Entry Lights Control System Honda Odyssey I

Interior/illumination Lights 6 illustrations ~1120 words

Scheme 17

Scheme 17: Component Location Index
Scheme 17: Component Location Index

Scheme 18

Scheme 18: Circuit Diagram
Scheme 18: Circuit Diagram

Control Unit Input Test

Note. Make sure the ignition switch is OFF before disconnecting the driver's under-dash fuse/relay box connectors.

Scheme 19

Scheme 19: Control Unit Input Test
Scheme 19: Control Unit Input Test

Scheme 20

Scheme 20
Scheme 20
  1. Before testing the entry light control functions, troubleshoot the multiplex integrated control system using B-CAN System Diagnosis Test Mode A (see «TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A»(ref-220996-S18207449512006022200000) ). Multiplex Integrated Control Unit
  2. Remove the left kick panel (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(ref-220969-S01393579752006022200000) ).
  3. Disconnect the driver's under-dash fuse/relay box connectors. NOTE: All connector views are wire side of female terminals.
  4. Inspect the connector terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 5.
  5. With the driver's under-dash fuse/relay box connectors still disconnected, make the input tests shown in «CONTROL UNIT INPUT TEST DESCRIPTION»(/honda/odyssey/i-2004-2009/remont/interiorillumination-lights/#entry-lights-control-system) , at the appropriate connector. If any test indicates a problem, find and correct the cause, the recheck the system. If all the input tests prove OK, go to step 6. CONTROL UNIT INPUT TEST DESCRIPTION Cavity Wire Test condition Test: Desired result Possible cause if result is not obtained P8 WHT/BLK Under all conditions Attach to ground: Ignition key light should come on. Blown No. 13 (20 A) fuse in the under-hood fuse/relay box Faulty ignition key light (LED) An open in the wire W4 YEL Interior light switch in middle (DOOR) position Attach to ground: Front and rear map light(s) should come on. Blown No. 6 (7.5 A) fuse in the driver's under-dash fuse/relay box Blown bulb Faulty map light An open in the wire
  6. Reconnect the connectors to the driver's under-dash fuse/relay box. Turn the ignition switch ON (II), and make the input tests shown in «CONTROL UNIT INPUT TEST DESCRIPTION»(/honda/odyssey/i-2004-2009/remont/interiorillumination-lights/#entry-lights-control-system) , at the appropriate connectors on the driver's under-dash fuse/relay box. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 7. CONTROL UNIT INPUT TEST DESCRIPTION Cavity Wire Test condition Test: Desired result Possible cause if result is not obtained P14 BLK Under all conditions Check for voltage to ground: There should be less than 1 V. Poor ground (G401) An open in the wire E9 BLK Under all conditions Check for voltage to ground: There should be less than 1 V. Poor ground (G601) An open in the wire E15 GRN Driver's door open Check for voltage to ground: There should be less than 1 V. Faulty driver's door switch An open in the wire Driver's door closed Check for voltage to ground: There should be 5 V or more Faulty driver's door switch Short to ground H12 LT GRN/RED Front passenger's door open Check for voltage to ground: There should be less than 1 V. Faulty front passenger's door switch An open in the wire Front passenger's door closed Check for voltage to ground: There should be 5 V or more. Faulty front passenger's door switch Short to ground E14 GRN/YEL Left rear door open Check for voltage to ground: There should be less than 1 V. Faulty left rear door switch An open in the wire Left rear door closed Check for voltage to ground: There should be 5 V or more. Faulty left rear door switch Short to ground H13 GRN/WHT Right rear door open Check for voltage to ground: There should be less than 1 V. Faulty right rear door switch An open in the wire Right rear door closed Check for voltage to ground: There should be 5 V or more. Faulty right rear door switch Short to ground P2 RED/WHT Ignition key inserted into the ignition switch Check for voltage to ground: There should be less than 1 V. Poor ground (G501) Faulty ignition key switch An open in the wire Ignition switch OFF and the ignition key removed from the ignition switch Check for voltage to ground: There should be 5 V or more. Faulty ignition key switch Short to ground Door Multiplex Control Unit
  7. Turn the ignition switch OFF.
  8. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-220965-S31837144572006022200000) ).
  9. Disconnect the 23P connector from the door multiplex control unit.
  10. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 11.
  11. Reconnect the connector to the door multiplex control unit. Turn the ignition switch ON (II), and make the input tests shown in «CONTROL UNIT INPUT TEST DESCRIPTION»(/honda/odyssey/i-2004-2009/remont/interiorillumination-lights/#entry-lights-control-system) , at the appropriate connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the MICU must be faulty; replace the driver's under-dash fuse/relay box. CONTROL UNIT INPUT TEST DESCRIPTION Cavity Wire Test condition Test: Desired result Possible cause if result is not obtained 8 WHT/BLU Driver's door key cylinder switch in LOCK Check for voltage to ground: There should be less than 1 V. Faulty driver's door key cylinder switch Poor ground (G601) An open in the wire Short to ground Driver's door key cylinder switch in the neutral position Check for voltage to ground: There should be 5 V or more. Driver's door key cylinder switch in UNLOCK Check for voltage to ground: There should be 5 V or more. 21 WHT Driver's door key cylinder switch in UNLOCK Check for voltage to ground: There should be less than 1 V. Faulty driver's door key cylinder switch Poor ground (G601) An open in the wire Short to ground Driver's door key cylinder switch in the neutral position Check for voltage to ground: There should be 5 V or more. Driver's door key cylinder switch in LOCK Check for voltage to ground: There should be 5 V or more.

Scheme 21

Scheme 21: Ignition Key Switch Test
Scheme 21: Ignition Key Switch Test
  1. Remove the steering column upper and lower covers (see «STEERING COLUMN REMOVAL AND INSTALLATION»(ref-220959-S32189971242006022100000) ).
  2. Disconnect the 6P connector (A).
  3. Check for continuity between the No. 1 and No. 2 terminals. There should be continuity with the key in the ignition switch. There should be no continuity with the key removed.
  4. If the continuity is not as specified, replace the ignition switch.

Scheme 22

Scheme 22: Ignition Key Light Test
Scheme 22: Ignition Key Light Test
  1. Remove the steering column upper and lower covers (see «STEERING COLUMN REMOVAL AND INSTALLATION»(ref-220959-S32189971242006022100000) ).
  2. Disconnect the 6P connector (A).
  3. The LED (B) should come on when power is connected to the No. 6 terminal and ground is connected to No. 5 terminal.
  4. If the LED does not come on, replace the ignition switch.
