Audio System: Removal & Installation Honda Insight ZE2 рестайлинг

Entertainment Systems 7 illustrations ~354 words

Audio Unit Removal/Installation

SRS components are located in this area. Review the SRS component location (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) in the SRS article before doing repairs or service.

Audio Remote Switch Replacement

SRS components are located in this area. Review the SRS component location (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) in the SRS article before doing repairs or service.

Scheme 152

Scheme 152: Audio Remote Switch Replacement
Scheme 152: Audio Remote Switch Replacement

Scheme 153

Scheme 153
Scheme 153

Scheme 154

Scheme 154
Scheme 154

Scheme 155

Scheme 155
Scheme 155
  1. Remove the steering wheel (see «STEERING WHEEL REMOVAL»(ref-513156-S09353438412012110700000) ).
  2. Remove the screws, and steering wheel rear cover (A).
  3. '11 model, remove the screw (B), and earth terminal (C).
  4. Remove the paddle shifter + (upshift switch) and paddle shifter - (downshift switch) (see «PADDLE SHIFTER + (UPSHIFT SWITCH) OR PADDLE SHIFTER - (DOWNSHIFT SWITCH) REPLACEMENT»(ref-513160-S00963146802012110700000) ).
  5. Remove the screws and the steering wheel trim (A).
  6. Disconnect the connectors, and remove the harness guide (A).
  7. Remove the audio remote switch (A).
  8. Install the audio remote switch in the reverse order of removal.

Scheme 156

Scheme 156: USB Adapter Control Unit Replacement
Scheme 156: USB Adapter Control Unit Replacement
  1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(ref-513202-S39188521932012110700000) ).
  2. Remove the center console armrest (see «CENTER CONSOLE ARMREST REPLACEMENT»(ref-513202-S37950423292012110700000) ).
  3. Remove the console box (see «COMPONENT LOCATION INDEX»(ref-513196-S34907052762012110700000) ).
  4. Disconnect the connector (A) from the USB adapter control unit (B).
  5. Remove the mounting bolts (C) and the USB adapter control unit.
  6. Install the USB adapter control unit in the reverse order of removal.

Scheme 157

Scheme 157: Auxiliary Jack Assembly Replacement
Scheme 157: Auxiliary Jack Assembly Replacement
  1. Remove the center lower trim (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(ref-513196-S07201669662012110700000) ).
  2. Remove the 5P connector (A) from the auxiliary jack assembly (B).
  3. Push out the auxiliary jack assembly from the center lower trim.
  4. Install the auxiliary jack assembly in the reverse order of removal.

Scheme 158

Scheme 158: AM/FM Antenna Replacement
Scheme 158: AM/FM Antenna Replacement
  1. Remove the AM/FM antenna mast (A).
  2. Remove the AM/FM antenna base (B). Remove the C-pillar trim (see «C-PILLAR TRIM»(ref-513199-S40419789852012110700000) ), and disconnect the connector (C). Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(ref-513199-S29276019462012110700000) ), and detach the clips (D). Remove the nut (E) from the AM/FM antenna base, and remove it.
  3. Install the AM/FM antenna in the reverse order of removal.
