Frame (V6): Removal & Installation Honda Crosstour I

Frames, Subframes & Crossmembers 8 illustrations ~325 words

Rear Wheelhouse Gusset Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the body or the related parts.

Scheme 11

Scheme 11: Rear Wheelhouse Gusset Replacement
Scheme 11: Rear Wheelhouse Gusset Replacement

Scheme 12

Scheme 12
Scheme 12
  1. Remove the rear side trim panel (see «REAR FLOOR COVER HANDLE»(ref-360104-S19917266102010042600000) ).
  2. Detach the wire harness clip(s) (A), and remove the bolts (B), then remove the rear wheelhouse gusset (C). 2WD 4WD
  3. Install the gusset in the reverse order of removal.

Rear Cargo Support Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the body or the related parts.

Scheme 13

Scheme 13: Rear Cargo Support Replacement
Scheme 13: Rear Cargo Support Replacement
  1. Remove these items: Rear trim panel (see «TRIM REMOVAL/INSTALLATION - CARGO AREA»(ref-360104-S07728838882010042600000) ) Front floor cover (see «TRIM REMOVAL/INSTALLATION - CARGO AREA»(ref-360104-S07728838882010042600000) )
  2. Remove the bolts (A, B) securing the rear cargo support (C), then-remove the support.
  3. Install the support in the reverse order of removal.

Spare Tire Carrier Replacement

Note. Put on gloves to protect your hands. Take, care not to scratch the body.

Scheme 14

Scheme 14: Spare Tire Carrier Replacement
Scheme 14: Spare Tire Carrier Replacement

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Remove the spare tire cap (A) from the rear trim panel (B), then loosen the carrier hook bolt (C) with the wheel nut wrench (D). NOTE: Turn the wrench until you can see the spare tire (65-70 rotations). Do not turn the wrench any further once you feel resistance.
  2. Release the spare tire carrier (A) from the carrier hook (B), then remove the spare tire (C) from the carrier. NOTE: When restoring the spare tire, place the spare tire facing up on the spare tire carrier.
  3. Remove the bolts securing the spare tire carrier (A) to the body.
  4. Release the hooks (A) from the body hole, then remove the spare tire carrier (B).
  5. If necessary, remove the bolt carrier hook cap (A), then remove the carrier hook (B) from the carrier hook bolt (C).
  6. Install the carrier in the reverse order of removal.

Subframe Replacement

Special Tools Required

Subframe Alignment Pin 070AG-SJAA10S
