Tailgate Honda Element YH2 facelift

Scheme 87

Scheme 88

1. Loosen each bolt slightly.
2. Adjust the tailgate (A) alignment in the following sequence: Adjust the tailgate hinges (B) right and left, as well as up and down, using the elongated holes. Adjust the fit between the tailgate and tailgate opening by moving both strikers (C).
3. Tighten each bolt securely.
4. Check that the tailgate opens properly and locks securely.
5. Check that the tailgate weatherstrip contacts the hatch weatherstrip properly on each side.
6. Apply touch-up paint to the hinge mounting bolts and around the hinges.
7. Apply multipurpose grease to the pivot portion of the tailgate hinges (A) as indicated by the arrows.

Note. Have an assistant help you when removing and installing the tailgate support cable. Take care not to damage the exterior parts.

Scheme 89

1. Close the tailgate half-way, and hold it.
2. Remove the bolts from the body and tailgate, then remove the tailgate support cable (A).
3. Install the support cable in the reverse order of removal.

Note. Have an assistant help you when removing and installing the tailgate weatherstrip.

Scheme 90

1. Open the tailgate half-way, and hold it.
2. On both sides of the tailgate weatherstrip (A), detach the clips with a clip remover, and release the double-sided adhesive tape (B).
3. Remove the tailgate weatherstrip by pulling out on it.
4. Scrape off the remaining double-sided adhesive tape from the weatherstrip and tailgate, and clean the weatherstrip and tailgate surface with alcohol. Attach the new double-sided adhesive tape (3M 4213, or equivalent) to the weatherstrip.
5. Align the weatherstrip with both edges of the tailgate, and install the weatherstrip along the edge of the tailgate. Make sure there are no wrinkles in the weatherstrip.
6. Install the clips in both sides.
7. Check for water leaks (see step 8 on «FRONT DOOR GLASS ADJUSTMENT»(ref-290859-S02402118452008072200000) ).
