Engine Assembly: Removal & Installation Honda Insight ZE2 рестайлинг

Mechanical 74 illustrations ~3438 words

Engine Removal

Special Tools Required

  1. Universal Lifting Eyelet 07AAK-SNAA120
  2. Engine Support Hanger, A and Reds AAR-T1256*

*Available through the Honda Tool and Equipment Program 888-424-6857

Note. IMA components are located in this area. The IMA is a high-voltage system. You must be familiar with the IMA system before working on or around it. Make sure you have read the IMA service precaution before doing repairs or service (see SERVICE PRECAUTIONS ). Use fender covers to avoid damaging painted surfaces. To avoid damaging the wiring and terminals, unplug the wiring connectors carefully while holding the connector portion. Mark all wiring and hoses to avoid misconnection at reassembly. Also, be sure that they do not contact other wiring or hoses, or interfere with other parts.

Scheme 136

Scheme 136
Scheme 136

Scheme 137

Scheme 137
Scheme 137

Scheme 138

Scheme 138
Scheme 138

Scheme 139

Scheme 139
Scheme 139

Scheme 140

Scheme 140
Scheme 140

Scheme 141

Scheme 141
Scheme 141

Scheme 142

Scheme 142
Scheme 142

Scheme 143

Scheme 143
Scheme 143

Scheme 144

Scheme 144
Scheme 144

Scheme 145

Scheme 145
Scheme 145

Scheme 146

Scheme 146
Scheme 146

Scheme 147

Scheme 147
Scheme 147

Scheme 148

Scheme 148
Scheme 148

Scheme 149

Scheme 149
Scheme 149

Scheme 150

Scheme 150
Scheme 150

Scheme 151

Scheme 151
Scheme 151

Scheme 152

Scheme 152
Scheme 152

Scheme 153

Scheme 153
Scheme 153

Scheme 154

Scheme 154
Scheme 154

Scheme 155

Scheme 155
Scheme 155

Scheme 156

Scheme 156
Scheme 156
  1. Turn the battery module switch OFF (see «DISCONNECTING THE MOTOR POWER CABLE CONNECTOR FROM THE MOTOR STATOR»(ref-513150-S38565231862012110700000) ).
  2. Before removing the engine/transmission, read the Service Precautions for the IMA System (see «SERVICE PRECAUTIONS»(ref-513150-S04476901372012110700000) ).
  3. Open the hood, and secure it with the hood support rod (A) in the wide-open position (B).
  4. Relieve fuel pressure (see «FUEL PRESSURE RELIEVING»(ref-513162-S11991841742012110700000) ).
  5. Do the 12 volt battery removal procedure (see «RECONNECTION»(ref-513168-S09107234022012110700000) ).
  6. Remove the cowl cover and the under-cowl panel (see «COWL COVER REPLACEMENT»(ref-513174-S22314343132012110700000) ).
  7. Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-513163-S20686336082012110700000) ).
  8. Disconnect the battery cables (A) from the battery terminal fuse box.
  9. Remove the harness clamps (B).
  10. Remove the harness clamp (A).
  11. Remove the two bolts (B) and loosen the two bolts (C), then remove the battery base (D).
  12. Remove the PCM cover (A).
  13. Disconnect the PCM connectors (A) and the engine wire harness connectors (B).
  14. Remove the harness clamp (C) and the harness holder (D), then remove the PCM (E).
  15. Disconnect the EVAP canister hose (A) and the brake booster vacuum hose (B).
  16. Remove the fuel feed hose clamp bracket (A) and the quick-connect fitting cover (B), then disconnect the fuel feed hose (C) (see «FUEL LINE/QUICK-CONNECT FITTING REMOVAL»(ref-513162-S01599489992012110700000) ).
  17. Disconnect the secondary HO2S connector (A), then remove the secondary HO2S harness from the clamps (B).
  18. Remove the steering joint cover, then disconnect the steering joint from the steering gearbox pinion shaft (see step 5 on «REMOVAL»(ref-513192-S27645180292012110700000) ). NOTE: Hold the steering wheel in the steering wheel holder tool. Hold the lower slide shaft on the column with a piece of wire between the joint yokes.
  19. Remove the radiator cap. NOTE: Wait until the engine is cool, then carefully remove the radiator cap.
  20. Raise the vehicle on the lift.
  21. Remove the front wheels.
  22. Remove the splash shield (see «SPLASH SHIELD REPLACEMENT»(ref-513179-S41212899722012110700000) ).
  23. Remove the drive belt (see «DRIVE BELT REPLACEMENT»(ref-513159-S05522561372012110700000) ).
  24. Loosen the drain plug in the radiator, and drain the engine coolant (see «COOLANT CHECK»(ref-513159-S17284160492012110700000) ).
  25. Drain the engine oil (see «ENGINE OIL REPLACEMENT»(ref-513154-S30056503812012110700000) ).
  26. Drain the transmission fluid (see «CVT FLUID REPLACEMENT»(ref-513160-S20302651322012110700000) ).
  27. Remove the secondary HO2S harness from the clamp (A).
  28. Remove the under-floor TWC (B).
  29. Remove the stabilizer links from the stabilizer (see «STABILIZER LINK REMOVAL/INSTALLATION»(ref-513180-S31760833192012110700000) ).
  30. Separate the knuckles from the lower arms (see step 4 on «LOWER ARM REMOVAL/INSTALLATION»(ref-513180-S20168329092012110700000) ).
  31. Separate the tie-rod end ball joint from the knuckles (see step 9 on «KNUCKLE/HUB/WHEEL BEARING REPLACEMENT»(ref-513180-S23540531142012110700000) ).
  32. Disconnect the EPS motor connector and the torque sensor connector (see step 18 on «STEERING GEARBOX REMOVAL AND INSTALLATION»(ref-513192-S41212808702012110700000) ).
  33. Remove the driveshaft heat shield.
  34. Remove the driveshafts (see «DRIVESHAFT INSPECTION»(ref-513158-S38017538132012110700000) ). Coat all precision-finished surfaces with clean engine oil. Tie a plastic bags over the driveshaft ends.
  35. Remove the A/C compressor without disconnecting the A/C hoses. Do not bend the A/C hoses excessively. NOTE: Hang the A/C compressor with a wire tie.
  36. Lower the vehicle on the lift.
  37. Remove the radiator (see «RADIATOR REPLACEMENT»(ref-513159-S05860812372012110700000) ).
  38. Disconnect the heater hoses (A).
  39. Disconnect the IMA power cable connector and the harness clamp. NOTE: Make sure you have read the IMA system service precautions (see «SERVICE PRECAUTIONS»(ref-513150-S04476901372012110700000) ).
  40. Remove the shift cable (see «SHIFT CABLE REPLACEMENT»(ref-513160-S03261235312012110700000) ).
  41. Remove the canister purge hose (A).
  42. Attach the first universal lifting eyelet (07AAK-SNAA120) to the air cleaner bracket hole (B) with a bolt (C) and a nut (D).
  43. Remove the harness clamp (A) from its clamp bracket (B) located in front of the damper top.
  44. Install the engine support hanger (AAR-T1256). Carefully position the engine support hanger to the vehicle; position both cross-arm foot bases (C) over the harness clamp brackets on both sides, and position both fronts stands (D) on the front bulkhead. Attach the hook (E) to the slotted hole in the first universal lifting eyelet (F), tighten the wing nut (G) by hand, and lift and support the engine/IMA motor/transmission. NOTE: Be careful when working around the windshield.
  45. Raise the vehicle on the lift.
  46. Support the transmission with a transmission jack and wood block under the transmission.
  47. Remove the torque rod (A). NOTE: Make sure the tab (B) on the bolt head aligned with the guide (C) on the front subframe.
  48. Remove the transmission jack and wood block from under the transmission.
  49. Support the front subframe with a transmission jack and wood block under the front subframe.
  50. Remove the front subframe mounting bolts.
  51. Lower the front subframe and steering gearbox as an assembly by lowering the jack slowly, then remove the assembly from under the vehicle.
  52. Lower the vehicle on the lift.
  53. Attach the second universal lifting eyelet to the cam chain case.
  54. Attach a chain hoist to the second universal lifting eyelet (A) and the transmission hanger (B), then lift the engine/IMA motor/transmission until it is securely supported by the chain hoist, then remove the engine support hanger and the first universal lifting eyelet. NOTE: Wrap the VSA modulator-control unit with the clean shop towel.
  55. Remove the harness holders (A).
  56. Remove the transmission mount bolts (B), and nuts (C), then remove the transmission mount bracket (D).
  57. Remove the ground cable (A), then remove the side engine mount/bracket assembly (B).
  58. Check that the engine/IMA motor/transmission is completely free of the vacuum hoses, the fuel hoses, the coolant hoses, and the electrical wiring.
  59. Slowly lower the engine/IMA motor/transmission about 150 mm (5.91 in). Check once again that all the hoses and the electrical wiring are disconnected and free from the engine/IMA motor/transmission, then lower it all the way and support it.
  60. Disconnect the chain hoist from the engine/IMA motor/transmission, then remove the second universal lifting eyelet.
  61. Raise the vehicle, and remove the engine/IMA motor/transmission from under the vehicle.

Engine Installation

Special Tools Required

  1. Universal Lifting Eyelet 07AAK-SNAA120
  2. Engine Support Hanger, A and Reds AAR-T1256*

*Available through the Honda Tool and Equipment Program 888-424-6857

Note. IMA components are located in this area. The IMA is a high-voltage system. You must be familiar with the IMA system before working on or around it. Make sure you have read the IMA service precaution before doing repairs or service (see SERVICE PRECAUTIONS ).

Scheme 157

Scheme 157
Scheme 157

Scheme 158

Scheme 158
Scheme 158

Scheme 159

Scheme 159
Scheme 159

Scheme 160

Scheme 160
Scheme 160

Scheme 161

Scheme 161
Scheme 161

Scheme 162

Scheme 162
Scheme 162

Scheme 163

Scheme 163
Scheme 163

Scheme 164

Scheme 164
Scheme 164

Scheme 165

Scheme 165
Scheme 165

Scheme 166

Scheme 166
Scheme 166

Scheme 167

Scheme 167
Scheme 167

Scheme 168

Scheme 168
Scheme 168

Scheme 169

Scheme 169
Scheme 169

Scheme 170

Scheme 170
Scheme 170

Scheme 171

Scheme 171
Scheme 171

Scheme 172

Scheme 172
Scheme 172

Scheme 173

Scheme 173
Scheme 173

Scheme 174

Scheme 174
Scheme 174

Scheme 175

Scheme 175
Scheme 175

Scheme 176

Scheme 176
Scheme 176

Scheme 177

Scheme 177
Scheme 177

Scheme 178

Scheme 178
Scheme 178

Scheme 179

Scheme 179
Scheme 179

Scheme 180

Scheme 180
Scheme 180
  1. Raise the vehicle on the lift, and position the engine/IMA motor/transmission under the vehicle. Be sure that they are properly aligned. Carefully lower the vehicle until the engine/IMA motor/transmission are properly positioned in the engine compartment. Make sure the vehicle is not resting on any part of the engine/IMA motor/transmission. Support the engine/IMA motor/transmission with a chain hoist (A) and carefully raise the engine/IMA motor/transmission into place. NOTE: Attach the first universal lifting eyelet (07AAK-SNAA120) to the cam chain case (see step 53 ). Reinstall the mounting bolts and support nuts in the sequence given in the following steps. Failure to follow this sequence may cause excessive noise and vibration, and reduce engine mount life. Wrap the VSA modulator-control unit with the clean shop towel.
  2. Install the side engine mount/bracket assembly (A), then tighten the new side engine mount/bracket assembly mounting bolts (B).
  3. Loosely install the new side engine mount/bracket assembly mounting nuts (C).
  4. Install the ground cable (D).
  5. Install the transmission mount bracket (A), and loosely install the new transmission mount bracket mounting bolts (B) and nuts (C).
  6. Install the harness holders (D).
  7. Attach the second universal lifting eyelet (A) to the air cleaner bracket hole (B) with a bolt (C) and a nut (D).
  8. Install the engine support hanger (AAR-T1256), then attach the hook (A) to the slotted hole in the second universal lifting eyelet (B). Tighten the wing nut (C) by hand to lift and support the engine/IMA motor/transmission. NOTE: Be careful when working around the windshield.
  9. Remove the chain hoist from the engine/IMA motor/transmission.
  10. Remove the first universal lifting eyelet from the cam chain case.
  11. Raise the vehicle on the lift.
  12. Support the front subframe with a transmission jack and wood block under the front subframe.
  13. Install the front subframe, then loosely install the new front subframe mounting bolts. NOTE: Be sure that the pinion shaft grommet is in place securely. Make sure the pinion shaft grommet is not turned up. Incorrect installation can cause leakage of water or mud, and noise. Take care not to damage the lower arm ball joint boot with the edge of the knuckle, etc.
  14. Align the front subframe, then torque the subframe mounting bolts to specification (see «SUBFRAME REPLACEMENT»(ref-513181-S33454181472012110700000) ).
  15. Remove the transmission jack and wood block from the front subframe.
  16. Support the transmission with a transmission jack and wood block under the transmission.
  17. Install the torque rod (A). Install the bolt with the tab (B) on the bolt head aligned with the guide (C) on the front subframe, then loosely install the new torque rod mounting bolt and nut (D). NOTE: Be sure to install the torque rod with the "UP" mark facing up.
  18. Remove the transmission jack and wood block from under the transmission.
  19. Lower the vehicle on the lift.
  20. Remove the engine support hanger, and install the harness clamp in its bracket location in front of the left damper top (see step 43 ).
  21. Remove the second universal lifting eyelet (A), and install the canister purge hose (B).
  22. Tighten the side engine mount/bracket assembly mounting nuts.
  23. Tighten the transmission mount mounting bolts and nuts in the numbered sequence shown.
  24. Raise the vehicle on the lift.
  25. Tighten the torque rod mounting bolt and nut in the numbered sequence shown.
  26. Install the driveshafts (see «DRIVESHAFT INSTALLATION»(ref-513158-S22460954482012110700000) ).
  27. Install the driveshaft heat shield.
  28. Connect the EPS motor connector and torque sensor connector (see step 13 on «INSTALLATION»(ref-513192-S25397232202012110700000) ).
  29. Connect the tie-rod end ball joints to the knuckles (see «KNUCKLE/HUB/WHEEL BEARING REPLACEMENT»(ref-513180-S23540531142012110700000) ).
  30. Connect the lower arms to the knuckles (see step 7 on «LOWER ARM REMOVAL/INSTALLATION»(ref-513180-S20168329092012110700000) ).
  31. Install the stabilizer links to the stabilizer (see «STABILIZER LINK REMOVAL/INSTALLATION»(ref-513180-S31760833192012110700000) ).
  32. Install the A/C compressor.
  33. Install the under-floor TWC (A) and the secondary HO2S harness to the clamp (B). NOTE: Use new gaskets (C) and new self-locking nuts (D).
  34. Install the splash shield (see «SPLASH SHIELD REPLACEMENT»(ref-513179-S41212899722012110700000) ).
  35. Lower the vehicle on the lift.
  36. Connect the IMA power cable connector and harness clamp. NOTE: Make sure you have read the IMA system service precautions (see «SERVICE PRECAUTIONS»(ref-513150-S04476901372012110700000) ).
  37. Install the shift cable (see «SHIFT CABLE REPLACEMENT»(ref-513160-S03261235312012110700000) ).
  38. Connect the heater hoses (A).
  39. Install the drive belt (see «DRIVE BELT REPLACEMENT»(ref-513159-S05522561372012110700000) ).
  40. Install the radiator (see «RADIATOR REPLACEMENT»(ref-513159-S05860812372012110700000) ).
  41. Remove the steering wheel holder tool, then connect the steering joint onto the steering gearbox pinion shaft (see step 24 on «INSTALLATION»(ref-513192-S25397232202012110700000) ).
  42. Install the steering joint cover (see step 27 on «INSTALLATION»(ref-513192-S25397232202012110700000) ).
  43. Connect the secondary HO2S connector (A), then install the secondary HO2S harness to the clamps (B).
  44. Connect the fuel feed hose (A) (see «FUEL LINE/QUICK-CONNECT FITTING INSTALLATION»(ref-513162-S21886125002012110700000) ), then install the quick-connect fitting cover (B) and the fuel feed hose clamp bracket (C).
  45. Connect the EVAP canister hose (A) and the brake booster vacuum hose (B).
  46. Install the PCM (A), then install the harness holder (B) and the harness clamp (C).
  47. Connect the engine wire harness connectors (D) and the PCM connectors (E).
  48. Install the PCM cover (A).
  49. Install the battery base (A), then install the harness clamp (B).
  50. Connect the battery cables (A) to the battery terminal fuse box.
  51. Install the harness clamps (B).
  52. Install the front wheels.
  53. Install the cowl cover and the under-cowl panel (see «COWL COVER REPLACEMENT»(ref-513174-S22314343132012110700000) ).
  54. Do the 12 volt battery installation procedure (see «RECONNECTION»(ref-513168-S09107234022012110700000) ).
  55. Turn the battery module switch ON (see «DISCONNECTING THE MOTOR POWER CABLE CONNECTOR FROM THE MOTOR STATOR»(ref-513150-S38565231862012110700000) ).
  56. Refill the transmission with CVT fluid (CVTF) (see «CVT FLUID REPLACEMENT»(ref-513160-S20302651322012110700000) ).
  57. Install the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-513163-S20686336082012110700000) ).
  58. Move the shift lever to each gear, and verify that the A/T gear position indicator follows the transmission range switch.
  59. Inspect for fuel leaks. Turn the ignition switch to ON (II) (do not operate the starter) so the fuel pump runs for about 2 seconds and pressurizes the fuel line. Repeat this operation three times, then check for fuel leakage at any point in the fuel line.
  60. Refill the radiator with engine coolant, and bleed air from the cooling system (see step 8 on «COOLANT REPLACEMENT»(ref-513159-S08850821602012110700000) ).
  61. Refill the engine with engine oil (see step 6 on «ENGINE OIL REPLACEMENT»(ref-513154-S30056503812012110700000) ).
  62. Do the PCM reset procedure (see «IF THE MIL DID NOT STAY ON»(ref-513169-S20882293332012110700000) ).
  63. Do the CKP pattern clear/CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-513169-S27253414082012110700000) ).
  64. Inspect the idle speed (see «IDLE SPEED INSPECTION»(ref-513173-S03126675442012110700000) ).
  65. Inspect the ignition timing (see «IGNITION TIMING INSPECTION»(ref-513165-S36048888522012110700000) ).

Scheme 181

Scheme 181: Side Engine Mount Replacement
Scheme 181: Side Engine Mount Replacement

Scheme 182

Scheme 182
Scheme 182

Scheme 183

Scheme 183
Scheme 183

Scheme 184

Scheme 184
Scheme 184

Scheme 185

Scheme 185
Scheme 185

Scheme 186

Scheme 186
Scheme 186
  1. Support the engine with a jack and a wood block under the oil pan.
  2. Remove the ground cable (A), then remove the side engine mount bracket (B).
  3. Remove the side engine mount (C).
  4. Install the side engine mount, then tighten the new side engine mount mounting bolts (D).
  5. Install the side engine mount bracket, then tighten the new side engine mount bracket mounting bolt (E).
  6. Loosely install the new side engine mount bracket mounting nuts (F), then install the ground cable.
  7. Remove the jack and wood block from under the oil pan.
  8. Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-513163-S20686336082012110700000) ).
  9. Loosen the transmission mount bracket mounting bolts and nuts (A).
  10. Raise the vehicle on the lift.
  11. Loosen the torque rod mounting bolt and nut (A).
  12. Lower the vehicle on the lift.
  13. Tighten the side engine mount/bracket assembly mounting nuts.
  14. Tighten the transmission mount mounting bolts and nuts in the numbered sequence shown.
  15. Raise the vehicle on the lift.
  16. Tighten the torque rod mounting bolt and nut in the numbered sequence shown.
  17. Lower the vehicle on the lift.
  18. Install the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-513163-S20686336082012110700000) ).

Scheme 187

Scheme 187: Transmission Mount Replacement
Scheme 187: Transmission Mount Replacement

Scheme 188

Scheme 188
Scheme 188

Scheme 189

Scheme 189
Scheme 189

Scheme 190

Scheme 190
Scheme 190

Scheme 191

Scheme 191
Scheme 191

Scheme 192

Scheme 192
Scheme 192

Scheme 193

Scheme 193
Scheme 193

Scheme 194

Scheme 194
Scheme 194

Scheme 195

Scheme 195
Scheme 195

Scheme 196

Scheme 196
Scheme 196
  1. Do the 12 volt battery removal procedure (see «RECONNECTION»(ref-513168-S09107234022012110700000) ).
  2. Turn the battery module switch OFF (see «DISCONNECTING THE MOTOR POWER CABLE CONNECTOR FROM THE MOTOR STATOR»(ref-513150-S38565231862012110700000) ).
  3. Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-513163-S20686336082012110700000) ).
  4. Disconnect the battery cables (A) from the battery terminal fuse box.
  5. Remove the harness clamps (B).
  6. Remove the harness clamp (A). Remove the two bolts (B) and loosen the two bolts (C), then remove the battery base (D).
  7. Remove the PCM (see «PCM REPLACEMENT»(ref-513153-S08243124262012110700000) ).
  8. Disconnect the IMA power cable connector and the harness clamp (see step 39 ).
  9. Support the transmission with a jack and a wood block under the transmission.
  10. Remove the harness holders (A).
  11. Remove the transmission mount bolts (B) and nuts (C), then remove the transmission mount bracket (D).
  12. Remove the transmission mount.
  13. Install the transmission mount, and loosely install the new transmission mount mounting bolts, then tighten the transmission mount mounting bolts in the numbered sequence shown.
  14. Install the transmission mount bracket (A), and loosely install the new transmission mount bracket mounting bolts (B) and nuts (C).
  15. Install the harness holders (D).
  16. Remove the jack and wood block from under the transmission.
  17. Raise the vehicle on the lift.
  18. Loosen the torque rod mounting bolt and nut (A).
  19. Lower the vehicle on the lift.
  20. Tighten the transmission mount mounting bolts and nuts in the numbered sequence shown.
  21. Raise the vehicle on the lift.
  22. Tighten the torque rod mounting bolt and nut in the numbered sequence shown.
  23. Install the battery base (A), then install the harness clamp (B).
  24. Connect the battery cables (A) to the battery terminal fuse box.
  25. Install the harness clamps (B).
  26. Install the PCM (see «PCM REPLACEMENT»(ref-513153-S08243124262012110700000) ).
  27. Connect the IMA power cable connector and the harness clamp (see step 36 ).
  28. Turn the battery module switch ON (see «DISCONNECTING THE MOTOR POWER CABLE CONNECTOR FROM THE MOTOR STATOR»(ref-513150-S38565231862012110700000) ).
  29. Do the 12 volt battery installation procedure (see «RECONNECTION»(ref-513168-S09107234022012110700000) ).
  30. Install the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-513163-S20686336082012110700000) ).

Scheme 197

Scheme 197: Torque Rod Replacement
Scheme 197: Torque Rod Replacement

Scheme 198

Scheme 198
Scheme 198
  1. Raise the vehicle on the lift.
  2. Support the transmission with a transmission jack and a wood block under the transmission.
  3. Remove the torque rod (A). NOTE: Make sure the tab (B) on the bolt head a aligned with the guide C) on the front subframe.
  4. Install the torque rod (A). NOTE: Be sure to install the torque rod with the "UP" mark facing up.
  5. Install the bolt with the tab (B) on the bolt head aligned with the guide (C) on the front subframe, then loosely install the new torque rod mounting bolt and nut.
  6. Remove the transmission jack and wood block from under the transmission.
  7. Tighten the torque rod mounting bolt and nut in the numbered sequence shown.
  8. Lower the vehicle on the lift.

Scheme 199

Scheme 199: Transmission Mount Bracket Replacement
Scheme 199: Transmission Mount Bracket Replacement

Scheme 200

Scheme 200
Scheme 200

Scheme 201

Scheme 201
Scheme 201

Scheme 202

Scheme 202
Scheme 202

Scheme 203

Scheme 203
Scheme 203

Scheme 204

Scheme 204
Scheme 204

Scheme 205

Scheme 205
Scheme 205

Scheme 206

Scheme 206
Scheme 206
  1. Do the 12 volt battery removal procedure (see «RECONNECTION»(ref-513168-S09107234022012110700000) ).
  2. Turn the battery module switch OFF (see «DISCONNECTING THE MOTOR POWER CABLE CONNECTOR FROM THE MOTOR STATOR»(ref-513150-S38565231862012110700000) ).
  3. Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-513163-S20686336082012110700000) ).
  4. Disconnect the battery cables (A) from the battery terminal fuse box.
  5. Remove the harness clamps (B).
  6. Remove the harness clamp (A). Remove the two bolts (B) and loosen the two bolts (C), then remove the battery base (D).
  7. Remove the PCM (see «PCM REPLACEMENT»(ref-513153-S08243124262012110700000) ).
  8. Disconnect the IMA power cable and the harness clamp (see step 39 ).
  9. Support the transmission with a jack and a wood block from under the transmission.
  10. Remove the harness holders (A).
  11. Remove the transmission mount bolts (B) and nuts (C) then remove the transmission mount bracket (D).
  12. Install the transmission mount bracket, and loosely install the new transmission mount bracket mounting bolts and nuts.
  13. Install the harness holders.
  14. Remove the jack and wood block from under the transmission.
  15. Raise the vehicle on the lift.
  16. Loosen the torque rod mounting bolt and nut (A).
  17. Lower the vehicle on the lift.
  18. Tighten the transmission mount mounting bolts and nuts in the numbered sequence shown.
  19. Raise the vehicle on the lift.
  20. Tighten the torque rod mounting bolt and nut in the numbered sequence shown.
  21. Lower the vehicle on the lift.
  22. Install the battery base (A), then install the harness clamp (B).
  23. Connect the battery cables (A) to the battery terminal fuse box.
  24. Install the harness clamps (B).
  25. Install the PCM (see «PCM REPLACEMENT»(ref-513153-S08243124262012110700000) ).
  26. Connect the IMA power cable and the harness clamp (see step 36 ).
  27. Turn the battery module switch ON (see «DISCONNECTING THE MOTOR POWER CABLE CONNECTOR FROM THE MOTOR STATOR»(ref-513150-S38565231862012110700000) ).
  28. Do the 12 volt battery installation procedure (see «RECONNECTION»(ref-513168-S09107234022012110700000) ).
  29. Install the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-513163-S20686336082012110700000) ).

Scheme 207

Scheme 207: Torque Rod Bracket Replacement
Scheme 207: Torque Rod Bracket Replacement

Scheme 208

Scheme 208
Scheme 208

Scheme 209

Scheme 209
Scheme 209
  1. Raise the vehicle on the lift.
  2. Support the transmission with a transmission jack and a wood block under the transmission.
  3. Remove the torque rod (A). NOTE: Make sure the tab (B) on the bolt head aligned with the guide (C) on the front subframe.
  4. Remove the torque rod bracket (A).
  5. Install the torque rod bracket.
  6. Install the torque rod (A). NOTE: Be sure to install the torque rod with the "UP" mark facing up.
  7. Install the bolt with the tab (B) on the bolt head aligned with the guide (C) on the front subframe, then loosely install the new torque rod mounting bolt and nut.
  8. Remove the transmission jack and wood block from under the transmission.
  9. Tighten the torque rod mounting bolt and nut in the numbered sequence shown.
  10. Lower the vehicle on the lift.

More articles — Engine Assembly
