Design Specifications
| Item | Measurement | Qualification | Specification |
|---|---|---|---|
| DIMENSIONS | Overall length | 4,999 mm (196.8 in) | |
| Overall width | 1,898 mm (74.7 in) | ||
| Overall height | 1,670 mm (65.7 in) | ||
| Wheelbase | 2,797 mm (110.1 in) | ||
| Track | Front | 1,648 mm (64.9 in) | |
| Rear | 1,648 mm (64.9 in) | ||
| Seating capacity | Five (5) | ||
| WEIGHT | Gross Vehicle Weight Rating (GVWR) | 2WD | 2,240 kg (4,938 lbs) |
| 4WD | 2,320kg (5,115 lbs) | ||
| ENGINE | Type | Water-cooled, 4-stroke SOHC i-VTEC Variable Cylinder Management gasoline engine | |
| Cylinder arrangement | 60° V6-cylinder, transverse | ||
| Bore and stroke | 89 x 93 mm (3.50 x 3 66 in) | ||
| Displacement | 3,471 cm 3 (211.8 cu in) | ||
| Compression ratio | 10.5 | ||
| Valve train | Belt driven, SOHC i-VTEC 4 valves per cylinder | ||
| Lubrication system | Forced, wet sump, with trochoid pump | ||
| Fuel required | Regular UNLEADED gasoline with 87 Pump Octane Number or higher | ||
| STARTER | Type | Gear reduction | |
| Nominal output | 1.8 kW | ||
| Nominal voltage | 12V | ||
| Hour rating | 30 seconds | ||
| Direction of rotation | Counterclockwise as viewed from drive end | ||
| AUTOMATIC TRANSMISSION | Type | Electronically-controlled automatic, five-speed forward, one reverse, three-element torque converter with lock-up clutch | |
| Primary reduction | Direct 1:1 | ||
| Gear ratio | 1st | 2.697 | |
| 2nd | 1.606 | ||
| 3rd | 1.071 | ||
| 4th | 0.766 | ||
| 5th | 0.612 | ||
| Reverse | 1.889 | ||
| Final reduction | Type | Single helical gear | |
| Gear ratio | 4.533 | ||
| STEERING | Type | Hydraulic power-assisted rack and pinion | |
| Overall ratio | 15.2 | ||
| Turns, lock-to-lock | 2.76 | ||
| Steering wheel diameter | 370 mm (14.57 in) | ||
| SUSPENSION | Type | Front | Independent double wishbone with stabilizer, coil spring |
| Rear | Independent multi-link with stabilizer, coil spring | ||
| Shock absorber | Front | Telescopic, hydraulic, nitrogen gas-filled | |
| Rear | Telescopic, hydraulic, nitrogen gas-filled | ||
| TIRES | Size (except EX-L) | Front and rear | 225/65R17 102T |
| Spare | T155/90D16 110M | ||
| Size (EX-L) | Front and rear | 225/60R18 100H | |
| Spare (2WD) | T155/90D16110M | ||
| Spare (4WD) | T155/90D17 101M | ||
| WHEEL ALIGNMENT | Camber | Front | 0°00' |
| Rear | 1°00' | ||
| Caster | Front | 3° 30' | |
| Total toe-in | Front | 0 mm (0 in) | |
| Rear | 2 mm (0.08 in) | ||
| Front wheel turning angle | Inward | 36° 36' | |
| Outward (reference) | 28° 49' | ||
| BRAKES | Type of service brake | Front | Power-assisted self-adjusting ventilated disc |
| Rear | Power-assisted self-adjusting solid disc | ||
| Type of parking brake | Mechanical actuating, rear wheels | ||
| Pad friction surface area (swept area) | Front | 60.5 cm 2 (9.38 sq in) x 2 | |
| Rear | 27.9 cm 2 (4.32 sq in) x 2 | ||
| Parking brake shoe friction surface area | 45.6 cm 2 (7.07 sq in) x 2 | ||
| AIR CONDITIONING | Compressor | Type | Swash plate/DENSO |
| Capacity | 154.4 mL (9.42 cu in)/rev | ||
| Maximum speed | 8,400 rpm | ||
| Lubricant capacity | 70 mL (2 3/8 fl.oz) | ||
| Lubricant type | DENSO ND-OIL 8 | ||
| Condenser | Type | Corrugated fin | |
| Evaporator | Type | Corrugated fin | |
| Blower | Type | Stabilized swirling flow | |
| Motor type | 216W/12V | ||
| Speed control | Infinitely variable | ||
| Maximum capacity | 505 m 3 (17,834 cu ft)/h | ||
| Temperature control | Air-mix type | ||
| Compressor clutch | Type | Dry, single plate, poly V-belt drive | |
| Electrical power consumption at 68°F (20°C) | 35 W maximum at 12 V | ||
| Refrigerant | Type | HFC-134a (R-134a) | |
| Capacity | 400-450 g (14.1-15.9 oz) | ||
| ELECTRICAL RATINGS | Battery | 12 V-72 Ah/20 HR (12 V-60 Ah/5 HR) | |
| Fuse | Under-hood fuse/relay box | 120 A, 70 A, 60 A, 50 A, 40 A, 30 A, 20 A, 15 A, 10 A, 7.5 A | |
| Driver's under-dash fuse/relay box | 20 A, 15A, 10A,7 5A | ||
| Passenger's under-dash fuse/relay box | 20 A, 15 A, 10 A, 7.5 A | ||
| Light bulbs | Headlight high beam | 12 V-60 W (HB3) | |
| Headlight low beam | 12 V-55W (H11) | ||
| Fog lights | 12V-55W (H11) | ||
| Front turn signal/parking lights | 12 V-24/2 2 CP | ||
| Front side marker lights | 12 V-5 W | ||
| Rear turn signal lights | 12 V-21 W | ||
| Brake lights/taillights | 12 V-21/5 W | ||
| High mount brake light | LED | ||
| Back-up lights | 12 V-21 W | ||
| License plate lights | 12 V-5 W | ||
| Individual map lights | 12 V-8 W | ||
| Ambient light | LED | ||
| Vanity mirror lights | 12 V-1.1 W | ||
| Glove box light | 12 V-2 CP | ||
| Door courtesy light | 12 V-2 CP | ||
| Ceiling light | 12 V-8 W | ||
| Cargo area light | 12 V-5 W | ||
| Washer reservoir | Capacity | 5.0 L (5.3 US qt) |
