Vsa System DTC Testing: Overview Honda CR-V IV

Anti-Lock/traction Control 68 illustrations ~18753 words

Scheme 1

Scheme 1: DTC 151-11: Low Tire Air Pressure
Scheme 1: DTC 151-11: Low Tire Air Pressure

Note. Before troubleshooting, CHECK THE OUTSIDE AIR TEMPERATURE SENSOR . If outside air temperature sensor is failed, the VSA modulator-control unit may set this code. Make sure to avoid uneven loading on one side (left or right) of the vehicle and excessive loading. Make sure to inflate the tires to recommended pressure, not higher than the specified pressure, when TPMS calibration is done. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the how to troubleshooting information.

DTC DescriptionDTCFreeze Frame
151-11 Low Tire Air Pressure
  1. Tire check: 1. Turn the ignition switch to LOCK (0). 2. Check all four tires for size, inflation, and wear. Are all four tires the correct size, properly inflated, and worn evenly? YES : The system is OK at this time. Do the TPMS calibration. NO : Install the correct tires, a known-good set of tires, or set the tires to the correct pressure, and do the TPMS calibration.

Scheme 2

Scheme 2: DTC 151-21: Different Diameter Tire Detection
Scheme 2: DTC 151-21: Different Diameter Tire Detection

Note. The DTC will be indicated when the vehicle has a different diameter tire(s) compared to the other tires. Check the record of using tires and wheels of a different size from originally supplied with the vehicle including the use of temporary spare tire. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the how to troubleshooting information.

DTC DescriptionDTCFreeze Frame
151-21 Different Diameter Tire Detection
  1. Tire and wheel check: 1. Turn the ignition switch to LOCK (0). 2. Check all four tires for size, inflation, and wear. Are all four tires the correct size, properly inflated, and worn evenly? YES : The system is OK at this time. Do the TPMS calibration. NO : Install the correct tires, a known-good set of tires, or set the tires to the correct pressure, and do the TPMS calibration.

Scheme 3

Scheme 3: DTC 151-31: TPMS Switch Circuit Open
Scheme 3: DTC 151-31: TPMS Switch Circuit Open

Note. Pressing and holding the TPMS switch for more than 60 seconds will cause this DTC to set. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the how to troubleshooting information.

DTC DescriptionDTCFreeze Frame
151-31 TPMS Switch Circuit Open

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Turn the ignition switch to ON (II), then wait for 60 seconds or more. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 151-31 TPMS Switch Circuit Open Is DTC 151-31 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time.
  2. Open wire check (TPMS_SW line) 1: 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. TPMS switch 5P connector 3. Turn the ignition switch to ON (II). 4. Measure the voltage between test points 1 and 2. Test condition IG ON (II) TPMS switch 5P connector: disconnected Test circuit TPMS_SW Test point 1 TPMS switch 5P connector No. 4 (YEL) Test point 2 Body ground Is there battery voltage? YES : The TPMS_SW wire is not open. Go to step 3. NO : Go to step 4 .
  3. Open wire check (GND line): 1. Measure the voltage between test points 1 and 2. Test condition IG ON (II) TPMS switch 5P connector: disconnected Test circuit GND Test point 1 TPMS switch 5P connector No. 4 (YEL) Test point 2 TPMS switch 5P connector No. 5 (BLK) Is there battery voltage? YES : The GND wire is OK. Check the TPMS switch. NO : Repair an open in the wire between the TPMS switch and body ground (G501).
  4. Open wire check (TPMS_SW line) 2: 1. Turn the ignition switch to LOCK (0). 2. Remove the gauge control module (Do not disconnect the connector) See «Rewriting the ODO Data and Transferring the Maintenance Minder™ Data to a New Gauge Control Module»(ref-595382-S29459770492014013100000) or «GAUGE CONTROL MODULE REMOVAL AND INSTALLATION»(ref-595382-S39482976312014013100000) . 3. Turn the ignition switch to ON (II). 4. Measure the voltage between test points 1 and 2. Test condition IG ON (II) TPMS switch 5P connector: disconnected Gauge control module 32P connector: connected Test circuit TPMS_SW Test point 1 Gauge control module 32P connector No. 24 (YEL) Test point 2 Body ground Is there battery voltage? YES : Repair an open in the wire between the TPMS switch and the gauge control module. NO : «DO THE TROUBLESHOOTING FOR THE GAUGE CONTROL MODULE»(ref-595406-S20099846262014013100000) . If necessary, substitute a known-good gauge control module, and recheck See «Rewriting the ODO Data and Transferring the Maintenance Minder™ Data to a New Gauge Control Module»(ref-595382-S29459770492014013100000) or «GAUGE CONTROL MODULE REMOVAL AND INSTALLATION»(ref-595382-S39482976312014013100000) .

Scheme 7

Scheme 7: DTC 11-13: Right-Front Wheel Speed Sensor Circuit Malfunction; DTC 13-13: Left-Front Wheel Speed Sen
Scheme 7: DTC 11-13: Right-Front Wheel Speed Sensor Circuit Malfunction; DTC 13-13: Left-Front Wheel Speed Sen

Scheme 8

Scheme 8
Scheme 8

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
11-13 Right-Front Wheel Speed Sensor Circuit Malfunction
13-13 Left-Front Wheel Speed Sensor Circuit Malfunction
15-13 Right-Rear Wheel Speed Sensor Circuit Malfunction
17-13 Left-Rear Wheel Speed Sensor Circuit Malfunction

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 11-13 Right-Front Wheel Speed Sensor Circuit Malfunction 13-13 Left-Front Wheel Speed Sensor Circuit Malfunction 15-13 Right-Rear Wheel Speed Sensor Circuit Malfunction 17-13 Left-Rear Wheel Speed Sensor Circuit Malfunction Is DTC 11-13, 13-13, 15-13, or 17-13 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. Shorted wire check (Wheel speed sensor lines to ground): 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. VSA modulator-control unit 38P connector 3. Check for continuity between body ground and the appropriate wheel speed sensor +B and GND terminals of the VSA modulator-control unit 38P connector individually (see table). Test condition IG LOCK (0) VSA modulator-control unit 38P connector: disconnected DTC Appropriate Terminal +B GND 11-13 Right-front No. 24 No. 13 13-13 Left-front No. 21 No. 9 15-13 Right-rear No. 23 No. 35 17-13 Left-rear No. 33 No. 22 Is there continuity? YES : Wheel speed sensor wires are shorted to ground. Go to step 3. NO : The wheel speed sensor wires are not shorted to ground. Go to step 4 .
  3. Wheel speed sensor(s) check: 1. Disconnect the following connector. Appropriate wheel speed sensor 2P connector 2. On the sensor side, check for continuity between test points 1 and 2. Test condition IG LOCK (0) VSA modulator-control unit 38P connector: disconnected Appropriate wheel speed sensor 2P connector: disconnected Test circuit +B Test point 1 Appropriate wheel speed sensor 2P connector No. 1 Test point 2 Body ground Test circuit GND Test point 1 Appropriate wheel speed sensor 2P connector No. 2 Test point 2 Body ground Is there continuity? YES : The wheel speed sensor wires are not shorted to ground. Replace the appropriate wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) . NO : Repair a short to body ground in the wire between the VSA modulator-control unit and the wheel speed sensor.
  4. Shorted wire check (Wheel speed sensor lines to power): 1. Turn the ignition switch to ON (II). 2. Measure the voltage between body ground and the appropriate wheel speed sensor +B and GND terminals of the VSA modulator-control unit 38P connector individually (see table). Test condition IG ON (II) VSA modulator-control unit 38P connector: disconnected DTC Appropriate Terminal +B GND 11-13 Right-front No. 24 No. 13 13-13 Left-front No. 21 No. 9 15-13 Right-rear No. 23 No. 35 17-13 Left-rear No. 33 No. 22 Is there 0.1 V or more? YES : Wheel speed sensor wires are shorted to power. Go to step 5. NO : The wheel speed sensor wires are not shorted to power. Go to step 6 .
  5. Wheel speed sensor(s) check: 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. Appropriate wheel speed sensor 2P connector 3. Turn the ignition switch to ON (II). 4. On the sensor side, measure the voltage between test points 1 and 2. Test condition IG ON (II) VSA modulator-control unit 38P connector: disconnected Appropriate wheel speed sensor 2P connector: disconnected Test circuit +B Test point 1 Appropriate wheel speed sensor 2P connector No. 1 Test point 2 Body ground Test circuit GND Test point 1 Appropriate wheel speed sensor 2P connector No. 2 Test point 2 Body ground Is there 0.1 V or more? YES : The wheel speed sensor wires are not shorted to power. Replace the appropriate wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) . NO : Repair a short to power in the wire between the VSA modulator-control unit and the appropriate wheel speed sensor.
  6. Shorted wire check (Wheel speed sensor lines wire to wire): 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. Appropriate wheel speed sensor 2P connector 3. Check for continuity between the appropriate VSA modulator-control unit 38P connector wheel speed sensor +B and GND terminals (see table). Test condition IG LOCK (0) VSA modulator-control unit 38P connector: disconnected Appropriate wheel speed sensor 2P connector: disconnected DTC Appropriate Terminal +B GND 11-13 Right-front No. 24 No. 13 13-13 Left-front No. 21 No. 9 15-13 Right-rear No. 23 No. 35 17-13 Left-rear No. 33 No. 22 Is there continuity? YES : Repair a short in the wires between the appropriate wheel speed sensor and the VSA modulator-control unit. NO : The wheel speed sensor wires are not shorted in the wires. Go to step 7.
  7. Open wire check (Wheel speed sensor lines) 1: 1. Check for continuity between the appropriate VSA modulator-control unit 38P connector terminal and the appropriate wheel speed sensor 2P connector terminal (see table). Test condition IG LOCK (0) VSA modulator-control unit 38P connector: disconnected Appropriate wheel speed sensor 2P connector: disconnected DTC VSA Modulator-Control Unit 38P Connector Terminal Appropriate Wheel Speed Sensor 2P Connector Terminal 11-13 No. 24 Right-front 13-13 No. 21 Left-front 15-13 No. 23 Right-rear 17-13 No. 33 Left-rear Is there continuity? YES : Go to step 8. NO : Repair an open in the wire between the appropriate wheel speed sensor and the VSA modulator-control unit.
  8. Open wire check (Wheel speed sensor lines) 2: 1. Check for continuity between the appropriate VSA modulator-control unit 38P connector terminal and the appropriate wheel speed sensor 2P connector terminal (see table). Test condition IG LOCK (0) VSA modulator-control unit 38P connector: disconnected Appropriate wheel speed sensor 2P connector: disconnected DTC VSA Modulator-Control Unit 38P Connector Terminal Appropriate Wheel Speed Sensor 2P Connector Terminal 11-13 No. 13 Right-front 13-13 No. 9 Left-front 15-13 No. 35 Right-rear 17-13 No. 22 Left-rear Is there continuity? YES : The wheel speed sensor wires are OK. If a DTC is indicated for either one of the front or rear wheels as described in step 1, go to step 9. YES : The wheel speed sensor wires are OK. If DTCs are indicated for both front or rear wheels as described in step 1, go to step 10 . NO : Repair an open in the wire between the appropriate wheel speed sensor and the VSA modulator-control unit.
  9. Wheel speed sensor(s) check 3: 1. Swap the appropriate front left and front right wheel speed sensors or rear left and rear right wheel speed sensors See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) . 2. Reconnect the following connectors. VSA modulator-control unit 38P connector Wheel speed sensor 2P connector 3. Turn the ignition switch to ON (II). 4. Clear the DTC with the HDS. 5. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 6. Check for DTCs with the HDS. DTC Before Swapping DTC After Swapping 11-13 (Right-front) 13-13 (Left-front) 13-13 (Left-front) 11-13 (Right-front) 15-13 (Right-rear) 17-13 (Left-rear) 17-13 (Left-rear) 15-13 (Right-rear) DTC Description DTC Freeze Frame Is the DTC indicated for the opposite wheel? YES : Replace the original wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) . NO : Go to step 11 .
  10. Wheel speed sensor(s) check (substitution): 1. Substitute a known-good wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) . DTC Appropriate Wheel Speed Sensor 11-13 Right-front 13-13 Left-front 15-13 Right-rear 17-13 Left-rear 2. Reconnect the following connectors. VSA modulator-control unit 38P connector Wheel speed sensor 2P connector 3. Turn the ignition switch to ON (II). 4. Clear the DTC with the HDS. 5. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 6. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 11-13 Right-Front Wheel Speed Sensor Circuit Malfunction 13-13 Left-Front Wheel Speed Sensor Circuit Malfunction 15-13 Right-Rear Wheel Speed Sensor Circuit Malfunction 17-13 Left-Rear Wheel Speed Sensor Circuit Malfunction Is DTC 11-13, 13-13, 15-13, or 17-13 indicated? YES : Go to step 11. NO : Replace the original wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) .
  11. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 2. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 3. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 11-13, 13-13, 15-13, or 17-13 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 16

Scheme 16: DTC 12-11: Right-Front Wheel Speed Sensor Electrical Noise or Intermittent Interruption; DTC 14-11:
Scheme 16: DTC 12-11: Right-Front Wheel Speed Sensor Electrical Noise or Intermittent Interruption; DTC 14-11:

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM . If the ABS and other indicators come on because of electrical noise, the indicators will go off when you test-drive the vehicle speed at 9 mph (15 km/h) or more and the noise is gone.

DTC DescriptionDTCFreeze Frame
12-11 Right-Front Wheel Speed Sensor Electrical Noise or Intermittent Interruption
14-11 Left-Front Wheel Speed Sensor Electrical Noise or Intermittent Interruption
16-11 Right-Rear Wheel Speed Sensor Electrical Noise or Intermittent Interruption
18-11 Left-Rear Wheel Speed Sensor Electrical Noise or Intermittent Interruption
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Test-drive the vehicle for 120 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 12-11 Right-Front Wheel Speed Sensor Electrical Noise or Intermittent Interruption 14-11 Left-Front Wheel Speed Sensor Electrical Noise or Intermittent Interruption 16-11 Right-Rear Wheel Speed Sensor Electrical Noise or Intermittent Interruption 18-11 Left-Rear Wheel Speed Sensor Electrical Noise or Intermittent Interruption Is DTC 12-11, 14-11, 16-11, or 18-11 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. Wheel speed sensor installation check: 1. Turn the ignition switch to LOCK (0). 2. Check that the appropriate wheel speed sensor is properly mounted See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) . DTC Appropriate Wheel Speed Sensor 12-11 Right-front 14-11 Left-front 16-11 Right-rear 18-11 Left-rear Is the wheel speed sensor installation OK? YES : Go to step 3. NO : Reinstall the wheel speed sensor, and recheck the mounting position See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) , then go to step 1 .
  3. Wheel speed sensor check (substitution): 1. Substitute a known-good wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) . DTC Appropriate Wheel Speed Sensor 12-11 Right-front 14-11 Left-front 16-11 Right-rear 18-11 Left-rear 2. Turn the ignition switch to ON (II). 3. Clear the DTC with the HDS. 4. Turn the ignition switch to LOCK (0). 5. Test-drive the vehicle for 120 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 6. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 12-11 Right-Front Wheel Speed Sensor Electrical Noise or Intermittent Interruption 14-11 Left-Front Wheel Speed Sensor Electrical Noise or Intermittent Interruption 16-11 Right-Rear Wheel Speed Sensor Electrical Noise or Intermittent Interruption 18-11 Left-Rear Wheel Speed Sensor Electrical Noise or Intermittent Interruption Is DTC 12-11, 14-11, 16-11, or 18-11 indicated? YES : Go to step 4. NO : Replace the original wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) .
  4. Magnetic encoder check: 1. Inspect the appropriate magnetic encoder for damage, debris, and correct installation. DTC Appropriate Magnetic Encoder Note 12-11 Right-front «REMOVE THE DRIVESHAFT OUTBOARD JOINT FROM THE APPROPRIATE WHEEL HUB»(ref-595434-S13559170152014013100000) . 14-11 Left-front 16-11 Right-rear «REMOVE THE HUB BEARING UNIT»(ref-595433-S03792719202014013100000) . 18-11 Left-rear Is the magnetic encoder surface OK? YES : Go to step 5. NO : Clean debris from the appropriate magnetic encoder surface on the wheel bearing or the hub bearing unit. If the DTC is still present, replace the appropriate «WHEEL BEARING»(ref-595434-S13559170152014013100000) or the «HUB BEARING UNIT»(ref-595433-S03792719202014013100000) .
  5. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle for 120 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 12-11, 14-11, 16-11, or 18-11 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 17

Scheme 17: DTC 12-14: Right-Front Wheel Speed Sensor Installation Error; DTC 14-14: Left-Front Wheel Speed Sens
Scheme 17: DTC 12-14: Right-Front Wheel Speed Sensor Installation Error; DTC 14-14: Left-Front Wheel Speed Sens

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
12-14 Right-Front Wheel Speed Sensor Installation Error
14-14 Left-Front Wheel Speed Sensor Installation Error
16-14 Right-Rear Wheel Speed Sensor Installation Error
18-14 Left-Rear Wheel Speed Sensor Installation Error
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Test-drive the vehicle at 31 mph (50 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 12-14 Right-Front Wheel Speed Sensor Installation Error 14-14 Left-Front Wheel Speed Sensor Installation Error 16-14 Right-Rear Wheel Speed Sensor Installation Error 18-14 Left-Rear Wheel Speed Sensor Installation Error Is DTC 12-14, 14-14, 16-14, or 18-14 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. Wheel speed sensor installation check: 1. Turn the ignition switch to LOCK (0). 2. Check that the appropriate wheel speed sensor is properly mounted See or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) or «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) . DTC Appropriate Wheel Speed Sensor 12-14 Right-front 14-14 Left-front 16-14 Right-rear 18-14 Left-rear Is the wheel speed sensor installation OK? YES : Go to step 3. NO : Reinstall the wheel speed sensor, and recheck the mounting position See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) , then go to step 1 .
  3. Wheel speed sensor check (substitution): 1. Turn the ignition switch to LOCK (0). 2. Substitute a known-good wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) . DTC Appropriate Wheel Speed Sensor 12-14 Right-front 14-14 Left-front 16-14 Right-rear 18-14 Left-rear 3. Turn the ignition switch to ON (II). 4. Clear the DTC with the HDS. 5. Turn the ignition switch to LOCK (0). 6. Test-drive the vehicle at 31 mph (50 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 7. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 12-14 Right-Front Wheel Speed Sensor Installation Error 14-14 Left-Front Wheel Speed Sensor Installation Error 16-14 Right-Rear Wheel Speed Sensor Installation Error 18-14 Left-Rear Wheel Speed Sensor Installation Error Is DTC 12-14, 14-14, 16-14, or 18-14 indicated? YES : Go to step 4. NO : Replace the original wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) .
  4. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle at 31 mph (50 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 12-14, 14-14, 16-14, or 18-14 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 18

Scheme 18: DTC 12-15: Right-Front Wheel Speed Sensor Installation Error; DTC 14-15: Left-Front Wheel Speed Sens
Scheme 18: DTC 12-15: Right-Front Wheel Speed Sensor Installation Error; DTC 14-15: Left-Front Wheel Speed Sens

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
12-15 Right-Front Wheel Speed Sensor Installation Error
14-15 Left-Front Wheel Speed Sensor Installation Error
16-15 Right-Rear Wheel Speed Sensor Installation Error
18-15 Left-Rear Wheel Speed Sensor Installation Error
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Test-drive the vehicle at 12 mph (20 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 12-15 Right-Front Wheel Speed Sensor Installation Error 14-15 Left-Front Wheel Speed Sensor Installation Error 16-15 Right-Rear Wheel Speed Sensor Installation Error 18-15 Left-Rear Wheel Speed Sensor Installation Error Is DTC 12-15, 14-15, 16-15, or 18-15 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. Wheel speed sensor installation check: 1. Turn the ignition switch to LOCK (0). 2. Check that the appropriate wheel speed sensor is properly mounted See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) . DTC Appropriate Wheel Speed Sensor 12-15 Right-front 14-15 Left-front 16-15 Right-rear 18-15 Left-rear Is the wheel speed sensor installation OK? YES : Go to step 3. NO : Reinstall the wheel speed sensor, and recheck the mounting position See «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) or «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) , then go to step 1 .
  3. Wheel speed sensor check (substitution): 1. Turn the ignition switch to LOCK (0). 2. Substitute a known-good wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) . DTC Appropriate Wheel Speed Sensor 12-15 Right-front 14-15 Left-front 16-15 Right-rear 18-15 Left-rear 3. Turn the ignition switch to ON (II). 4. Clear the DTC with the HDS. 5. Turn the ignition switch to LOCK (0). 6. Test-drive the vehicle at 12 mph (20 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 7. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 12-15 Right-Front Wheel Speed Sensor Installation Error 14-15 Left-Front Wheel Speed Sensor Installation Error 16-15 Right-Rear Wheel Speed Sensor Installation Error 18-15 Left-Rear Wheel Speed Sensor Installation Error Is DTC 12-15, 14-15, 16-15, or 18-15 indicated? YES : Go to step 4. NO : Replace the original wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) .
  4. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle at 12 mph (20 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 12-15, 14-15, 16-15, or 18-15 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 19

Scheme 19: DTC 121-11: VSA Solenoid Valve Malfunction; DTC 122-11: VSA Solenoid Valve Malfunction; DTC 123-11:
Scheme 19: DTC 121-11: VSA Solenoid Valve Malfunction; DTC 122-11: VSA Solenoid Valve Malfunction; DTC 123-11:

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
121-11 VSA Solenoid Valve Malfunction
122-11 VSA Solenoid Valve Malfunction
123-11 VSA Solenoid Valve Malfunction
124-11 VSA Solenoid Valve Malfunction
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Test-drive the vehicle at 9 mph (15 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 121-11 VSA Solenoid Valve Malfunction 122-11 VSA Solenoid Valve Malfunction 123-11 VSA Solenoid Valve Malfunction 124-11 VSA Solenoid Valve Malfunction Is DTC 121-11, 122-11, 123-11, or 124-11 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle at 9 mph (15 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 121-11, 122-11, 123-11, or 124-11 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 20

Scheme 20: DTC 158-1: ECU Software Update Failure
Scheme 20: DTC 158-1: ECU Software Update Failure

Note. Do not turn the ignition switch to LOCK (0) while updating the VSA modulator-control unit. If you turn the ignition switch to LOCK (0) before completion, the VSA modulator-control unit will be damaged. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
158-1 ECU Software Update Failure
  1. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 3. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 158-1 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 21

Scheme 21: DTC 25-21: Yaw Rate Sensor (Inside of Modulator-Control Unit) Output Signal Malfunction; DTC 26-21:
Scheme 21: DTC 25-21: Yaw Rate Sensor (Inside of Modulator-Control Unit) Output Signal Malfunction; DTC 26-21:

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM . The yaw rate-acceleration sensor is built into the VSA modulator-control unit. Before troubleshooting, check the VSA modulator-control unit for proper mounting. If not properly installed the VSA modulator-control unit may set these codes.

DTC DescriptionDTCFreeze Frame
25-21 Yaw Rate Sensor (Inside of Modulator-Control Unit) Output Signal Malfunction
26-21 Lateral Acceleration Sensor (Inside of Modulator-Control Unit) Output Signal Malfunction
28-21 Longitudinal Acceleration Sensor (Inside of Modulator-Control Unit) Output Signal Malfunction
28-22 Longitudinal Acceleration Sensor (Inside of Modulator-Control Unit) Stuck
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Test-drive the vehicle at 31 mph (50 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 25-21 Yaw Rate Sensor (Inside of Modulator-Control Unit) Output Signal Malfunction 26-21 Lateral Acceleration Sensor (Inside of Modulator-Control Unit) Output Signal Malfunction 28-21 Longitudinal Acceleration Sensor (Inside of Modulator-Control Unit) Output Signal Malfunction 28-22 Longitudinal Acceleration Sensor (Inside of Modulator-Control Unit) Stuck Is DTC 25-21, 26-21, 28-21, or 28-22 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle at 31 mph (50 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 25-21, 26-21, 28-21, or 28-22 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 22

Scheme 22: DTC 27-20: Steering Angle Sensor Internal Circuit Malfunction
Scheme 22: DTC 27-20: Steering Angle Sensor Internal Circuit Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
27-20 Steering Angle Sensor Internal Circuit Malfunction
  1. DTC check: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Start the engine for at least 5 seconds. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 27-20 Steering Angle Sensor Internal Circuit Malfunction 86-11 F-CAN Bus-Off Malfunction 86-19 F-CAN Communication With Steering Angle Sensor Malfunction Is DTC 27-20 indicated? YES : If DTC 27-20 is only indicated, go to step 2. YES : If DTC 86-11 or 86-19 are also indicated, go to «DTC 86-11»(ref-595411-S42139491852014013100000) or «86-19»(ref-595411-S30626733572014013100000) . NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. Steering angle sensor check (substitution): 1. Turn the ignition switch to LOCK (0). 2. «SUBSTITUTE A KNOWN-GOOD STEERING ANGLE SENSOR»(ref-595416-S21284073902014013100000) . 3. Turn the ignition switch to ON (II). 4. Clear the DTC with the HDS. 5. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 6. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 27-20 Steering Angle Sensor Internal Circuit Malfunction Is DTC 27-20 indicated? YES : Go to step 3. NO : «REPLACE THE ORIGINAL STEERING ANGLE SENSOR»(ref-595416-S21284073902014013100000) .
  3. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 2. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 3. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 27-20 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 23

Scheme 23: DTC 27-21: Steering Angle Sensor Output Signal Malfunction
Scheme 23: DTC 27-21: Steering Angle Sensor Output Signal Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
27-21 Steering Angle Sensor Output Signal Malfunction
  1. DTC check: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Start the engine, then turn the steering wheel from lock to lock several times. 5. Test-drive the vehicle at 31 mph (50 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 6. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 27-21 Steering Angle Sensor Output Signal Malfunction 86-11 F-CAN Bus-Off Malfunction 86-19 F-CAN Communication With Steering Angle Sensor Malfunction Is DTC 27-21 indicated? YES : If DTC 27-21 is only indicated, go to step 2. YES : If DTC 86-11 or 86-19 are also indicated, go to «DTC 86-11»(ref-595411-S42139491852014013100000) or «86-19»(ref-595411-S30626733572014013100000) . NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. Steering angle sensor check (substitution): 1. Turn the ignition switch to LOCK (0). 2. «SUBSTITUTE A KNOWN-GOOD STEERING ANGLE SENSOR»(ref-595416-S21284073902014013100000) . 3. Turn the ignition switch to ON (II). 4. Clear the DTC with the HDS. 5. Turn the ignition switch to LOCK (0). 6. Start the engine, then turn the steering wheel from lock to lock several times. 7. Test-drive the vehicle at 31 mph (50 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 8. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 27-21 Steering Angle Sensor Output Signal Malfunction Is DTC 27-21 indicated? YES : Go to step 3. NO : «REPLACE THE ORIGINAL STEERING ANGLE SENSOR»(ref-595416-S21284073902014013100000) .
  3. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Start the engine, then turn the steering wheel from lock to lock several times. 4. Test-drive the vehicle at 31 mph (50 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 27-21 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 24

Scheme 24: DTC 31-11: ABS Solenoid Valve Malfunction; DTC 32-11: ABS Solenoid Valve Malfunction; DTC 33-11: ABS
Scheme 24: DTC 31-11: ABS Solenoid Valve Malfunction; DTC 32-11: ABS Solenoid Valve Malfunction; DTC 33-11: ABS

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
31-11 ABS Solenoid Valve Malfunction
32-11 ABS Solenoid Valve Malfunction
33-11 ABS Solenoid Valve Malfunction
34-11 ABS Solenoid Valve Malfunction
35-11 ABS Solenoid Valve Malfunction
36-11 ABS Solenoid Valve Malfunction
37-11 ABS Solenoid Valve Malfunction
38-11 ABS Solenoid Valve Malfunction
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 31-11 ABS Solenoid Valve Malfunction 32-11 ABS Solenoid Valve Malfunction 33-11 ABS Solenoid Valve Malfunction 34-11 ABS Solenoid Valve Malfunction 35-11 ABS Solenoid Valve Malfunction 36-11 ABS Solenoid Valve Malfunction 37-11 ABS Solenoid Valve Malfunction 38-11 ABS Solenoid Valve Malfunction Is DTC 31-11, 32-11, 33-11, 34-11, 35-11, 36-11, 37-11, or 38-11 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 3. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 31-11, 32-11, 33-11, 34-11, 35-11, 36-11, 37-11, or 38-11 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 25

Scheme 25: DTC 51-12: Motor Power Source Circuit Malfunction; DTC 51-80: Motor Malfunction; DTC 52-11: Motor St
Scheme 25: DTC 51-12: Motor Power Source Circuit Malfunction; DTC 51-80: Motor Malfunction; DTC 52-11: Motor St

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
51-12 Motor Power Source Circuit Malfunction
51-80 Motor Malfunction
52-11 Motor Stuck OFF

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27
  1. DTC check: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Turn the ignition switch to ON (II), then wait for at least 20 seconds or more. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 51-12 Motor Power Source Circuit Malfunction 51-80 Motor Malfunction 52-11 Motor Stuck OFF 53-11 Motor Relay Stuck ON Is DTC 51-12, 51-80, or 52-11 indicated? YES : If DTC 51-12, 51-80, or 52-11 are only indicated, go to step 2. YES : If DTC 53-11 is also indicated, go to «DTC 53-11»(ref-595411-S27921773082014013100000) . NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. Fuse check: 1. Turn the ignition switch to LOCK (0). 2. Check the following fuse. Fuse No. A1-3 (40 A) Location Under-hood fuse/relay box Is the fuse OK? YES : The fuse is OK. Reinstall the fuse, then go to step 5 . NO : Go to step 3.
  3. Shorted wire check (+B ABS/VSA MTR line): 1. Disconnect the following connector. VSA modulator-control unit 38P connector 2. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) VSA modulator-control unit 38P connector: disconnected Test circuit +B ABS/VSA MTR Test point 1 VSA modulator-control unit 38P connector No. 2 (RED) Test point 2 Body ground Is there continuity? YES : Repair a short to body ground in the wire between the No. A1-3 (40 A) fuse in the under-hood fuse/relay box and the VSA modulator-control unit. NO : The +B ABS/VSA MTR wire is not shorted to ground. Install a new No. A1-3 (40 A) fuse in the under-hood fuse/relay box, then go to step 4.
  4. VSA modulator-control unit check: 1. Reconnect the following connector. VSA modulator-control unit 38P connector 2. Turn the ignition switch to ON (II). 3. Clear the DTC with the HDS. 4. Turn the ignition switch to LOCK (0). 5. Turn the ignition switch to ON (II), then wait for at least 20 seconds or more. 6. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 51-12 Motor Power Source Circuit Malfunction 51-80 Motor Malfunction 52-11 Motor Stuck OFF Is DTC 51-12, 51-80, or 52-11 indicated? YES : Go to step 6 . NO : The troubleshooting is complete.
  5. Open wire check (+B ABS/VSA MTR line): 1. Disconnect the following connector. VSA modulator-control unit 38P connector 2. Measure the voltage between test points 1 and 2. Test condition IG LOCK (0) VSA modulator-control unit 38P connector: disconnected Test circuit +B ABS/VSA MTR Test point 1 VSA modulator-control unit 38P connector No. 2 (RED) Test point 2 Body ground Is there battery voltage? YES : The +B ABS/VSA MTR wire is OK. Go to step 6. NO : Repair an open in the wire between the No. A1-3 (40 A) fuse in the under-hood fuse/relay box and the VSA modulator-control unit.
  6. VSA modulator-control unit check (update): 1. Reconnect the following connector. VSA modulator-control unit 38P connector (if disconnected) 2. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 3. Turn the ignition switch to LOCK (0). 4. Turn the ignition switch to ON (II), then wait for at least 20 seconds or more. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 51-12, 51-80, or 52-11 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 28

Scheme 28: DTC 51-13: Motor Drive Circuit Malfunction
Scheme 28: DTC 51-13: Motor Drive Circuit Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
51-13 Motor Drive Circuit Malfunction
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Test-drive the vehicle at 25 mph (40 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 51-13 Motor Drive Circuit Malfunction Is DTC 51-13 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle at 25 mph (40 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 51-13 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 29

Scheme 29: DTC 53-11: Motor Relay Stuck ON
Scheme 29: DTC 53-11: Motor Relay Stuck ON

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
53-11 Motor Relay Stuck ON

Scheme 30

Scheme 30
Scheme 30
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 53-11 Motor Relay Stuck ON Is DTC 53-11 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. Open wire check (GND line): 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. VSA modulator-control unit 38P connector 3. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) VSA modulator-control unit 38P connector: disconnected Test circuit GND Test point 1 VSA modulator-control unit 38P connector No. 1 (BLK) Test point 2 Body ground Is there continuity? YES : The GND wire is OK. Go to step 3. NO : Repair an open in the wire between the VSA modulator-control unit and body ground (G201).
  3. VSA modulator-control unit check (update): 1. Reconnect the following connector. VSA modulator-control unit 38P connector 2. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 3. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 53-11 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 31

Scheme 31: DTC 54-13: Fail-Safe Relay Power Source Malfunction
Scheme 31: DTC 54-13: Fail-Safe Relay Power Source Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
54-13 Fail-Safe Relay Power Source Malfunction
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 54-13 Fail-Safe Relay Power Source Malfunction Is DTC 54-13 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 3. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 54-13 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 32

Scheme 32: DTC 54-14: Fail-Safe Relay Drive Circuit Malfunction
Scheme 32: DTC 54-14: Fail-Safe Relay Drive Circuit Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
54-14 Fail-Safe Relay Drive Circuit Malfunction
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Test-drive the vehicle at 9 mph (15 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 54-14 Fail-Safe Relay Drive Circuit Malfunction Is DTC 54-14 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle at 9 mph (15 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 54-14 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 33

Scheme 33: DTC 61-12: Modulator-Control Unit Power Source Circuit (IG) Low Voltage
Scheme 33: DTC 61-12: Modulator-Control Unit Power Source Circuit (IG) Low Voltage

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
61-12 Modulator-Control Unit Power Source Circuit (IG) Low Voltage

Scheme 34

Scheme 34
Scheme 34
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Start the engine, and warm it up to normal operating temperature (the radiator fan comes on). 5. Test-drive the vehicle at 6 mph (10 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 6. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 61-12 Modulator-Control Unit Power Source Circuit (IG) Low Voltage Is DTC 61-12 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting, then «CHECK THE BATTERY»(/honda/cr-v/iv-2011-2015/remont/body-electrical/#battery) .
  2. VSA modulator-control unit check: 1. Check and note the parameter(s) below with the HDS. Signal Current conditions Values Unit BATTERY VOLTAGE 2. Using a voltmeter, measure and note the voltage across the battery terminals. NOTE: If the voltage is below 9.5 V, «CHECK THE BATTERY»(/honda/cr-v/iv-2011-2015/remont/body-electrical/#battery) , and check the PGM-FI DTCs See «HOW TO TROUBLESHOOT THE FUEL AND EMISSIONS SYSTEMS»(ref-595375-S37864539652014013100000) or «HOW TO TROUBLESHOOT THE A/T SYSTEM»(ref-595372-S19132079362014013100000) . 3. Compare the voltage noted in step 2-1 to the voltage in step 2-2. Is the difference between the two voltage readings less than 3 V? YES : Check the «BATTERY»(/honda/cr-v/iv-2011-2015/remont/body-electrical/#battery) , and check the PGM-FI DTCs See «HOW TO TROUBLESHOOT THE FUEL AND EMISSIONS SYSTEMS»(ref-595375-S37864539652014013100000) or «HOW TO TROUBLESHOOT THE A/T SYSTEM»(ref-595372-S19132079362014013100000) . NO : Go to step 3.
  3. Open wire check (IG1 VSA/ABS line): 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. VSA modulator-control unit 38P connector 3. Turn the ignition switch to ON (II). 4. Measure the voltage between test points 1 and 2. Test condition IG ON (II) VSA modulator-control unit 38P connector: disconnected Test circuit IG1 VSA/ABS Test point 1 VSA modulator-control unit 38P connector No. 36 (PUR) Test point 2 Body ground Is there battery voltage? YES : The IG1 VSA/ABS wire is OK. Go to step 4. NO : Repair an open or high resistance in the wire between the No. B24 (7.5 A) fuse in the under-dash fuse/relay box and the VSA modulator-control unit.
  4. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Start the engine, and warm it up to normal operating temperature (the radiator fan comes on). 4. Test-drive the vehicle at 6 mph (10 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 61-12 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 35

Scheme 35: DTC 62-11: Modulator-Control Unit Power Source Circuit (IG) High Voltage
Scheme 35: DTC 62-11: Modulator-Control Unit Power Source Circuit (IG) High Voltage

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
62-11 Modulator-Control Unit Power Source Circuit (IG) High Voltage
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Start the engine. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 62-11 Modulator-Control Unit Power Source Circuit (IG) High Voltage Is DTC 62-11 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. VSA modulator-control unit check: 1. With the engine still running, check and note the parameter(s) below with the HDS. Signal Current conditions Values Unit BATTERY VOLTAGE 2. Using a voltmeter, measure and note the voltage across the battery terminals. NOTE: If the voltage is more than 15.1 V, troubleshoot the PGM-FI DTCs See «HOW TO TROUBLESHOOT THE A/T SYSTEM»(ref-595372-S19132079362014013100000) or «HOW TO TROUBLESHOOT THE FUEL AND EMISSIONS SYSTEMS»(ref-595375-S37864539652014013100000) . 3. Compare the voltage noted in step 2-1 to the voltage in step 2-2. Is the difference between the two voltage readings less than 3 V? YES : Check the «BATTERY»(/honda/cr-v/iv-2011-2015/remont/body-electrical/#battery) , and check the PGM-FI DTCs See «HOW TO TROUBLESHOOT THE A/T SYSTEM»(ref-595372-S19132079362014013100000) or «HOW TO TROUBLESHOOT THE FUEL AND EMISSIONS SYSTEMS»(ref-595375-S37864539652014013100000) . NO : Go to step 3.
  3. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Start the engine. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 62-11 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 36

Scheme 36: DTC 65-11: Brake Fluid Level Switch Circuit Malfunction
Scheme 36: DTC 65-11: Brake Fluid Level Switch Circuit Malfunction

Note. Bleeding the brake system while the ignition switch is ON (II) can cause this DTC. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
65-11 Brake Fluid Level Switch Circuit Malfunction

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38
  1. Brake fluid level check: 1. Check the brake fluid level in the master cylinder reservoir. Is the brake fluid level OK? YES : Go to step 2. NO «INSPECT THE BRAKE LINES AND HOSES FOR LEAKS»(ref-595379-S19061388902014013100000) , and repair as needed. Inspect the brake pads: «FRONT»(ref-595378-S41336708142014013100000) , «REAR»(ref-595378-S36062725572014013100000) , and replace worn out brake pads. Add brake fluid and recheck.
  2. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 4. Wait for at least 60 seconds. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 65-11 Brake Fluid Level Switch Circuit Malfunction Is DTC 65-11 indicated? YES : The failure is duplicated. Go to step 3. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  3. Gauge control module check: 1. Release the parking brake. 2. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 3. Wait for at least 60 seconds. 4. Check the brake system indicator in the gauge control module. Does the indicator come on then go off? YES : Go to step 6 . NO : Go to step 4.
  4. Brake fluid level switch check: 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. Brake fluid level switch 2P connector 3. On the switch side, check for continuity between test points 1 and 2. Test condition IG LOCK (0) Brake fluid level switch 2P connector: disconnected Test circuit BRAKE LEVEL SW, GND Test point 1 Brake fluid level switch 2P connector No. 1 Test point 2 Brake fluid level switch 2P connector No. 2 Is there continuity? YES : Replace the master cylinder (brake fluid level switch is included) See «BRAKE MASTER CYLINDER INSPECTION»(ref-595379-S09369673432014013100000) or «BRAKE MASTER CYLINDER REMOVAL AND INSTALLATION»(ref-595378-S08592977052014013100000) . NO : Go to step 5.
  5. Shorted wire check (BRAKE LEVEL SW line): 1. Disconnect the following connector. Gauge control module 32P connector 2. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) Brake fluid level switch 2P connector: disconnected Gauge control module 32P connector: disconnected Test circuit BRAKE LEVEL SW Test point 1 Brake fluid level switch 2P connector No. 2 (GRY) Test point 2 Body ground Is there continuity? YES : Repair a short to body ground in the wire between the gauge control module and the brake fluid level switch. NO : The BRAKE LEVEL SW wire is OK. Replace the gauge control module See «Rewriting the ODO Data and Transferring the Maintenance Minder™ Data to a New Gauge Control Module»(ref-595382-S29459770492014013100000) or «GAUGE CONTROL MODULE REMOVAL AND INSTALLATION»(ref-595382-S39482976312014013100000) .
  6. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 2. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 3. Wait for at least 60 seconds. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 65-11 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 39

Scheme 39: DTC 66-13: Pressure Sensor Malfunction
Scheme 39: DTC 66-13: Pressure Sensor Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
66-13 Pressure Sensor Malfunction
  1. Brake pedal height check: 1. Check the brake pedal height See «BRAKE PEDAL REMOVAL AND INSTALLATION»(ref-595378-S34794043342014013100000) or «BRAKE PEDAL AND BRAKE PEDAL POSITION SWITCH ADJUSTMENT»(ref-595378-S25209739752014013100000) . Is brake pedal height OK? YES : Go to step 2. NO : Adjust the brake pedal height See «BRAKE PEDAL REMOVAL AND INSTALLATION»(ref-595378-S34794043342014013100000) or «BRAKE PEDAL AND BRAKE PEDAL POSITION SWITCH ADJUSTMENT»(ref-595378-S25209739752014013100000) .
  2. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 66-13 Pressure Sensor Malfunction Is DTC 66-13 indicated? YES : The failure is duplicated. Go to step 3. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  3. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 2. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 3. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 66-13 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 40

Scheme 40: DTC 66-14: Pressure Sensor Sensitivity Malfunction
Scheme 40: DTC 66-14: Pressure Sensor Sensitivity Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
66-14 Pressure Sensor Sensitivity Malfunction
  1. Brake pedal height check: 1. Check the brake pedal height See «BRAKE PEDAL REMOVAL AND INSTALLATION»(ref-595378-S34794043342014013100000) or «BRAKE PEDAL AND BRAKE PEDAL POSITION SWITCH ADJUSTMENT»(ref-595378-S25209739752014013100000) . Is brake pedal height OK? YES : Go to step 2. NO : Adjust the brake pedal height See «BRAKE PEDAL REMOVAL AND INSTALLATION»(ref-595378-S34794043342014013100000) or «BRAKE PEDAL AND BRAKE PEDAL POSITION SWITCH ADJUSTMENT»(ref-595378-S25209739752014013100000) .
  2. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Test-drive the vehicle at 9 mph (15 km/h) or more for 60 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 66-14 Pressure Sensor Sensitivity Malfunction Is DTC 66-14 indicated? YES : The failure is duplicated. Go to step 3. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  3. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle at 9 mph (15 km/h) or more for 60 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 66-14 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 41

Scheme 41: DTC 68-12: Brake Pedal Position Switch Stuck ON
Scheme 41: DTC 68-12: Brake Pedal Position Switch Stuck ON

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
68-12 Brake Pedal Position Switch Stuck ON

Scheme 42

Scheme 42
Scheme 42
  1. Brake pedal position switch performance check 1: 1. Check the parameter(s) below with the HDS while pressing the brake pedal. Signal Current conditions Values Unit BRAKE SWITCH Does it indicate ON when the pedal is pressed, and OFF when the pedal is released? YES : Go to step 2. NO : Go to step 3 .
  2. Problem verification: 1. Clear the DTC with the HDS. 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle at 9 mph (15 km/h) or more for 60 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 68-12 Brake Pedal Position Switch Stuck ON Is DTC 68-12 indicated? YES : The failure is duplicated. Go to step 6 . NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  3. Brake pedal position switch performance check 2: 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. Brake pedal position switch 4P connector 3. Check the parameter(s) below with the HDS. Signal Current conditions Values Unit BRAKE SWITCH Does the indicator change from ON to OFF? YES : Replace the brake pedal position switch See «BRAKE PEDAL REMOVAL AND INSTALLATION»(ref-595378-S34794043342014013100000) or «BRAKE PEDAL AND BRAKE PEDAL POSITION SWITCH ADJUSTMENT»(ref-595378-S25209739752014013100000) or «PCM UPDATE»(ref-595375-S42937672232014013100000) or «PCM REMOVAL AND INSTALLATION»(ref-595374-S31779448642014013100000) . NO : Go to step 4.
  4. Shorted wire check (STOP SW line to power): 1. Turn the ignition switch to LOCK (0). 2. Short the SCS line with the HDS. 3. Disconnect the following connector. PCM connector A (49P) 4. Turn the ignition switch to ON (II). 5. Measure the voltage between test points 1 and 2. Test condition IG ON (II) Brake pedal position switch 4P connector: disconnected PCM connector A (49P): disconnected Test circuit STOP SW Test point 1 Brake pedal position switch 4P connector No. 1 (BLU) Test point 2 Body ground Is there 0.1 V or more? YES : Repair a short to power in the wire between the PCM and the brake pedal position switch. NO : The STOP SW wire is OK. Go to step 5.
  5. PCM check (update or substitution): 1. Turn the ignition switch to LOCK (0). 2. Reconnect the following connectors. Brake pedal position switch 4P connector PCM connector A (49P) 3. Update the PCM if it does not have the latest software See «PCM REMOVAL AND INSTALLATION»(ref-595374-S31779448642014013100000) or «PCM UPDATE»(ref-595375-S42937672232014013100000) , or substitute a known-good PCM See «PCM UPDATE»(ref-595375-S42937672232014013100000) or «PCM REMOVAL AND INSTALLATION»(ref-595374-S31779448642014013100000) . 4. Clear the DTC with the HDS. 5. Turn the ignition switch to LOCK (0). 6. Test-drive the vehicle at 9 mph (15 km/h) or more for 60 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 7. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 68-12 Brake Pedal Position Switch Stuck ON Is DTC 68-12 indicated? YES : Go to step 6. NO : If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) .
  6. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle at 9 mph (15 km/h) or more for 60 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 68-12 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 43

Scheme 43: DTC 68-13: Brake Pedal Position Switch Circuit Malfunction
Scheme 43: DTC 68-13: Brake Pedal Position Switch Circuit Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
68-13 Brake Pedal Position Switch Circuit Malfunction

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Turn the ignition switch to ON (II), then press the brake pedal hard for 1 second or more. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 68-13 Brake Pedal Position Switch Circuit Malfunction Is DTC 68-13 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. VSA modulator-control unit performance check: 1. Start the engine. 2. Check the parameter(s) below with the HDS. Do not press the brake pedal. Signal Current conditions Values Unit BRAKE PRESSURE Is there 8 MPa or less? YES : Go to step 3. NO : «CHECK FOR BRAKE DRAG»(ref-595379-S32506699502014013100000) or a misadjusted brake pedal position switch See «BRAKE PEDAL AND BRAKE PEDAL POSITION SWITCH ADJUSTMENT»(ref-595378-S25209739752014013100000) or «BRAKE PEDAL REMOVAL AND INSTALLATION»(ref-595378-S34794043342014013100000) . If they are normal, go to step 12 .
  3. Brake pedal position switch performance check 1: 1. Check the parameter(s) below with the HDS while pressing the brake pedal. Signal Current conditions Values Unit BRAKE SWITCH Does it indicate ON when the pedal is pressed, and OFF when the pedal is released? YES : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting. NO : Go to step 4.
  4. Brake pedal position switch performance check 2: 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. Brake pedal position switch 4P connector 3. Connect terminals 1 and 2 with a jumper wire. Terminal 1 Brake pedal position switch 4P connector No. 1 (BLU) Terminal 2 Brake pedal position switch 4P connector No. 2 (GRN) 4. Turn the ignition switch to ON (II). 5. Check the parameter(s) below with the HDS. Signal Current conditions Values Unit BRAKE SWITCH Does it indicate ON? YES : Check the brake pedal position switch adjustment See «BRAKE PEDAL REMOVAL AND INSTALLATION»(ref-595378-S34794043342014013100000) or «BRAKE PEDAL AND BRAKE PEDAL POSITION SWITCH ADJUSTMENT»(ref-595378-S25209739752014013100000) . If it is OK, replace the brake pedal position switch See «BRAKE PEDAL POSITION SWITCH REMOVAL AND INSTALLATION»(ref-595378-S12912584612014013100000) or «BRAKE PEDAL AND BRAKE PEDAL POSITION SWITCH ADJUSTMENT»(ref-595378-S25209739752014013100000) . NO : Go to step 5.
  5. Fuse check: 1. Turn the ignition switch to LOCK (0). 2. Disconnect the jumper wire. 3. Check the following fuse. Fuse No. A16 (10 A) Location Under-hood fuse/relay box Is the fuse OK? YES : The fuse is OK. Reinstall the fuse, then go to step 9 . NO : Go to step 6.
  6. Shorted wire check (+B STOP line): 1. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) Brake pedal position switch 4P connector: disconnected Test circuit +B STOP Test point 1 Brake pedal position switch 4P connector No. 2 (GRN) Test point 2 Body ground Is there continuity? YES : Repair a short to body ground in the wire between the No. A16 (10 A) fuse in the under-hood fuse/relay box and the brake pedal position switch. NO : The +B STOP wire is not shorted to body ground. Go to step 7.
  7. Shorted wire check (STOP SW line to power): 1. Short the SCS line with the HDS. 2. Disconnect the following connector. PCM connector A (49P) 3. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) Brake pedal position switch 4P connector: disconnected PCM connector A (49P): disconnected Test circuit STOP SW Test point 1 Brake pedal position switch 4P connector No. 1 (BLU) Test point 2 Body ground Is there continuity? YES : Repair a short to body ground in the wire between the brake pedal position switch and the PCM. NO : The STOP SW wire is not short to body ground. Install a new No. A16 (10 A) fuse in the under-hood fuse/relay box, then go to step 8.
  8. VSA modulator-control unit check: 1. Reconnect the following connectors. Brake pedal position switch 4P connector PCM connector A (49P) 2. Turn the ignition switch to ON (II). 3. Clear the DTC with the HDS. 4. Turn the ignition switch to LOCK (0). 5. Turn the ignition switch to ON (II), then press the brake pedal hard for 1 second or more. 6. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 68-13 Brake Pedal Position Switch Circuit Malfunction Is DTC 68-13 indicated? YES : Go to step 12 . NO : The troubleshooting is complete.
  9. Open wire check (+B STOP line): 1. Measure the voltage between test points 1 and 2. Test condition IG LOCK (0) Brake pedal position switch 4P connector: disconnected Test circuit +B STOP Test point 1 Brake pedal position switch 4P connector No. 2 (GRN) Test point 2 Body ground Is there battery voltage? YES : The +B STOP wire is OK. Go to step 10. NO : Repair an open in the wire between the No. A16 (10 A) fuse in the under-hood fuse/relay box and the brake pedal position switch.
  10. Open wire check (STOP SW line): 1. Short the SCS line with the HDS. 2. Disconnect the following connector. PCM connector A (49P) 3. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) Brake pedal position switch 4P connector: disconnected PCM connector A (49P): disconnected Test circuit STOP SW Test point 1 Brake pedal position switch 4P connector No. 1 (BLU) Test point 2 PCM connector A (49P) No. 13 (BLU) Is there continuity? YES : The STOP SW wires is OK. Go to step 11. NO : Repair an open in the wire between the PCM and the brake pedal position switch.
  11. PCM check (update or substitution): 1. Reconnect the following connectors. Brake pedal position switch 4P connector PCM connector A (49P) 2. Update the PCM if it does not have the latest software See «PCM UPDATE»(ref-595375-S42937672232014013100000) or «PCM REMOVAL AND INSTALLATION»(ref-595374-S31779448642014013100000) , or substitute a known-good PCM See «PCM UPDATE»(ref-595375-S42937672232014013100000) or «PCM REMOVAL AND INSTALLATION»(ref-595374-S31779448642014013100000) . 3. Clear the DTC with the HDS. 4. Turn the ignition switch to LOCK (0). 5. Turn the ignition switch to ON (II), then press the brake pedal hard for 1 second or more. 6. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 68-13 Brake Pedal Position Switch Circuit Malfunction Is DTC 68-13 indicated? YES : Go to step 12. NO : If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM See «PCM UPDATE»(ref-595375-S42937672232014013100000) or «PCM REMOVAL AND INSTALLATION»(ref-595374-S31779448642014013100000) .
  12. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Turn the ignition switch to ON (II), then press the brake pedal hard for 1 second or more. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 68-13 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 49

Scheme 49: DTC 71-80: Abnormal Slip Malfunction
Scheme 49: DTC 71-80: Abnormal Slip Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
71-80 Abnormal Slip Malfunction
  1. Tire check: 1. Turn the ignition switch to LOCK (0). 2. «CHECK ALL FOUR TIRES FOR SIZE, INFLATION, AND WEAR»(/honda/cr-v/iv-2011-2015/remont/wheel-alignment/#wheel-alignment) . Are all four tires the correct size, properly inflated, and worn evenly? YES : Go to step 2. NO : Install the correct tires, a known-good set of tires, or set the tires to the correct pressure, and retest by test-driving.
  2. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Test-drive the vehicle at 12 mph (20 km/h) or more for 90 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 71-80 Abnormal Slip Malfunction Is DTC 71-80 indicated? YES : The failure is duplicated. Go to step 3. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  3. Wheel speed sensor performance check: 1. Test-drive the vehicle at 12 mph (20 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 2. Check the parameter(s) below with the HDS. Signal Current conditions Values Unit RIGHT FRONT WHEEL SPEED LEFT FRONT WHEEL SPEED RIGHT REAR WHEEL SPEED LEFT REAR WHEEL SPEED Are one of the four values different? YES : Go to step 4. NO : Go to step 6 .
  4. Wheel speed sensor check (substitution): 1. Turn the ignition switch to LOCK (0). 2. Substitute a known-good wheel speed sensor See «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) or «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) . Appropriate Wheel Speed Sensor Right-front Left-front Right-rear Left-rear 3. Turn the ignition switch to ON (II). 4. Clear the DTC with the HDS. 5. Turn the ignition switch to LOCK (0). 6. Test-drive the vehicle at 12 mph (20 km/h) or more for 90 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 7. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 71-80 Abnormal Slip Malfunction Is DTC 71-80 indicated? YES : Go to step 5. NO : Replace the original wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) .
  5. Magnetic encoder check: 1. Turn the ignition switch to LOCK (0). 2. Inspect the magnetic encoder for damage, debris, and correct installation. Front: «REMOVE THE DRIVESHAFT OUTBOARD JOINT FROM THE APPROPRIATE WHEEL HUB»(ref-595434-S13559170152014013100000) . Rear: «REMOVE THE HUB BEARING UNIT»(ref-595433-S03792719202014013100000) . Is the magnetic encoder surface OK? YES : Go to step 6. NO : Clean debris from the magnetic encoder surface on the wheel bearing or the hub bearing unit. If the DTC is still present, replace the appropriate «WHEEL BEARING»(ref-595434-S13559170152014013100000) or the «HUB BEARING UNIT»(ref-595433-S03792719202014013100000) .
  6. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle at 12 mph (20 km/h) or more for 90 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 71-80 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 50

Scheme 50: DTC 71-81: Right-Front Wheel Abnormal Slip Malfunction; DTC 71-82: Left-Front Wheel Abnormal Slip Ma
Scheme 50: DTC 71-81: Right-Front Wheel Abnormal Slip Malfunction; DTC 71-82: Left-Front Wheel Abnormal Slip Ma

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
71-81 Right-Front Wheel Abnormal Slip Malfunction
71-82 Left-Front Wheel Abnormal Slip Malfunction
71-83 Right-Rear Wheel Abnormal Slip Malfunction
71-84 Left-Rear Wheel Abnormal Slip Malfunction
  1. Tire check: 1. Turn the ignition switch to LOCK (0). 2. «CHECK ALL FOUR TIRES FOR SIZE, INFLATION, AND WEAR»(/honda/cr-v/iv-2011-2015/remont/wheel-alignment/#wheel-alignment) . Are all four tires the correct size, properly inflated, and worn evenly? YES : Go to step 2. NO : Install the correct tires, a known-good set of tires, or set the tires to the correct pressure, and retest by test-driving.
  2. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Test-drive the vehicle at 12 mph (20 km/h) or more for 90 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 71-81 Right-Front Wheel Abnormal Slip Malfunction 71-82 Left-Front Wheel Abnormal Slip Malfunction 71-83 Right-Rear Wheel Abnormal Slip Malfunction 71-84 Left-Rear Wheel Abnormal Slip Malfunction Is DTC 71-81, 71-82, 71-83, or 71-84 indicated? YES : The failure is duplicated. Go to step 3. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  3. Wheel speed sensor performance check: 1. Test-drive the vehicle at 12 mph (20 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 2. Check the parameter(s) below with the HDS. Signal Current conditions Values Unit RIGHT FRONT WHEEL SPEED LEFT FRONT WHEEL SPEED RIGHT REAR WHEEL SPEED LEFT REAR WHEEL SPEED Is any one of the four values different? YES : Go to step 4. NO : Go to step 6 .
  4. Wheel speed sensor check (substitution): 1. Turn the ignition switch to LOCK (0). 2. Substitute a known-good wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) . Appropriate Wheel Speed Sensor Right-front Left-front Right-rear Left-rear 3. Turn the ignition switch to ON (II). 4. Clear the DTC with the HDS. 5. Turn the ignition switch to LOCK (0). 6. Test-drive the vehicle at 12 mph (20 km/h) or more for 90 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 7. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 71-81 Right-Front Wheel Abnormal Slip Malfunction 71-82 Left-Front Wheel Abnormal Slip Malfunction 71-83 Right-Rear Wheel Abnormal Slip Malfunction 71-84 Left-Rear Wheel Abnormal Slip Malfunction Is DTC 71-81, 71-82, 71-83, or 71-84 indicated? YES : Go to step 5. NO : Replace the original wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) .
  5. Magnetic encoder check: 1. Turn the ignition switch to LOCK (0). 2. Inspect the magnetic encoder for damage, debris, and correct installation. Front: «REMOVE THE DRIVESHAFT OUTBOARD JOINT FROM THE APPROPRIATE WHEEL HUB»(ref-595434-S13559170152014013100000) . Rear: «REMOVE THE HUB BEARING UNIT»(ref-595433-S03792719202014013100000) . Is the magnetic encoder surface OK? YES : Go to step 6. NO : Clean debris from the magnetic encoder surface on the wheel bearing or the hub bearing unit. If the DTC is still present, replace the appropriate «WHEEL BEARING»(ref-595434-S13559170152014013100000) or the «HUB BEARING UNIT»(ref-595433-S03792719202014013100000) .
  6. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle at 12 mph (20 km/h) or more for 90 seconds or more. NOTE: Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 71-81, 71-82, 71-83, or 71-84 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) , then go to step 2 and recheck. If the DTC is still present, replace the appropriate «WHEEL BEARING»(ref-595434-S13559170152014013100000) or the «HUB BEARING UNIT»(ref-595433-S03792719202014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 51

Scheme 51: DTC 81-11: Modulator-Control Unit Internal Circuit Malfunction
Scheme 51: DTC 81-11: Modulator-Control Unit Internal Circuit Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
81-11 Modulator-Control Unit Internal Circuit Malfunction
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 81-11 Modulator-Control Unit Internal Circuit Malfunction Is DTC 81-11 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 3. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 81-11 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 52

Scheme 52: DTC 81-19: Yaw Rate Sensor (Inside of Modulator-Control Unit) Internal Circuit Malfunction; DTC 81-2
Scheme 52: DTC 81-19: Yaw Rate Sensor (Inside of Modulator-Control Unit) Internal Circuit Malfunction; DTC 81-2

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM . The yaw rate-acceleration sensor is built into the VSA modulator-control unit. Before troubleshooting, check the VSA modulator-control unit for proper mounting. If not properly installed the VSA modulator-control unit may set these codes.

DTC DescriptionDTCFreeze Frame
81-19 Yaw Rate Sensor (Inside of Modulator-Control Unit) Internal Circuit Malfunction
81-20 Acceleration Sensor (Inside of Modulator-Control Unit) Internal Circuit Malfunction
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 81-19 Yaw Rate Sensor (Inside of Modulator-Control Unit) Internal Circuit Malfunction 81-20 Acceleration Sensor (Inside of Modulator-Control Unit) Internal Circuit Malfunction Is DTC 81-19 or 81-20 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) , «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 3. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 81-19 or 81-20 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 53

Scheme 53: DTC 83-11: ECM/PCM (PGM-FI) Malfunction
Scheme 53: DTC 83-11: ECM/PCM (PGM-FI) Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
83-11 ECM/PCM (PGM-FI) Malfunction
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 83-11 ECM/PCM (PGM-FI) Malfunction Is DTC 83-11 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. PGM-FI DTCs check: 1. Check for PGM-FI DTCs with the HDS. DTC Description Confirmed DTC Pending DTC Freeze Frame Are any DTCs indicated? YES : Go to indicated DTC's troubleshooting. NO : Go to step 3.
  3. PCM check (update or substitution): 1. Update the PCM if it does not have the latest software See «PCM REMOVAL AND INSTALLATION»(ref-595374-S31779448642014013100000) or «PCM UPDATE»(ref-595375-S42937672232014013100000) , or substitute a known-good PCM See «PCM REMOVAL AND INSTALLATION»(ref-595374-S31779448642014013100000) or «PCM UPDATE»(ref-595375-S42937672232014013100000) . 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 83-11 ECM/PCM (PGM-FI) Malfunction Is DTC 83-11 indicated? YES : Go to step 4. NO : If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM See «PCM REMOVAL AND INSTALLATION»(ref-595374-S31779448642014013100000) or «PCM UPDATE»(ref-595375-S42937672232014013100000) .
  4. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 3. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 83-11 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 54

Scheme 54: DTC 86-11: F-CAN Bus-Off Malfunction
Scheme 54: DTC 86-11: F-CAN Bus-Off Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
86-11 F-CAN Bus-Off Malfunction

Scheme 55

Scheme 55
Scheme 55
  1. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Start the engine for at least 5 seconds. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 86-11 F-CAN Bus-Off Malfunction Is DTC 86-11 indicated? YES : The failure is duplicated. Go to step 2. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. Open wire check (F CAN-L, F CAN-H lines): 1. Turn the ignition switch to LOCK (0). 2. Short the SCS line with the HDS. 3. Disconnect the following connectors. VSA modulator-control unit 38P connector PCM connector A (49P) 4. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) VSA modulator-control unit 38P connector: disconnected PCM connector A (49P): disconnected Test circuit F CAN-L Test point 1 VSA modulator-control unit 38P connector No. 26 (RED) Test point 2 PCM connector A (49P) No. 4 (RED) Test circuit F CAN-H Test point 1 VSA modulator-control unit 38P connector No. 38 (WHT) Test point 2 PCM connector A (49P) No. 3 (WHT) Is there continuity? YES : The F CAN-L, F CAN-H wires are OK. Go to step 3. NO : Repair an open in the wire between the PCM and the VSA modulator-control unit.
  3. VSA modulator-control unit check (update): 1. Reconnect the following connectors. VSA modulator-control unit 38P connector PCM connector A (49P) 2. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 3. Turn the ignition switch to LOCK (0). 4. Start the engine for at least 5 seconds. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 86-11 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 56

Scheme 56: DTC 86-12: F-CAN Communication With ECM/PCM (PGM-FI) Malfunction; DTC 86-13: F-CAN Communication Wit
Scheme 56: DTC 86-12: F-CAN Communication With ECM/PCM (PGM-FI) Malfunction; DTC 86-13: F-CAN Communication Wit

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
86-12 F-CAN Communication With ECM/PCM (PGM-FI) Malfunction
86-13 F-CAN Communication With PCM (AT/CVT) Malfunction

Scheme 57

Scheme 57
Scheme 57
  1. DTC check: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Start the engine for at least 5 seconds. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 86-11 F-CAN Bus-Off Malfunction 86-12 F-CAN Communication With ECM/PCM (PGM-FI) Malfunction 86-13 F-CAN Communication With PCM (AT/CVT) Malfunction Is DTC 86-12 or 86-13 indicated? YES : If DTC 86-12 or 86-13 are only indicated, go to step 2. YES : If DTC 86-11 is also indicated, go to «DTC 86-11»(ref-595411-S42139491852014013100000) . NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. Open wire check (F CAN-L, F CAN-H lines): 1. Turn the ignition switch to LOCK (0). 2. Short the SCS line with the HDS. 3. Disconnect the following connectors. VSA modulator-control unit 38P connector PCM connector A (49P) 4. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) VSA modulator-control unit 38P connector: disconnected PCM connector A (49P): disconnected Test circuit F CAN-L Test point 1 VSA modulator-control unit 38P connector No. 26 (RED) Test point 2 PCM connector A (49P) No. 4 (RED) Test circuit F CAN-H Test point 1 VSA modulator-control unit 38P connector No. 38 (WHT) Test point 2 PCM connector A (49P) No. 3 (WHT) Is there continuity? YES : The F CAN-L, F CAN-H wires are OK. Go to step 3. NO : Repair an open in the wire between the PCM and the VSA modulator-control unit.
  3. PCM check (update or substitution): 1. Reconnect the following connectors. VSA modulator-control unit 38P connector PCM connector A (49P) 2. Update the PCM if it does not have the latest software See «PCM REMOVAL AND INSTALLATION»(ref-595374-S31779448642014013100000) or «PCM UPDATE»(ref-595375-S42937672232014013100000) , or substitute a known-good PCM See «PCM UPDATE»(ref-595375-S42937672232014013100000) or «PCM REMOVAL AND INSTALLATION»(ref-595374-S31779448642014013100000) . 3. Clear the DTC with the HDS. 4. Turn the ignition switch to LOCK (0). 5. Start the engine for at least 5 seconds. 6. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 86-12 F-CAN Communication With ECM/PCM (PGM-FI) Malfunction 86-13 F-CAN Communication With PCM (AT/CVT) Malfunction Is DTC 86-12 or 86-13 indicated? YES : Go to step 4. NO : If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM See «PCM REMOVAL AND INSTALLATION»(ref-595374-S31779448642014013100000) or «PCM UPDATE»(ref-595375-S42937672232014013100000) .
  4. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Start the engine for at least 5 seconds. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 86-12 or 86-13 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 58

Scheme 58: DTC 86-14: F-CAN Communication With Gauge Control Module Malfunction
Scheme 58: DTC 86-14: F-CAN Communication With Gauge Control Module Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
86-14 F-CAN Communication With Gauge Control Module Malfunction

Scheme 59

Scheme 59
Scheme 59
  1. DTC check: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Start the engine for at least 5 seconds. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 86-11 F-CAN Bus-Off Malfunction 86-14 F-CAN Communication With Gauge Control Module Malfunction Is DTC 86-14 indicated? YES : If DTC 86-14 is only indicated, go to step 2. YES : If DTC 86-11 is also indicated, go to «DTC 86-11»(ref-595411-S42139491852014013100000) . NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. Body electrical system DTC check: 1. Check for gauge control module DTCs with the HDS. DTC Description DTC Are any DTCs indicated? YES : Go to indicated DTC's troubleshooting. NO : Go to step 3.
  3. Open wire check (F CAN-L, F CAN-H lines): 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connectors. VSA modulator-control unit 38P connector Gauge control module 32P connector 3. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) VSA modulator-control unit 38P connector: disconnected Gauge control module 32P connector: disconnected Test circuit F CAN-L Test point 1 VSA modulator-control unit 38P connector No. 26 (RED) Test point 2 Gauge control module 32P connector No. 20 (RED) Test circuit F CAN-H Test point 1 VSA modulator-control unit 38P connector No. 38 (WHT) Test point 2 Gauge control module 32P connector No. 19 (WHT) Is there continuity? YES : The F CAN-L, F CAN-H wires are OK. Go to step 4. NO : Repair an open in the wire between the gauge control module and the VSA modulator-control unit.
  4. Gauge control module check (substitution): 1. Substitute a known-good gauge control module See «Rewriting the ODO Data and Transferring the Maintenance Minder™ Data to a New Gauge Control Module»(ref-595382-S29459770492014013100000) or «GAUGE CONTROL MODULE REMOVAL AND INSTALLATION»(ref-595382-S39482976312014013100000) . 2. Reconnect the following connectors. VSA modulator-control unit 38P connector Gauge control module 32P connector 3. Turn the ignition switch to ON (II). 4. Clear the DTC with the HDS. 5. Turn the ignition switch to LOCK (0). 6. Start the engine for at least 5 seconds. 7. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 86-14 F-CAN Communication With Gauge Control Module Malfunction Is DTC 86-14 indicated? YES : Go to step 5. NO : Replace the original gauge control module See «Rewriting the ODO Data and Transferring the Maintenance Minder™ Data to a New Gauge Control Module»(ref-595382-S29459770492014013100000) or «GAUGE CONTROL MODULE REMOVAL AND INSTALLATION»(ref-595382-S39482976312014013100000) .
  5. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Start the engine for at least 5 seconds. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 86-14 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 60

Scheme 60: DTC 86-19: F-CAN Communication With Steering Angle Sensor Malfunction
Scheme 60: DTC 86-19: F-CAN Communication With Steering Angle Sensor Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
86-19 F-CAN Communication With Steering Angle Sensor Malfunction

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63
  1. DTC check: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Start the engine for at least 5 seconds. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 86-11 F-CAN Bus-Off Malfunction 86-19 F-CAN Communication With Steering Angle Sensor Malfunction Is DTC 86-19 indicated? YES : If DTC 86-19 is only indicated, go to step 2. YES : If DTC 86-11 is also indicated, go to «DTC 86-11»(ref-595411-S42139491852014013100000) . NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. Open wire check (F CAN-L, F CAN-H lines): 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connectors. VSA modulator-control unit 38P connector Steering angle sensor 4P connector 3. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) VSA modulator-control unit 38P connector: disconnected Steering angle sensor 4P connector: disconnected Test circuit F CAN-L Test point 1 VSA modulator-control unit 38P connector No. 26 (RED) Test point 2 Steering angle sensor 4P connector No. 3 (RED) Test circuit F CAN-H Test point 1 VSA modulator-control unit 38P connector No. 38 (WHT) Test point 2 Steering angle sensor 4P connector No. 2 (WHT) Is there continuity? YES : The F CAN-L, F CAN-H wires are OK. Go to step 3. NO : Repair an open in the wire between the steering angle sensor and the VSA modulator-control unit.
  3. Open wire check (IG1 VSA/ABS line): 1. Turn the ignition switch to ON (II). 2. Measure the voltage between test points 1 and 2. Test condition IG ON (II) VSA modulator-control unit 38P connector: disconnected Steering angle sensor 4P connector: disconnected Test circuit IG1 VSA/ABS Test point 1 Steering angle sensor 4P connector No. 1 (GRN) Test point 2 Body ground Is there battery voltage? YES : The IG1 VSA/ABS wire is OK. Go to step 4. NO : Repair an open in the wire between the No. B24 (7.5 A) fuse in the under-dash fuse/relay box and the steering angle sensor.
  4. Open wire check (GND line): 1. Turn the ignition switch to LOCK (0). 2. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) VSA modulator-control unit 38P connector: disconnected Steering angle sensor 4P connector: disconnected Test circuit GND Test point 1 Steering angle sensor 4P connector No. 4 (BLK) Test point 2 Body ground Is there continuity? YES : The GND wire is OK. Go to step 5. NO : Repair an open in the wire between the steering angle sensor and body ground (G501).
  5. Steering angle sensor check (substitution): 1. «SUBSTITUTE A KNOWN-GOOD STEERING ANGLE SENSOR»(ref-595416-S21284073902014013100000) . 2. Reconnect the following connectors. VSA modulator-control unit 38P connector Steering angle sensor 4P connector 3. Turn the ignition switch to ON (II). 4. Clear the DTC with the HDS. 5. Turn the ignition switch to LOCK (0). 6. Start the engine for at least 5 seconds. 7. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 86-19 F-CAN Communication With Steering Angle Sensor Malfunction Is DTC 86-19 indicated? YES : Go to step 6. NO : «REPLACE THE ORIGINAL STEERING ANGLE SENSOR»(ref-595416-S21284073902014013100000) .
  6. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Start the engine for at least 5 seconds. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 86-19 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 64

Scheme 64: DTC 87-1: Wheel Speed Sensor Circuit Short to Power
Scheme 64: DTC 87-1: Wheel Speed Sensor Circuit Short to Power

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
87-1 Wheel Speed Sensor Circuit Short to Power
  1. DTC check: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 11-13 Right-Front Wheel Speed Sensor Circuit Malfunction 13-13 Left-Front Wheel Speed Sensor Circuit Malfunction 15-13 Right-Rear Wheel Speed Sensor Circuit Malfunction 17-13 Left-Rear Wheel Speed Sensor Circuit Malfunction 87-1 Wheel Speed Sensor Circuit Short to Power Is DTC 87-1 indicated? YES : If DTC 87-1 is only indicated, go to step 2. YES : If DTC 11-13, 13-13, 15-13, or 17-13 are also indicated, go to «DTC 11-13, 13-13, 15-13, or 17-13»(ref-595411-S08368036252014013100000) . NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  2. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) . 2. Turn the ignition switch to LOCK (0), then turn it to ON (II) again. 3. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 87-1 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) , «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 65

Scheme 65: DTC 88-11: Wheel Speed Sensor Noise Malfunction
Scheme 65: DTC 88-11: Wheel Speed Sensor Noise Malfunction

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM . A wheel bearing that is installed backwards can cause this DTC.

DTC DescriptionDTCFreeze Frame
88-11 Wheel Speed Sensor Noise Malfunction
  1. Tire check: 1. Turn the ignition switch to LOCK (0). 2. «CHECK ALL FOUR TIRES FOR SIZE, INFLATION, AND WEAR»(/honda/cr-v/iv-2011-2015/remont/wheel-alignment/#wheel-alignment) . Are all four tires the correct size, properly inflated, and worn evenly? YES : Go to step 2. NO : Install the correct tires, a known-good set of tires, or set the tires to the correct pressure, and retest by test-driving.
  2. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Test-drive the vehicle at 9 mph (15 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 88-11 Wheel Speed Sensor Noise Malfunction Is DTC 88-11 indicated? YES : The failure is duplicated. Go to step 3. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  3. Wheel speed sensor performance check: 1. Test-drive the vehicle at 9 mph (15 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 2. Check the parameter(s) below with the HDS. Signal Current conditions Values Unit RIGHT FRONT WHEEL SPEED LEFT FRONT WHEEL SPEED RIGHT REAR WHEEL SPEED LEFT REAR WHEEL SPEED Is any one of the four values different? YES : Go to step 4. NO : Go to step 6 .
  4. Wheel speed sensor check (substitution): 1. Turn the ignition switch to LOCK (0). 2. Substitute a known-good wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) . Appropriate Wheel Speed Sensor Right-front Left-front Right-rear Left-rear 3. Turn the ignition switch to ON (II). 4. Clear the DTC with the HDS. 5. Turn the ignition switch to LOCK (0). 6. Test-drive the vehicle at 9 mph (15 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 7. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 88-11 Wheel Speed Sensor Noise Malfunction s DTC 88-11 indicated? YES : Go to step 5. NO : Replace the original wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) .
  5. Magnetic encoder check: 1. Turn the ignition switch to LOCK (0). 2. Inspect the magnetic encoder for damage, debris, and correct installation. Front: «REMOVE THE DRIVESHAFT OUTBOARD JOINT FROM THE APPROPRIATE WHEEL HUB»(ref-595434-S13559170152014013100000) . Rear: «REMOVE THE HUB BEARING UNIT»(ref-595433-S03792719202014013100000) . Is the magnetic encoder surface OK? YES : Go to step 6. NO : Clean debris from the appropriate magnetic encoder surface on the wheel bearing or the hub bearing unit. If the DTC is still present, replace the appropriate «WHEEL BEARING»(ref-595434-S13559170152014013100000) or the «HUB BEARING UNIT»(ref-595433-S03792719202014013100000) .
  6. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle at 9 mph (15 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 88-11 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 66

Scheme 66: DTC 88-12: ABS Activation Time Too Long
Scheme 66: DTC 88-12: ABS Activation Time Too Long

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM . A wheel bearing that is installed backwards can cause this DTC.

DTC DescriptionDTCFreeze Frame
88-12 ABS Activation Time Too Long
  1. Tire check: 1. Turn the ignition switch to LOCK (0). 2. «CHECK ALL FOUR TIRES FOR SIZE, INFLATION, AND WEAR»(/honda/cr-v/iv-2011-2015/remont/wheel-alignment/#wheel-alignment) . Are all four tires the correct size, properly inflated, and worn evenly? YES : Go to step 2. NO : Install the correct tires, a known-good set of tires, or set the tires to the correct pressure, and retest by test-driving.
  2. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Test-drive the vehicle at 31 mph (50 km/h) or more for 10 seconds or more under these conditions: Accelerator pedal pressed. Brake pedal released. NOTE: Drive the vehicle on the road, not on a lift. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 88-12 ABS Activation Time Too Long Is DTC 88-12 indicated? YES : The failure is duplicated. Go to step 3. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  3. Wheel speed sensor performance check: 1. Test-drive the vehicle at 31 mph (50 km/h) or more. NOTE: Drive the vehicle on the road, not on a lift. 2. Check the parameter(s) below with the HDS. Signal Current conditions Values Unit RIGHT FRONT WHEEL SPEED LEFT FRONT WHEEL SPEED RIGHT REAR WHEEL SPEED LEFT REAR WHEEL SPEED Is any one of the four values different? YES : Go to step 4. NO : Go to step 6 .
  4. Wheel speed sensor check (substitution): 1. Turn the ignition switch to LOCK (0). 2. Substitute a known-good wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) . Appropriate Wheel Speed Sensor Right-front Left-front Right-rear Left-rear 3. Turn the ignition switch to ON (II). 4. Clear the DTC with the HDS. 5. Turn the ignition switch to LOCK (0). 6. Test-drive the vehicle at 31 mph (50 km/h) or more for 10 seconds or more under these conditions: Accelerator pedal pressed. Brake pedal released. NOTE: Drive the vehicle on the road, not on a lift. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 88-12 ABS Activation Time Too Long Is DTC 88-12 indicated? YES : Go to step 5. NO : Replace the original wheel speed sensor See «FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S04333569742014013100000) or «REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION»(ref-595378-S03989399462014013100000) .
  5. Magnetic encoder check: 1. Turn the ignition switch to LOCK (0). 2. Inspect the magnetic encoder for damage, debris, and correct installation. Front: «REMOVE THE DRIVESHAFT OUTBOARD JOINT FROM THE APPROPRIATE WHEEL HUB»(ref-595434-S13559170152014013100000) . Rear: «REMOVE THE HUB BEARING UNIT»(ref-595433-S03792719202014013100000) . Is the magnetic encoder surface OK? YES : Go to step 6. NO : Clean debris from the appropriate magnetic encoder surface on the wheel bearing or the hub bearing unit. If the DTC is still present, replace the appropriate «WHEEL BEARING»(ref-595434-S13559170152014013100000) or the «HUB BEARING UNIT»(ref-595433-S03792719202014013100000) .
  6. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) or «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle at 31 mph (50 km/h) or more for 10 seconds or more under these conditions: Accelerator pedal pressed. Brake pedal released. NOTE: Drive the vehicle on the road, not on a lift. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 88-12 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 67

Scheme 67: DTC 91-1: VSA Activation Time Too Long
Scheme 67: DTC 91-1: VSA Activation Time Too Long

Note. BEFORE YOU TROUBLESHOOT, RECORD ALL FREEZE DATA AND ANY ON-BOARD SNAPSHOT, AND REVIEW THE HOW TO TROUBLESHOOT THE VSA SYSTEM .

DTC DescriptionDTCFreeze Frame
91-1 VSA Activation Time Too Long
  1. Brake system check: 1. Turn the ignition switch to LOCK (0). 2. Check the brake system for leaks or mechanical problems. Is the brake system OK? (No brake fluid leakage, no air trapped in the brake system, no brake pads worn out.) YES : Go to step 2. NO : Repair the brake system.
  2. Problem verification: 1. Turn the ignition switch to ON (II). 2. Clear the DTC with the HDS. 3. Turn the ignition switch to LOCK (0). 4. Test-drive the vehicle in a straight line. Accelerate the vehicle up to 6 mph (10 km/h) or more, and stop, then accelerate up to 6 mph (10 km/h) or more. NOTE: Do the test-driving in a safe area. Drive the vehicle on the road, not on a lift. 5. Check for DTCs with the HDS. DTC Description DTC Freeze Frame 91-1 VSA Activation Time Too Long Is DTC 91-1 indicated? YES : The failure is duplicated. Go to step 3. NO : Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting.
  3. VSA modulator-control unit check (update): 1. Update the VSA modulator-control unit if it does not have the latest software See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . 2. Turn the ignition switch to LOCK (0). 3. Test-drive the vehicle in a straight line. Accelerate the vehicle up to 6 mph (10 km/h) or more, and stop, then accelerate up to 6 mph (10 km/h) or more. NOTE: Do the test-driving in a safe area. Drive the vehicle on the road, not on a lift. 4. Check for DTCs with the HDS. DTC Description DTC Freeze Frame Is DTC 91-1 indicated? YES : Check for loose terminals in the VSA modulator-control unit 38P connector. If the VSA modulator-control unit was updated and the symptom/indication is still present, replace the VSA modulator-control unit See «VSA SENSOR NEUTRAL POSITION MEMORIZATION»(ref-595411-S26728862432014013100000) , «VSA MODULATOR-CONTROL UNIT REMOVAL AND INSTALLATION»(ref-595411-S13354206342014013100000) or «VSA MODULATOR-CONTROL UNIT UPDATE»(ref-595411-S33795849562014013100000) . NO : Troubleshooting is complete. If any other DTCs are indicated, go to the indicated DTCs troubleshooting.

Scheme 68

Scheme 68: VSA Modulator-Control Unit Connector for Inputs and Outputs
Scheme 68: VSA Modulator-Control Unit Connector for Inputs and Outputs
Terminal numberWire colorTerminal signDescriptionSignal
1BLKGNDGround for the VSA modulator-control unitContinuity to ground
2RED+B_ABS/VSA_MTRPower source for the motor relayBattery voltage (about 12 V) at all times
3BLKGNDGround for the pump motorContinuity to ground
4WHT+B_ABS/VSA_FSRPower source for the fail-safe relayBattery voltage (about 12 V) at all times
5Not usedNot used
6Not usedNot used
7Not usedNot used
8Not usedNot used
9GRNFR_L_ABS_ SNSRDetects left-front wheel speed sensor signal
10Not usedNot used
11LT BLUK_LINECommunication with HDSPulse voltage (digital signal)
12Not usedNot used
13PNKFR_R_ABS_ SNSRDetects right-front wheel speed sensor signal
14Not usedNot used
15Not usedNot used
16Not usedNot used
17Not usedNot used
18Not usedNot used
19Not usedNot used
20Not usedNot used
21ORNFR_L_ABS_SNSR+Detects left-front wheel speed sensor signal
22PURRR_L_ABS_ SNSRDetects left-rear wheel speed sensor signal
23LT GRNRR_R_ABS_SNSR+Detects right-rear wheel speed sensor signal
24WHTFR_R_ABS_SNSR+Detects right-front wheel speed sensor signal
25Not usedNot used
26REDF_CAN-LF-CAN communication circuit
27Not usedNot used
28Not usedNot used
29Not usedNot used
30Not usedNot used
31Not usedNot used
32Not usedNot used
33GRYRR_L_ABS_SNSR+Detects left-rear wheel speed sensor signal
34Not usedNot used
35GRNRR_R_ABS_ SNSRDetects right-rear wheel speed sensor signal
36PURIG1_VSA/ABSPower source for activating the systemWith ignition switch ON (II): battery voltage (about 12 V)
37Not usedNot used
38WHTF_CAN-HF-CAN communication circuit

More articles — Vsa System DTC Testing
