Engine Lubrication: Component Locations Honda Fit GE

Special Tools Required

Oil filter wrench 07AAA-PLCA100

Scheme 19

Scheme 20

Scheme 21

1. Drain the engine oil (see «ENGINE OIL REPLACEMENT»(ref-320427-S37377730802009071400000) ).
2. Remove the oil filter with the oil filter wrench.
3. Inspect the filter to make sure the rubber seal is not stuck to the oil filter seating surface of the engine.
4. Inspect the threads (A) and the rubber seal (B) on the new filter. Clean the seat on the oil pan, then apply a light coat of new engine oil to the filter rubber seal. Use only filters with a built-in bypass system.
5. Install the oil filter by hand.
6. After the rubber seal seats, tighten the oil filter clockwise with the oil filter wrench. Tighten: 3/4 Turn Clockwise Tightening Torque: 12 N.m (1.2 kgf.m, 8.8 lbf.ft)
7. If four numbers or marks (1 to 4 or ↓ to ↓↓↓↓) are printed around the outside of the filter, you can use the following procedure to tighten the filter. Spin the filter on until its seal lightly seats against the oil pan, and note which number or mark is at the bottom. Tighten the filter by turning it clockwise three numbers or marks from the one you noted. For example, if mark ↓ is at the bottom when the seal is lightly seated, tighten the filter until the mark ↓↓↓↓ comes around to the bottom.
8. After oil filter replacement, refill with new engine oil (see «ENGINE OIL REPLACEMENT»(ref-320427-S37377730802009071400000) , and «ENGINE OIL LEVEL CHECK»(ref-320427-S42842234232009071400000) ), run the engine for more than 3 minutes, then check for oil leakage.

Scheme 22

Scheme 23

1. Remove the filter (see «ENGINE OIL FILTER REPLACEMENT»(ref-320427-S38088097852009071400000) ).
2. Remove the oil filter feed pipe.
3. Install two 20 x 1.5 mm nuts (A) onto the new oil filter feed pipe. Hold one nut with a wrench, then use a second wrench to tighten the other nut.
4. Apply new engine oil to the oil filter feed pipe threads, then torque the oil filter feed pipe to 39 N.m (4.0 kgf.m, 29 lbf.ft), then remove the nuts from the oil filter feed pipe.
5. Install the oil filter (see «ENGINE OIL FILTER REPLACEMENT»(ref-320427-S38088097852009071400000) ).

Scheme 24

1. Support eyelet 07AAK-SNAA600
2. Engine support hanger, A and Reds AAR-T1256 * * : This special tool is available through the Honda Tool and Equipment Program, 888-424-6857

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. Open the hood, and secure it with the hood support rod (A) in the wide-open position (B).
2. Drain the engine oil (see «ENGINE OIL REPLACEMENT»(ref-320427-S37377730802009071400000) ).
3. Remove the under-cowl panel (see «UNDER-COWL PANEL REPLACEMENT»(ref-320448-S09609825902009071400000) ).
4. Support the engine with a jack and a wood block under the oil pan.
5. Remove the cam chain (see «CAM CHAIN REMOVAL»(ref-320441-S32997938752009071400000) ).
6. Remove the alternator mounting bolt, then install the support eyelet.
7. Install the engine support hanger (AAR-T1256) onto the vehicle, and attach the hook (A) to the support eyelet (B). Tighten the wing nut (C) by hand, and lift and support the engine/transmission. NOTE: Be careful when working around the windshield.
8. Remove the jack and the wood block from under the oil pan.
9. Remove the oil pan (see «OIL PAN REMOVAL»(ref-320456-S01082494382009071400000) ).
10. Remove the oil screen (A), then remove the oil pump (B).
