Interior Lights: Overview Honda CR-V III рестайлинг

Interior/illumination Lights 10 illustrations ~559 words

Scheme 1

Scheme 1: With moonroof

Scheme 2

Scheme 2: Without moonroof

Scheme 3

Scheme 3: Circuit Diagram

Scheme 4

Scheme 4: '07-08 and '10 models With moonroof and '09 model

Scheme 5

Scheme 5
  1. Turn the map light switch OFF.
  2. Carefully pry the lens (A) off with a small screwdriver. Front Map Light: 8 W x 2
  3. Remove the screws, then remove the map lights (B) and moonroof switch or navigation microphone (C).
  4. Disconnect the 3P connector from the map lights and the 10P *1 (12P) *2 connector from the moonroof switch or navigation microphone. *1: '07 model *2: '08-10 models
  5. Check for continuity between the terminals in each switch position according to the table.
  6. If the continuity is not as specified, check the bulb(s). If the bulb(s) are OK, replace the light assembly.
  7. Install the light in the reverse order of removal.

Scheme 6

Scheme 6: '07-08 and '10 models Without moonroof

Scheme 7

Scheme 7
  1. Turn the map light switch OFF.
  2. Carefully pry the lens (A) off with a small screwdriver. Front Map Light: 8 W x 2
  3. Remove the screws, then remove the map lights (B).
  4. Disconnect the 3P connector (C) from the map lights.
  5. Check for continuity between the terminals in each switch position according to the table.
  6. If the continuity is not as specified, check the bulb(s). If the bulb(s) are OK, replace the light assembly.
  7. Install the light in the reverse order of removal.

Scheme 8

Scheme 8: Ceiling Light Test/Replacement
  1. Turn the ceiling light switch OFF.
  2. Carefully pry the lens (A) off with a small screwdriver. Ceiling Light: 8 W
  3. Remove the screws, then remove the ceiling light (B).
  4. Disconnect the 3P connector (C) from the ceiling light.
  5. Check for continuity between the terminals. There should be continuity between terminals No. 1 and No. 2 with the switch in the MIDDLE position. There should be continuity between terminals No. 2 and No. 3 (Body ground) with the switch in the ON position. There should be no continuity between terminals No. 1 and No. 2, and between terminal No. 2 and body ground with the switch in the OFF position.
  6. If the continuity is not as specified, check the bulb. If the bulb is OK, replace the light.
  7. Install the light in the reverse order of removal.

Scheme 9

Scheme 9: Cargo Area Light Test/Replacement
  1. Open the tailgate, and turn the cargo area light switch OFF.
  2. Carefully pry the lens (A) off with a small screwdriver. Cargo Area Light: 8 W
  3. Remove the screws, then remove the cargo area light (B).
  4. Disconnect the 3P connector (C) from the cargo area light.
  5. Check for continuity between the terminals. There should be continuity between terminals No. 1 and No. 2 with the switch in the MIDDLE position. There should be continuity between terminals No. 2 and No. 3 (Body ground) with the switch in the ON position. There should be no continuity between terminals No. 1 and No. 2, and between terminal No. 2 and body ground with the switch in the OFF position.
  6. If the continuity is not as specified, check the bulb. If the bulb is OK, replace the light.
  7. Install the light in the reverse order of removal.

Scheme 10

Scheme 10: Tailgate Latch Switch Test
  1. Open the tailgate.
  2. Remove the tailgate lower trim (see «TAILGATE LOWER TRIM REPLACEMENT»(ref-371384-S38515279552010091000000) ).
  3. Disconnect the 2P connector (A) from the tailgate latch switch (B).
  4. Check for continuity between terminals No. 1 and No. 2. There should be continuity with the tailgate open. There should be no continuity with the tailgate closed.
  5. If the continuity is not as specified, replace the tailgate latch assembly.
