Wiring diagram: Computer data lines — Computer data lines circuit, w/o can gateway Honda Fit GP facelift
All systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines 2
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance 1.5l
- Exterior lights 3
- Ground distribution
- Headlights
- Horn
- Instrument cluster 2
- Interior lights 2
- Navigation 4
- Power distribution
- Power door locks
- Power mirrors
- Power seats
- Power top/sunroof
- Power windows
- Radio 3
- Shift interlock 2
- Starting/charging 3
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer 2
Computer data lines circuit, w/o can gateway (1 of 2) Honda Fit GP facelift
Components on the diagram
Computer data lines circuit, w/o can gateway (2 of 2) Honda Fit GP facelift
