.
- Loosen the 14 mm flare nut (A), and disconnect the feed line (B).
- Loosen the adjustable hose clamp (C) and disconnect the return hose (D).
- Lift and support the engine with the special tools. Position the tool over the hood latch. Loop the cable (A) around the throttle body (B), and tighten the wing nut (C) on the tool by hand until the cable is tight. NOTE: For '02-04 models, replace the cable eyebolt assembly (A) on the engine support fixture with 07ZAA-S0XA100.
- Remove the rear engine mount (A).
- Pass the removed 12 mm flange bolt (A) through the bolt hole of the mounting bracket (B), and hook the rear engine mount (C) removed in step 16 on the 12 mm flange bolt.
- Attach a wood block (A) to the lower center of the front subframe (B). Attach a jack to the center of the wood block and support the front subframe securely by raising the jack.
- Loosen the four 14 mm special bolts (C) on the front subframe so they are 30 mm (1.18 in.) from the mounting surface (until the stepped part of each bolt can be seen). Do not loosen the 14 mm special bolts more than necessary.
- Remove the four 12 mm flange bolts from the front stiffener plates (A).
- Remove the two 12 mm flange bolts from the rear stiffener plates (A).
- Lower the jack slowly until the front subframe is held with the 14 mm special bolts that were loosened in step 19 .
- Remove the clamp for the feed line (A) from the right mounting bracket (B) of the steering gearbox.
- Remove the two 10 mm mounting bolts from the left gearbox.
- Move the steering gearbox (A) between the body and front subframe toward the left, and remove the steering gearbox.
Scheme 114
- Cylinder end seal remover attachment 07TAF-SZ50100
- Driver 07749-0010000
- Attachment, 42 x 47 mm 07746-0010300
- Piston seal ring guide 07lAG-SM4010A or 07lAG-SM40100
- Piston seal ring sizing tool 07lAG-SM4020A or 07lAG-SM40200
- Pincer Oetiker 1098, or equivalent, commercially available
Note. Refer to the Exploded View as needed during the following procedure.
Front hub dis/assembly tool 07965-SA50500
Scheme 115
Scheme 116
- Remove the boot from the tie-rod end, and wipe the old grease off the ball pin.
- Pack the lower area of the ball pin (A) with multipurpose grease.
- Pack the interior of the new boot (B) and lip (C) with multipurpose grease. Note these items when installing new grease: Keep grease off the boot installation section (D) and the tapered section (E) if the ball pin. Do not allow dust, dirt, or other foreign materials to enter the boot.
- Install the new boot (A) using the special tool. The boot must not have a gap at the boot installation sections (B). After installing the boot, check the ball pin tapered section for grease contamination, and wipe it if necessary.
