Deployment Tool Check

  1. Connect the yellow clips to both switch protector handles on the tool.
  2. Then connect the red lead to the positive battery post and the black lead to the negative battery post.
  3. Push the operation switch: The green light should come on, indicating that the tool is operating properly and is ready for use. If the red light stays on, the tool is faulty, and another one must be used for the procedure.
  4. Disconnect the tool clips and connectors from the protector handles and the 12 volt battery.

Scheme 276

Scheme 276: Removal
Scheme 276: Removal

Scheme 277

Scheme 277
Scheme 277

Scheme 278

Scheme 278
Scheme 278
  1. Make sure the front wheels are aligned straight ahead.
  2. Do the 12 volt battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(ref-513168-S03188703672012110700000) ), then wait at least 3 minutes before starting work.
  3. Remove the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(ref-513177-S26501192022012110700000) ).
  4. Disconnect the cable reel subharness 20P connector (A) from the cable reel, then remove the steering wheel bolt (B).
  5. Confirm that the front wheels point straight ahead, then remove the steering wheel with a steering wheel puller (see step 5 «STEERING WHEEL REMOVAL»(ref-513156-S09353438412012110700000) ). Do not tap on the steering wheel or steering column shaft when removing the steering wheel.
  6. Remove the upper and lower column covers (see «COLUMN COVER REMOVAL/INSTALLATION»(ref-513196-S12359952412012110700000) ).
  7. Disconnect the dashboard wire harness 4P connector (A) from the cable reel 4P connector (B), then disconnect the dashboard wire harness 20P connector (C) from the cable reel (D).
  8. Release the lock tab (A) under the cable reel connector with a 90° hook shaped tool (B). Slide the tool below the cable reel connector just above the lock tab. Release the lower lock tab (C), and slide the cable reel off the column.

Scheme 279

Scheme 279: Installation
Scheme 279: Installation

Scheme 280

Scheme 280
Scheme 280

Scheme 281

Scheme 281
Scheme 281

Scheme 282

Scheme 282
Scheme 282

Scheme 283

Scheme 283
Scheme 283
  1. Before installing the steering wheel, make sure the front wheels are aligned straight ahead.
  2. Do the 12 volt battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(ref-513168-S03188703672012110700000) ), then wait at least 3 minutes.
  3. Set the turn signal canceling sleeve (A) so that the tabs (B) are aligned vertically.
  4. Carefully install the cable reel (A) on the steering column shaft. Then connect dashboard wire harness 20P connector (B) to the cable reel, and connect the cable reel 4P connector (C) to the dashboard wire harness 4P connector (D).
  5. Install the upper and lower column covers (see «COLUMN COVER REMOVAL/INSTALLATION»(ref-513196-S12359952412012110700000) ).
  6. Before installing the steering wheel, make sure the front wheels are pointing ahead, then center the cable reel (A). Do this by first rotating the cable reel clockwise until it stops. Then rotate it counterclockwise (about three turns) until the arrow mark (B) on the cable reel label points straight up.
  7. Position the two tabs (A) of the turn signal canceling sleeve (B) as shown, and install the steering wheel on to the steering column shaft, making sure the steering wheel hub (C) engages the pins (D) of the cable reel and tabs of the turn signal canceling sleeve. Do not tap on the steering wheel or steering column shaft when installing the steering wheel.
  8. Install the steering wheel bolt (A), and tighten it to the specified torque, then connect the cable reel subharness 20P connector (B) to the cable reel.
  9. Install the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(ref-513177-S26501192022012110700000) ).
  10. Do the 12 volt battery terminal reconnection procedure (see «RECONNECTION»(ref-513168-S09107234022012110700000) ).
  11. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(ref-513177-S34198896262012110700000) ).
  12. After installing the cable reel, confirm proper system operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds, and then goes off. Make sure the horn and turn signal switches work properly. Make sure the steering wheel switches work properly.
  13. After installation, check the steering wheel spoke angle. If the steering spoke angles to the right and left are not equal (steering wheel is not centered), correct the engagement of the steering wheel/column shaft splines.

Scheme 284

Scheme 284: Removal
Scheme 284: Removal
  1. Do the 12 volt battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(ref-513168-S03188703672012110700000) ), then wait at least 3 minutes before starting work.
  2. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(ref-513202-S39188521932012110700000) ).
  3. Remove the heater joint duct (see step 7 «DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION»(ref-513196-S37894156082012110700000) ).
  4. Disconnect SRS unit connectors (A) from the SRS unit. NOTE: The SRS unit connectors have lever locks. Release the locks before disconnecting the connectors (see «LEVER-LOCKED CONNECTOR»(ref-513177-S39755598732012110700000) ).
  5. Remove the TORX bolts (B) using a TORX T30 bit, then pull out the SRS unit.

Scheme 285

Scheme 285: Installation
Scheme 285: Installation
  1. Install the SRS unit (A) with new TORX bolts (B), then connect the SRS unit connectors (C) to the SRS unit; push them into position until they click and the lever locks are fully secured (see «LEVER-LOCKED CONNECTOR»(ref-513177-S39755598732012110700000) ). NOTE: Be sure the SRS unit is sitting squarely against its bracket before torquing the TORX bolts.
  2. Do the 12 volt battery terminal reconnection procedure (see «RECONNECTION»(ref-513168-S09107234022012110700000) ).
  3. Make sure the SRS unit has the latest software. If it does not have the latest, update the software in the SRS unit (see «SRS UNIT UPDATE»(ref-513177-S41979510162012110700000) ).
  4. Do the front passenger's weight sensor initialization (see «FRONT PASSENGER'S WEIGHT SENSOR INITIALIZATION»(ref-513177-S02973184092012110700000) ).
  5. Do the ODS unit operation check (see «ODS UNIT OPERATION CHECK»(ref-513177-S15716667732012110700000) ).
  6. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
  7. Reinstall all removed parts.

Scheme 286

Scheme 286: Removal
Scheme 286: Removal
  1. Do the 12 volt battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(ref-513168-S03188703672012110700000) ), then wait at least 3 minutes before starting work.
  2. Slide the front seat forward fully.
  3. Remove the B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(ref-513199-S23204921682012110700000) ).
  4. Disconnect the floor wire harness 4P connector (A) from the side impact sensor (first) (B).
  5. Remove the TORX bolt (C) using a TORX T30 bit, then remove the side impact sensor (first).

Scheme 287

Scheme 287: Installation
Scheme 287: Installation
  1. Install the side impact sensor (first) with a new TORX bolt (A), using a TORX T30 bit. Connect the floor wire harness 4P connector (B) to the side impact sensor (first) (C).
  2. Do the 12 volt battery terminal reconnection procedure (see «RECONNECTION»(ref-513168-S09107234022012110700000) ).
  3. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(ref-513177-S34198896262012110700000) ).
  4. Confirm proper. SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
  5. Reinstall all removed parts.

Scheme 288

Scheme 288: Removal
Scheme 288: Removal
  1. Do the 12 volt battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(ref-513168-S03188703672012110700000) ), then wait at least 3 minutes before starting work.
  2. Remove the cargo area side trim panel (see «TRIM REMOVAL/INSTALLATION - CARGO AREAS»(ref-513199-S36077582502012110700000) ).
  3. Disconnect the wire harness 2P connector (A) from the side impact sensor (second) (B).
  4. Remove the TORX bolt (C) using a TORX T30 bit, then remove the side impact sensor (second).

Scheme 289

Scheme 289: Installation
Scheme 289: Installation
  1. Install the side impact sensor (second) with a new TORX bolt (A), using a TORX T30 bit. Connect the wire harness 2P connector (B) to the side impact sensor (second) (C).
  2. Do the 12 volt battery terminal reconnection procedure (see «RECONNECTION»(ref-513168-S09107234022012110700000) ).
  3. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(ref-513177-S34198896262012110700000) ).
  4. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
  5. Reinstall all removed parts.

Scheme 290

Scheme 290: Removal
Scheme 290: Removal
  1. Do the 12 volt battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(ref-513168-S03188703672012110700000) ), then wait at least 3 minutes before starting work.
  2. Remove the rear seat cushion (see «REAR SEAT REMOVAL/INSTALLATION»(ref-513197-S37475010872012110700000) ).
  3. Pull out the carpet as needed.
  4. Remove the two bolts (A) and the rear safing sensor cover (B).
  5. Disconnect the floor wire harness 2P connector (C) from the rear safing sensor (D). Remove the TORX bolt (E) using a TORX T30 bit, then remove the rear safing sensor.

Scheme 291

Scheme 291: Installation
Scheme 291: Installation
  1. Install the rear safing sensor with a new TORX bolt (A), using a TORX T30 bit. Connect the floor wire harness 2P connector (B) to the rear safing sensor(C).
  2. Install the rear safing sensor cover (D) with two bolts (E).
  3. Do the 12 volt battery terminal reconnection procedure (see «RECONNECTION»(ref-513168-S09107234022012110700000) ).
  4. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(ref-513177-S34198896262012110700000) ).
  5. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
  6. Install all removed parts.
