Transfer Output Shaft Installation Height Inspection/Adjustment
Note. If the transfer output shaft, transfer output shaft bearing, transmission housing bearing, transmission housing, or torque converter housing were replaced, adjust the transfer output shaft installation height with the 28.5 mm thrust shim.
Scheme 5
Scheme 6
- Install the transfer output shaft (A) in the torque converter housing, and install the 28.5 mm thrust shim (B) on the top of the shaft. If you replace the 28.5 mm thrust shim with a new one, use the same thickness shim as the old one. Standard: 46.31-46.35 mm (1.8232-1.8248 in) Transfer Output Shaft Cutaway View
- Install a new gasket (C) on the torque converter housing.
- Measure the installed height (D) of the transfer output shaft between the surface (E) of the gasket and the top (F) of the 28.5 mm thrust shim in at least three places. Use the average as the actual height.
- If the measurement is out of standard, remove the 28.5 mm thrust shim and measure its thickness.
- Select and install a new thrust shim, then recheck the installation height. THRUST SHIM, 28.5 mm THICKNESS SPECIFICATION No. Thickness A 1.82 mm (0.0717 in) B 1.84 mm (0.0724 in) C 1.86 mm (0.0732 in) D 1.88 mm (0.0740 in) M 1.90 mm (0.0748 in) F 1.92 mm (0.0756 in) G 1.94 mm (0.0764 in) H 1.96 mm (0.0772 in) I 1.98 mm (0.0780 in) J 2.00 mm (0.0787 in) K 2.02 mm (0.0795 in) L 2.04 mm (0.0803 in) M 2.06 mm (0.0811 in) N 2.08 mm (0.0819 in) O 2.10 mm (0.0827 in) P 2.12 mm (0.0835 in) Q 2.14 mm (0.0843 in) R 2.16 mm (0.0850 in) S 2.18 mm (0.0858 in) T 2.20 mm (0.0866 in) U 2.22 mm (0.0874 in) V 2.24 mm (0.0882 in) W 2.26 mm (0.0890 in) X 2.28 mm (0.0898 in) Y 2.30 mm (0.0906 in) Z 2.32 mm (0.0913 in) AA 2.34 mm (0.0921 in)
Scheme 7
Scheme 8
Scheme 9
Scheme 10
- Warm up the engine to normal operating temperature (the radiator fan comes on), then turn the engine off.
- Raise the vehicle on a lift, and make sure it is securely supported.
- Remove the drain plug (A), and drain the transfer fluid (hypoid gear oil).
- Reinstall the drain plug with a new sealing washer (B).
- Remove the filler plug (A) and sealing washer (B).
- Refill the transfer assembly with the recommended fluid (hypoid gear oil) through the filler hole (C) until the fluid flows out. Use a SAE 90 viscosity hypoid gear oil, API classified GL4 or GL5 only. Viscosity: SAE 90 Transfer Fluid (Hypoid Gear Oil) Capacity: 0.41 L (0.43 US qt) at change 0.45 L (0.48 US qt) at overhaul
- Install the filler plug with a new sealing washer.
Scheme 11
Scheme 12
Scheme 13
- Raise the vehicle on a lift, and make sure it is supported securely.
- Move the shift lever to N.
- Make a reference mark (A) across the No. 1 propeller shaft (B) and the transfer companion flange (C).
- Separate the No. 1 propeller shaft from the transfer companion flange.
- Set a dial indicator (A) on the transfer companion flange (B); position the dial indicator tip (C) on the direct extension of the bolt hole center (D).
- Measure the transfer gear backlash. Standard: 0.06-0.16 mm (0.0024-0.0063 in) If the backlash is out of standard, replace the transfer assembly. If the backlash is within standard, and the inspection is complete, go to next step.
- Install the No. 1 propeller shaft (A) to the transfer companion flange (B) by aligning the reference mark (C).
Scheme 14
- Remove the transfer assembly (see «TRANSFER ASSEMBLY REMOVAL»(ref-360064-S06821893052010042600000) ).
- Secure the transfer housing (A) in a bench vise (B) with soft jaws.
- Rotate the transfer companion flange several times to seat the tapered roller bearings.
- Measure the starting torque at the companion flange (C) using a torque wrench (D) and a socket (E). Standard: 2.38-4.01 N.m (24.3-40.9 kgf.m, 21.1-35.5 lbf.ft) If the starting torque is out of standard, replace the transfer assembly. If the starting torque is within standard, go to next step.
- Install the transfer assembly (see «TRANSFER ASSEMBLY INSTALLATION»(ref-360064-S14821512462010042600000) ).
