Engine Block (K24Z1): Other Honda CR-V III рестайлинг

Main Bearing Selection

Crankshaft Bore Code Location

Scheme 526

Scheme 527

1. Numbers, letters, or bars have been stamped on the end of the block as a code for the size of each of the five main journal bores. Write down the crank bore codes. If you can't read the codes because of accumulated dirt and dust, do not scrub them with a wire brush or scraper. Clean them only with solvent or detergent. Main Journal Code Location
2. The main journal codes are stamped on the crankshaft in either location.
3. Use the crank bore codes and crank journal codes to select the appropriate replacement bearings from the following table.

Note. The color code is on the edge of the bearing. When using bearing halves of different colors, it does not matter which color is used in the top or bottom.

Scheme 528

Cylinder Bore Honing

Only a scored or scratched cylinder bore must be honed.

Scheme 529

1. Measure the cylinder bores (see «BLOCK AND PISTON INSPECTION»(ref-371382-S31937858892010091000000) ). If the block is to be reused, hone the cylinders, and remeasure the bores.
2. Hone the cylinder bores with honing oil and a fine (400 grit) stone in a 60 degree cross-hatch pattern (A). Use only a rigid hone with 400 grit or finer stone such as Sunnen, Ammco, or equivalent. Do not use stones that are worn or broken.
3. When honing is complete, thoroughly clean the engine block of all metal particles. Wash the cylinder bores with hot soapy water, then dry and oil them immediately to prevent rusting. Never use solvent, it will only redistribute the grit on the cylinder walls. NOTE: Never use solvent, it will only redistribute the grit on the cylinder walls.
4. If scoring or scratches are still present in the cylinder bores after honing the engine block to the service limit, rebore the engine block. Some light vertical scoring and scratching is acceptable if it is not deep enough to catch your fingernail, and does not run the full length of the bore.

Scheme 530

Scheme 531

1. Remove the piston from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-371382-S01486799712010091000000) ).
2. Apply new engine oil to the piston pin snap rings (A), and turn them in the ring grooves until the end gaps are lined up with the cutouts in the piston pin bores (B). NOTE: Take care not to damage the ring grooves.
3. Remove both snap rings. Start at the cutout in the piston pin bore. Remove the snap rings carefully so they do not go flying or get lost. Wear eye protection.
4. Heat the piston and connecting rod assembly to about 158 °F (70 °C), then remove the piston pin.

Scheme 532
