Glass Height Adjustment
The roof panel (A) should be even with the glass weatherstrip (B), to within 2+0.5/---1 mm (0.08+0.02/---0.04 in.) at the center of the glass opening. If not, make the following adjustment
Scheme 2
Scheme 3
Scheme 4
- Remove the skylight.
- For front height: On both glass brackets (A), using a T30 Torx bit, loosen the bolts (B), and install a shims (C) between the glass frame (D) and glass bracket. Shim: Thickness 2 mm (0.08 in.) max.
- For rear height: On the glass latch (A), loosen the nuts (B), and install a shim (C) between the glass frame (D) and glass latch. Shim: Thickness 1 mm (0.04 in.) max.
- Install the skylight.
- Check that the latch handle works smoothly.
- Lock the skylight securely, and recheck the glass height alignment.
Scheme 5
- Remove the skylight.
- To prevent damage to the skylight, place it on a work area with a protective covering.
- Remove the nuts and shim (A), then remove the glass latch (B).
- Install the latch in the reverse order of removal, and note these items: Apply multipurpose grease to the handle pivot portions and latch arm moving portion as indicated by the arrows. Check the glass latch operation.
Scheme 6
Scheme 7
- Remove the skylight.
- To prevent damage to the skylight, place it on a work area with a protective covering.
- Using a T30 Torx bit, remove the screws and shim (A), then remove the glass bracket (B).
- Install the bracket in the reverse order of removal.
Scheme 8
- Remove these items: Skylight Rear roof trim (see «D-PILLAR TRIM/REAR ROOF TRIM»(ref-220595-S19214592252006022100000) ) Roof trim (see step 8 on «HEADLINER REMOVAL/INSTALLATION»(ref-220595-S27580112932006022100000) ) Glass latch handle trim (see step 7 on «HEADLINER REMOVAL/INSTALLATION»(ref-220595-S27580112932006022100000) )
- Pull down the headliner as necessary. Take care not to bend the headliner excessively, or you may crease or break it.
- Remove the screws (A, B), then remove the latch bracket (C).
- Install the bracket in the reverse order of removal, and make sure the guide projection (D) is installed into the elongated hole (E) properly.
