Fuse & Relay Identification

  1. 1 - 7.5 Amp Radio Motor Antenna, Cigarette Lighter Relay
  2. 2 - 7.5 Amp Daytime Running Lights Control Unit (Canada)
  3. 3 - 7.5 Amp PGM-FI Main Relay, ECM, Gauge (Brake Check Circuit) Starter Signal
  4. 4 - 7.5 Amp Heater Control Relay, A/C Compressor Clutch Relay, Radiator Fan Control Module, Recirculation Control Motor, Heater Control Panel, Rear Window Defogger Indicator Light, Mode Control Motor, A/C Thermostat, Rear Window Defogger Relay, Blower Motor Relay
  5. 5 - 7.5 Amp Power Mirror
  6. 6 - 30 Amp Spare Fuse
  7. 7 - Not Used
  8. 8 - 10 Amp Spare Fuse
  9. 9 - 30 Amp Front Wiper/Washer, Intermittent Wiper
  10. 10 - 10 Amp Window Relay, Sunroof, Rear Wiper
  11. 11 - 7.5 Amp Alternator, Transmission Control Module (TCM), ELD Unit Radiator Fan Control Module, Cruise Control System (ECU)
  12. 12 - 20 Amp Spare Fuse
  13. 13 - 7.5 Amp Spare Fuse
  14. 14 - 10 Amp SRS (Air Bags)
  15. 15 - 15 Amp PGM-FI Main Relay & Fuel Pump, SRS Unit
  16. 16 - 10 Amp Back-Up Lights, Gauge & Warning/Indicator Lights, Shift Lever Position Indicator, Shift Lock Solenoid, Safety Indicator, Vehicle Speed Sensor (VSS), Clock Turn Signal Lights/Relay, Integrated Control Unit
  17. 17 - 15 Amp Spare Fuse

Scheme 1

Scheme 1: UNDERHOOD FUSE PANEL IDENTIFICATION

Relay Identification

  1. A - Cooling Fan
  2. B - Headlight Dimmer
  3. C - Power Windows
  4. D - Head Lights

Fuse & Circuit Breaker Identification

  1. 1 - 20 Amp Radiator Fan Motor
  2. 2 - 15 Amp Right Headlight
  3. 3 - 15 Amp Left Headlight
  4. 4 - 30 Amp Rear Defroster
  5. 5 - 50 Amp Ignition Switch
  6. 6 - 20 Amp Right Rear Power Window Motor
  7. 7 - 20 Amp Right Front Power Window Motor
  8. 8 - 30 Amp Sun Roof (EX)
  9. 9 - 20 Amp A/C Condenser Fan Motor, A/C Compressor Clutch Relay Cooling Fan Timer Unit
  10. 10 - 7.5 Amp Radio (Backup), Clock, ECM, Transmission Control Module
  11. 11 - 20 Amp Left Rear Power Window Motor & Switch
  12. 12 - 20 Amp Left Front Power Window Motor & Switch
  13. 13 - 10 Amp ECU (Injector) (ECM)
  14. 14 - 20 Amp Power Door Lock Control Unit
  15. 15 - 15 Amp Daytime Running Lights (Canada)
  16. 16 - 15 Amp Small Light
  17. 17 - 7.5 Amp Dome Light, Courtesy Lights, Cigarette Lighter, Trunk Light Power Antenna, Integrated Control Unit
  18. 18 - 20 Amp Power Seat Height Motor
  19. 19 - 15 Amp Radio, Cigarette Lighter
  20. 20 - 15 Amp Stop Light, Horn
  21. 21 - 10 Amp Hazard
  22. 22 - 40 Amp Heater Blower
  23. 23 - 40 Amp Wiper
  24. 24 - 100 Amp Battery, Power Distribution

Scheme 2

Scheme 2: ABS FUSE PANEL IDENTIFICATION
  1. 1 - 40 Amp ABS Motor
  2. 2 - 20 Amp ABS B1
  3. 3 - 15 Amp ABS B2
  4. 4 - 10 Amp ABS Unit
