Under-hood Fuse/Relay Box
| Socket | Ref | Terminal | Connects to |
|---|---|---|---|
| A/C compressor clutch relay | 2 | 4 | Engine compartment wire harness |
| A/C condenser fan relay | 3 | 4 | Engine compartment wire harness |
| Headlight relay | 1 | 4 | Engine compartment wire harness |
| Horn relay | 4 | 4 | Engine compartment wire harness |
| Radiator fan relay | 5 | 4 | Engine compartment wire harness |
| T104 | 7 | Engine compartment wire harness | |
| T101 | 8 | Engine wire harness | |
| T102 | 6 | EPS wire harness |
CONNECTOR TO FUSE/RELAY BOX INDEX - UNDER-HOOD FUSE/RELAY BOX
Scheme 3
Under-dash Fuse/Relay Box and Subfuse Box
| Socket | Ref | Terminal | Connects to | Notes |
|---|---|---|---|---|
| A | 24 | 6 | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | |
| A/F sensor relay | 17 | 4 | ||
| A/T reverse relay | 18 | 4 | A/T | |
| B | 23 | 14 | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | |
| Blower motor relay | 12 | 4 | ||
| C | 25 | 8 | Driver's door wire harness (see DRIVER'S DOOR WIRE HARNESS ) | |
| D | 30 | 21 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| Diode | 8 | 2 | ||
| Door lock relay | 1 | 5 | ||
| Driver's door unlock relay | 3 | 5 | ||
| E | 31 | 14 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| F | 28 | 16 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| Fog light relay | 16 | 4 | ||
| G | 33 | 2 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| H | 32 | 6 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| I | 27 | 2 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| Ignition coil relay | 11 | 4 | ||
| J | 29 | 3 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| K | 19 | 6 | EPS subharness (see EPS SUBHARNESS ) | |
| L | 26 | 6 | Roof wire harness (see ROOF WIRE HARNESS ) | |
| M (Optional connector) | 10 | 5 | Not used | |
| N | 20 | 4 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) | |
| O | 21 | 6 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) | |
| P | 22 | 13 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) | |
| PGM-FI main relay 1 | 13 | 4 | ||
| PGM-FI main relay 2 | 14 | 4 | ||
| Passengers' doors/tailgate unlock relay | 4 | 5 | ||
| Power window relay | 5 | 4 | ||
| Q (Memory erase signal connector socket) | 7 | |||
| Rear window defogger relay | 15 | 4 | ||
| Starter cut relay | 2 | 4 | ||
| Taillight relay | 6 | 4 | ||
| Throttle actuator control module relay | 9 | 4 |
CONNECTOR TO FUSE/RELAY BOX INDEX - UNDER-DASH FUSE/RELAY BOX AND SUBFUSE BOX
