Relays: Other Honda Element I

Body Electrical 8 illustrations ~145 words

Normally-open type B

Check for continuity between the terminals.

Scheme 53

Scheme 53: Normally-open type B
Scheme 53: Normally-open type B
  1. There should be continuity between the No. 1 and No. 3 terminals when power and ground are connected to the No. 2 and No. 4 terminals.
  2. There should be no continuity between the No. 1 and No. 3 terminals when power is disconnected.

Blower motor relay

type 1

Scheme 54

Scheme 54
Scheme 54

type 2

Scheme 55

Scheme 55
Scheme 55

Rear window defogger relay

Scheme 56

Scheme 56
Scheme 56

Five-terminal type

Check for continuity between the terminals.

Scheme 57

Scheme 57: Five-terminal type
Scheme 57: Five-terminal type
  1. There should be continuity between the No. 1 and No. 2 terminals when power and ground are connected to the No. 3 and No. 4 terminals.
  2. There should be no continuity between the No. 1 and No. 4 terminals when power is disconnected.

Low beam cut relay (Canada)

Scheme 58

Scheme 58
Scheme 58

PGM-FI main relay 2

type 1

Scheme 59

Scheme 59
Scheme 59

type 2

Scheme 60

Scheme 60
Scheme 60
