Service Information (multi-information display)
Maintenance items, which should be serviced at the same time that you replace the engine oil (A), appear on the multi-information display. You can view them on the "Maintenance info" screen at any time.
Scheme 11
- Turn the ignition switch to ON (II).
- Press the MENU button to go to the "Vehicle Menu" screen.
- Select "Vehicle Information" with the Audio Remote/Multi-Information Display Switch, then press the Source/Enter Button.
- Press the Source/Enter Button again to go to the "Maintenance info" screen. The maintenance item(s) appears on the Maintenance Minder.
Note. The vehicle must be stopped to reset the Maintenance Minder. If a required service is done and the Maintenance Minder is not reset, or if the Maintenance Minder is reset without doing the service, the system will not show the proper maintenance timing. This can lead to serious mechanical problems because there will be no accurate record of when the required maintenance is needed. The engine oil life and the maintenance item(s) can be independently reset with the HDS.
Scheme 12
- Turn the ignition switch to ON (II).
- Push the SEL/RESET knob repeatedly until the engine oil life indicator is displayed.
- Press and hold the SEL/RESET knob for about 10 seconds. The engine oil life indicator and the maintenance item code(s) will blink, then release the knob. NOTE: If you are resetting the Maintenance Minder when the engine oil life is more than 15 %, make sure any maintenance item(s) requiring service are done before resetting the display.
- Press and hold the SEL/RESET knob for another 5 seconds. The maintenance item code(s) will disappear, and the engine oil life will reset to "100 %."
Scheme 13
Scheme 14
- Turn the ignition switch to ON (II).
- Refer to the «HOW TO ACCESS MAINTENANCE MINDER»(ref-595380-S06603085522014013100000) procedure, and go to the "Maintenance info" screen, then displaying maintenance item(s).
- Press the Source/Enter Button to change into maintenance item(s) reset mode. NOTE: If you are resetting the Maintenance Minder when the engine oil life is more than 15 %, make sure any maintenance item(s) requiring service are done before resetting the display. To cancel the reset mode, select "NO", then press the Source/Enter Button.
- To reset the Maintenance Minder, select "YES" with the Audio Remote/Multi-Information Display Switch, then press the Source/Enter Button. The displayed maintenance items disappear, and the engine oil life display returns to "100 %." The display will return to the Maintenance Minder, and you will see any maintenance items that are necessary for your vehicle at the next maintenance service will appear.
- Connect the Honda Diagnostic System (HDS) to the data link connector (DLC) See «MAINTENANCE MINDER™ MAINTENANCE MAIN ITEMS»(ref-595380-S11493609192014013100000) or «MAINTENANCE MINDER™ MAINTENANCE SUB ITEMS»(ref-595380-S23488594002014013100000) .
- Turn the ignition switch to ON (II).
- Make sure the HDS communicates with the vehicle and the powertrain control module (PCM). If it does not communicate, troubleshoot the DLC circuit See «PCM REMOVAL AND INSTALLATION»(ref-595374-S31779448642014013100000) or «PCM UPDATE»(ref-595375-S42937672232014013100000) .
- Select GAUGES in the BODY ELECTRICAL with the HDS.
- Select ADJUSTMENT in the GAUGES with the HDS.
- Select MAINTENANCE MINDER in the ADJUSTMENT with the HDS.
- Select RESET in the MAINTENANCE MINDER with the HDS.
- Select the individual maintenance item you wish to reset with the HDS.
If the message "SERVICE" or "SERVICE DUE NOW" does not appear more than 12 months after the display is reset, change the engine oil every year.
Note. Inspect idle speed every 160, 000 miles (256, 000 km). Adjust the valves during services A, B, 1, 2, or 3 if they are noisy. Replace the brake fluid every 3 years (independent of the maintenance messages in the information display).
| Symbol | Maintenance Main Items |
|---|---|
| A | REPLACE ENGINE OIL Engine oil capacity without oil filter: 3.8 L (4.0 US qt) |
| B | REPLACE ENGINE OIL AND OIL FILTER Engine oil capacity with oil filter: 4.0 L (4.2 US qt) |
| CHECK FRONT AND REAR BRAKES Check brake pads and disc thickness. Check for damage. Check calipers for damage, leaks, and tightness. Check parking brake linings for cracking, glazing, wear, and for oil or grease contamination. | |
| CHECK PARKING BRAKE ADJUSTMENT Check number of clicks (5 to 6) when parking brake pedal is pressed with 294 N (30.0 kgf, 66.1 lbf) of force. | |
| Inspect tie-rod ends, steering gearbox, and gearbox boots See PARKING BRAKE INSPECTION or PARKING BRAKE INSPECTION AND ADJUSTMENT Check steering linkage. Check boots for damage and leaking grease. | |
| INSPECT SUSPENSION COMPONENTS Check bolts for tightness. Check condition of ball joint boots for deterioration and damage. | |
| INSPECT DRIVESHAFT BOOTS Check boots for cracks and boot bands for tightness. | |
| INSPECT BRAKE HOSES AND LINES INCLUDING VSA LINES Check master cylinder and VSA modulator-control unit for damage or leakage. | |
| Inspect all fluid levels and condition of fluids ENGINE COOLANT AUTOMATIC TRANSMISSION FLUID Rear Differential Fluid Inspection BRAKE FLUID Windshield washer fluid | |
| INSPECT EXHAUST SYSTEM * Check catalytic converter heat shields, exhaust pipes, and mufflers for damaged, leaks, and tightness. | |
| INSPECT FUEL LINES and CONNECTIONS * Check for loose connections, cracks, and deterioration; retighten loose connections and replace damaged parts. |
Note. According to state and federal regulations, failure to do the maintenance items marked with an asterisk (*) will not void the customer's emissions warranties. However, Honda recommends that all maintenance services be done at the recommended interval, to ensure long-term reliability.
| Number | Maintenance Sub Items |
|---|---|
| 1 | Rotate tires, and check tire inflation and condition Follow the pattern shown in the Owner's Manual. |
| 2 | REPLACE AIR CLEANER ELEMENT If the vehicle is driven primarily in dusty conditions, replace every 15, 000 miles (24, 000 km). |
| REPLACE DUST AND POLLEN FILTER If the vehicle is driven mostly in areas that have high concentrations of dust, pollen, or soot in the air, replace every 15, 000 miles (24, 000 km). Replace filter whenever airflow from the heating and air conditioning system is less than normal. | |
| INSPECT DRIVE BELT Look for cracks and damage, then check the position of drive belt auto-tensioner indicator. | |
| 3 | REPLACE AUTOMATIC TRANSMISSION FLUID Use Honda ATF DW-1. Automatic transmission fluid capacity: 2WD models: 2.2 L (2.3 US qt) AWD models: 2.6 L (2.7 US qt) If you tow a CR-V behind a motor home, transmission fluid must be changed every 2 years or 30, 000 miles (48, 000 km), whichever comes first. |
| 4 | REPLACE SPARK PLUGS Use ILZKR7B-11S (NGK) or SXU22HCR11S (DENSO). |
| INSPECT VALVE CLEARANCE (COLD) Intake: 0.21-0.25 mm (0.009-0.009 in) Exhaust: 0.25-0.29 mm (0.010-0.011 in) | |
| 5 | Replace engine coolant See VALVE CLEARANCE ADJUSTMENT or VALVE, SPRING, AND VALVE SEAL REMOVAL AND INSTALLATION Use Honda Long Life Antifreeze/Coolant Type 2, and if necessary, add Honda Extreme Cold Weather Antifreeze/Coolant Type 2 (concentrate) as need for prolong cold temperatures below -22°F (-30°C). Capacity (including reservoir): 6.23 L (1.646 US gal) |
| 6 | REPLACE REAR DIFFERENTIAL FLUID (AWD MODELS) Use Honda Dual Pump Fluid II. Capacity: 1.2 L (1.3 US qt) |
