Power Mirrors Honda Element YH2

Mirrors 13 illustrations ~690 words

Scheme 8

Scheme 8: Component Location Index
Scheme 8: Component Location Index

Scheme 9

Scheme 9: Circuit Diagram
Scheme 9: Circuit Diagram

Scheme 10

Scheme 10: Function Test
Scheme 10: Function Test
  1. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-220591-S37518720862006022100000) ).
  2. Disconnect the 13P connector (A) from the power mirror switch (B).
  3. Choose the appropriate test based on the symptom: Both mirrors don't work, go to step 4. Left mirror doesn't work, go to step 6 . Right mirror doesn't work, go to step 7 . Both mirrors
  4. Check for voltage between the No. 2 terminal and body ground with the ignition switch ON (II). There should be battery voltage. If there is no battery voltage, check for: Blown No. 14 (10 A) fuse in the under-dash fuse/relay box. An open in the BLK/YEL wire. If there is battery voltage, go to step 5.
  5. Check for continuity between the No. 6 terminal and body ground. There should be continuity. If there is no continuity, check for: An open in the BLK wire. Poor ground (G501). If there is continuity, check both mirrors individually as described in step 6 and step 7 . Left mirror
  6. Connect the No. 2 terminal to the No. 10 terminal, and the No. 5 (then No. 12) terminal to No. 6 terminal with jumper wires. The left mirror should tilt down (then swing left) with the ignition switch ON (II). If the mirror does not tilt down (or does not swing left), check for an open in the GRN/WHT (or BLU/WHT) wire between the left mirror and the 13P connector. If the wire is OK, check the left mirror actuator (see «POWER MIRROR ACTUATOR TEST»(/honda/element/yh2-2003-2006/remont/mirrors/#power-mirrors) ). If the mirror neither tilts down nor swings left, repair the BLU/BLK wire. If the mirror works properly, check the mirror switch (see «POWER MIRROR SWITCH TEST/REPLACEMENT»(/honda/element/yh2-2003-2006/remont/mirrors/#power-mirrors) ). Right mirror
  7. Connect the No. 2 terminal to the No. 11 terminal, and the No. 5 (then No. 13) terminal to No. 6 terminal with jumper wires. The right mirror should tilt down (then swing left) with the ignition switch ON (II). If the mirror does not tilt down (or does not swing left), check for an open in the GRN/WHT (or WHT/RED) wire between the right mirror and the 13P connector. If the wire is OK, check the right mirror actuator (see «POWER MIRROR SWITCH TEST/REPLACEMENT»(/honda/element/yh2-2003-2006/remont/mirrors/#power-mirrors) ). If the mirror neither tilts down nor swings left, repair the RED/YEL wire. If the mirror works properly, check the mirror switch (see «POWER MIRROR SWITCH TEST/REPLACEMENT»(/honda/element/yh2-2003-2006/remont/mirrors/#power-mirrors) ).

Scheme 11

Scheme 11: Power Mirror Switch Test/Replacement
Scheme 11: Power Mirror Switch Test/Replacement

Scheme 12

Scheme 12
Scheme 12
  1. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-220591-S37518720862006022100000) ).
  2. Disconnect the 13P connector from the power mirror switch (A).
  3. Check for continuity between the terminals in each switch position according to the table.
  4. If the continuity is not as specified, remove the screws and replace the switch.

Scheme 13

Scheme 13: Power Mirror Actuator Test
Scheme 13: Power Mirror Actuator Test

Scheme 14

Scheme 14
Scheme 14
  1. Remove the door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-220591-S37518720862006022100000) ).
  2. Disconnect the 8P connector (A) from the power mirror actuator (B).
  3. Check actuator operation by connecting power and ground according to the table.
  4. If the mirror fails to work properly, replace the mirror actuator.

Scheme 15

Scheme 15: Power Mirror Actuator Replacement
Scheme 15: Power Mirror Actuator Replacement

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. Remove the mirror holder (see «MIRROR HOLDER REPLACEMENT»(/honda/element/yh2-2003-2006/remont/mirrors/#mirrors) ).
  2. Disconnect the 6P connector from the mirror, and remove the power mirror (see «POWER MIRROR/MANUAL MIRROR REPLACEMENT»(/honda/element/yh2-2003-2006/remont/mirrors/#mirrors) ).
  3. Remove the cover (A), then remove the two screws from the mirror connector (B).
  4. Record the terminal locations and wire colors.
  5. Cut the wire harness with the wire cutter.
  6. Remove the three screws, and separate the mirror housing (A) from the bracket (B).
  7. Remove the cover (A), then remove the three screws and the actuator (B).
  8. Route the wire harness (A) of the new actuator through the hole in the bracket (B) and gasket (C).
  9. Install the actuator, bracket, and cover in the reverse order of removal.
  10. Insert the new actuator terminals into the connector in the original arrangement as shown.
  11. Reassemble in the reverse order of disassembly. Be careful not to break the mirror holder when reinstalling it to the actuator.
  12. Reinstall the mirror assembly to the door.
  13. Operate the power mirror to ensure smooth operation.
