Shift Lock System Honda Insight ZE2 рестайлинг

Cvt 13 illustrations ~1982 words

Shift Lock System

The shift lock system prevents the shift lever from mis-shifting. The shift lock solenoid is normally OFF. After starting the engine in P, the shift lever cannot move to any other position from P because the shift lock stop stops the lock pin unless certain conditions are met. When the brake pedal is pressed and the accelerator pedal is not pressed, the PCM commands are shift lock solenoid is ON; the shift lock solenoid plunger in the shift lock solenoid pulls the shift lock stop to release the lock pin. Pressing the shift lever button allows the shift lever to move to any other position. When the brake pedal and the accelerator pedal are pressed at the same time, the PCM commands the solenoid OFF and the shift lock system is locked.

Scheme 319

Scheme 319: Shift Lock System
Scheme 319: Shift Lock System

When the shift lock system does not operate due to mechanical or electrical trouble, you can unlock the shift lock temporarily by inserting the ignition key into the shift lock release hole and pressing the shift lock release. When the shift lock release is pressed, the shift lock stop releases the lock pin, and the shift lever can move to any other position.

Scheme 320

Scheme 320
Scheme 320

Scheme 321

Scheme 321: Circuit Diagram - PCM CVT Control System-Five-position Transmission
Scheme 321: Circuit Diagram - PCM CVT Control System-Five-position Transmission

Scheme 322

Scheme 322
Scheme 322

Scheme 323

Scheme 323: Circuit Diagram - PCM CVT Control System-Six-position Transmission
Scheme 323: Circuit Diagram - PCM CVT Control System-Six-position Transmission

Scheme 324

Scheme 324
Scheme 324

Note. Before you troubleshoot, record all freeze data and any on-board snapshot with the HDS, and review the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). This code is caused by an electrical circuit problem and cannot be caused by a mechanical problem in the transmission.

  1. Turn the ignition switch to ON (II).
  2. Clear the DTC with the HDS.
  3. Block the rear wheels, and raise the front of the vehicle. Make sure it is securely supported, and allow the front wheels to rotate freely, or raise the vehicle on a lift.
  4. Start the engine, disable the VSA by pressing the VSA OFF button, run the vehicle with the shift lever in L, and the engine speed at 4, 500 rpm or higher, then release the accelerator without pressing it again, for at least 6 seconds. Slow down and stop the wheels.
  5. Monitor the OBD STATUS for P0501 in the DTCs MENU with the HDS. Does the HDS indicate FAILED? YES -Replace the vehicle speed sensor (see «VEHICLE SPEED SENSOR REPLACEMENT»(ref-513160-S36177006132012110700000) ), then go to step 6. NO -If the HDS indicates PASSED, intermittent failure, the system is OK at this time. Check for poor connections or loose terminals between the PCM and the vehicle speed sensor. If the HDS indicates NOT COMPLETED, go to step 4 .
  6. Turn the ignition switch to ON (II).
  7. Clear the DTC with the HDS.
  8. Start the engine, disable the VSA by pressing the VSA OFF button, run the vehicle with the shift lever in D, and keep the vehicle at speeds over 25 mph (40 km/h) while monitoring the Output shaft (Driven pulley) Speed rpm in the Data List with the HDS, then release the accelerator without pressing it again, for at least 7 seconds. Slow down and stop the wheels.
  9. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0501 indicated? YES -Check for poor connections or loose terminals between the vehicle speed sensor and the PCM, then go to step 11 . NO -Go to step 10.
  10. Monitor the OBD STATUS for P0501 in the DTCs MENU with the HDS. Does the HDS indicate PASSED? YES -Troubleshooting is complete. If any other Pending or Confirmed DTCs were indicated in step 9 , go to the indicated «DTC'S TROUBLESHOOTING»(ref-513160-S17721622272012110700000) . NO -If the HDS indicates FAILED, check for poor connections or loose terminals between the vehicle speed sensor and the PCM, then go to step 1 . If the HDS indicates NOT COMPLETED, go to step 8 .
  11. Update the PCM if it does not have the latest software (see «PCM UPDATE»(ref-513153-S08553155092012110700000) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-513169-S18138486322012110700000) ).
  12. Start the engine, disable the VSA by pressing the VSA OFF button, run the vehicle with the shift lever in D, and keep the vehicle at speeds over 25 mph (40 km/h) while monitoring the Output shaft (Driven pulley) Speed rpm in the Data List with the HDS, then release the accelerator without pressing it again, for at least 7 seconds.
  13. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0501 indicated? YES -Check for poor connections or loose terminals between the vehicle speed sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-513169-S18138486322012110700000) ), then go to step 12 . If the PCM was substituted, go to step 1 . NO -Go to step 14.
  14. Monitor the OBD STATUS for P0501 in the DTCs MENU with the HDS. Does the HDS indicate PASSED? YES -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-513153-S08243124262012110700000) ). If any other Pending or Confirmed DTCs were indicated in step 13 , go to the indicated «DTC'S TROUBLESHOOTING»(ref-513160-S17721622272012110700000) . NO -If the HDS indicates FAILED, check for poor connections or loose terminals between the vehicle speed sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-513169-S18138486322012110700000) ), then go to step 12 . If the PCM was substituted, go to step 1 . If the HDS indicates NOT COMPLETED, go to step 12 .

Note. Before you troubleshoot, record all freeze data and any on-board snapshot with the HDS, and review the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). This code is caused by an electrical circuit problem and cannot be caused by a mechanical problem in the transmission.

Scheme 325

Scheme 325: DTC P0502: Problem in CVT Speed Sensor Circuit
Scheme 325: DTC P0502: Problem in CVT Speed Sensor Circuit

Scheme 326

Scheme 326
Scheme 326

Scheme 327

Scheme 327
Scheme 327

Scheme 328

Scheme 328
Scheme 328

Scheme 329

Scheme 329
Scheme 329

Scheme 330

Scheme 330
Scheme 330

Scheme 331

Scheme 331
Scheme 331
  1. Check for proper vehicle speed sensor installation (see «VEHICLE SPEED SENSOR REPLACEMENT»(ref-513160-S36177006132012110700000) ). If the sensor is installed incorrectly, reinstall the sensor correctly, then go to step 26 .
  2. Turn the ignition switch to ON (II).
  3. Clear the DTC with the HDS.
  4. Block the rear wheels, and raise the front of the vehicle. Make sure it is securely supported, and allow the front wheels to rotate freely, or raise the vehicle on a lift.
  5. Start the engine, disable the VSA by pressing the VSA OFF button, run the vehicle with the shift lever in D, and the engine speed at 4, 500 rpm or higher, then release the accelerator without pressing it again, for at least 6 seconds. Slow down and stop the wheels.
  6. Monitor the OBD STATUS for P0502 in the DTCs MENU with the HDS. Does the HDS indicate FAILED? YES -Go to step 7. NO -If the HDS indicates PASSED, intermittent failure, the system is OK at this time. Check for poor connections or loose terminals between the PCM and the vehicle speed sensor. If the HDS indicates NOT COMPLETED, go to step 5 .
  7. Turn the ignition switch to LOCK (0).
  8. Jump the SCS line with the HDS.
  9. Disconnect PCM connector C (49P).
  10. Check for continuity between PCM connector terminal C44 and body ground, and between PCM connector terminal C49 and body ground. Is there continuity? YES -Go to step 11. NO -Repair open in the wires between PCM connector terminals C44, C49, and body ground (G101), or repair poor body ground (G101), then go to step 26 .
  11. Connect PCM connector C (49P).
  12. Disconnect the vehicle speed sensor 3P connector.
  13. Turn the ignition switch to ON (II).
  14. Measure the voltage between vehicle speed sensor 3P connector terminal No. 1 and body ground. Is there about 5 V? YES -Go to step 19 . NO -Go to step 15.
  15. Turn the ignition switch to LOCK (0).
  16. Jump the SCS line with the HDS.
  17. Disconnect PCM connector B (49P).
  18. Check for continuity between PCM connector terminal B19 and vehicle speed sensor 3P connector terminal No. 1. Is there continuity? YES -Go to step 32 . NO -Repair an open in the wire between PCM connector terminal B19 and the vehicle speed sensor 3P connector, then go to step 26 .
  19. Measure the voltage between vehicle speed sensor 3P connector terminals No. 2 and No. 3. Is there about 5 V? YES -Replace the vehicle speed sensor (see «VEHICLE SPEED SENSOR REPLACEMENT»(ref-513160-S36177006132012110700000) ), then go to step 26 . NO -Go to step 20.
  20. Turn the ignition switch to LOCK (0).
  21. Jump the SCS line with the HDS.
  22. Disconnect PCM connector B (49P).
  23. Check for continuity between vehicle speed sensor 3P connector terminal No. 2 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between PCM connector terminal B38 and the vehicle speed sensor 3P connector, then go to step 26 . NO -Go to step 24.
  24. Check for continuity between PCM connector terminal B34 and vehicle speed sensor 3P connector terminal No. 3. Is there continuity? YES -Go to step 25. NO -Repair an open in the wire between the vehicle speed sensor 3P connector and PCM connector terminal B34, then go to step 26 .
  25. Check for continuity between PCM connector terminal B38 and vehicle speed sensor 3P connector terminal No. 2. Is there continuity? YES -Go to step 32 . NO -Repair an open in the wire between PCM connector terminal B38 and the vehicle speed sensor 3P connector, then go to step 26.
  26. Reconnect all connectors.
  27. Turn the ignition switch to ON (II).
  28. Clear the DTC with the HDS.
  29. Start the engine, disable the VSA by pressing the VSA OFF button, run the vehicle with the shift lever in D, until the vehicle speed reaches 37 mph (60 km/h), then slow down and stop the wheels.
  30. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0502 indicated? YES -Check for poor connections or loose terminals between the vehicle speed sensor and the PCM, then go to step 1 . NO -Go to step 31.
  31. Monitor the OBD STATUS for P0502 in the DTCs MENU with the HDS. Does the HDS indicate PASSED? YES -Troubleshooting is complete. If any other Pending or Confirmed DTCs were indicated in step 30 , go to the indicated «DTC'S TROUBLESHOOTING»(ref-513160-S17721622272012110700000) . NO -If the HDS indicates FAILED, check for poor connections or loose terminals between the vehicle speed sensor and the PCM, then go to step 1 . If the HDS indicates NOT COMPLETED, go to step 29 .
  32. Reconnect all connectors.
  33. Update the PCM if it does not have the latest software (see «PCM UPDATE»(ref-513153-S08553155092012110700000) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-513169-S18138486322012110700000) ).
  34. Start the engine, disable the VSA by pressing the VSA OFF button, run the vehicle with the shift lever in D, until the vehicle speed reaches 37 mph (60 km/h), then slow down and stop the wheels.
  35. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0502 indicated? YES -Check for poor connections or loose terminals between the vehicle speed sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-513169-S18138486322012110700000) ), then go to step 34 . If the PCM was substituted, go to step 2 . NO -Go to step 36.
  36. Monitor the OBD STATUS for P0502 in the DTCs MENU with the HDS. Does the HDS indicate PASSED? YES -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-513153-S08243124262012110700000) ). If any other Pending or Confirmed DTCs were indicated in step 35 , go to the indicated «DTC'S TROUBLESHOOTING»(ref-513160-S17721622272012110700000) . NO -If the HDS indicates FAILED, check for poor connections or loose terminals between the vehicle speed sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-513169-S18138486322012110700000) ), then go to step 34 . If the PCM was substituted, go to step 1 . If the HDS indicates NOT COMPLETED, go to step 34 .
