Power Steering System: Overview Honda CR-V IV

Scheme 1

1. Power Steering Assist Check NOTE: This test should be done with original equipment tires and wheels at the correct tire pressure. Start the engine, and let it idle. Attach a commercially available spring scale (A) to the steering wheel. With the engine idling and the vehicle on a clean, dry floor, pull the scale as shown, and read it as soon as the tires begin to turn. Initial turning load: 34 N (3.5 kgf, 7.6 lbf) If the scale reads no more than the specification, the power assist is OK. If it reads more, check these items: Steering linkage Rack guide adjustment EPS system

Scheme 2

1. HDS DLC - Connection Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard. Turn the ignition switch to ON (II). Make sure the HDS communicates with the vehicle. If it does not communicate, go to the DLC circuit troubleshooting.
2. Steering Angle Sensor Neutral Position - Clear Select EPS ADJUSTMENT, then select EPS STEERING ANGLE SENSOR VALUE CLEAR and follow the screen prompts on the HDS. NOTE: See the HDS Help menu for specific instructions.
