SEAT BELT REMINDER
With the ignition switch in "on" (II) or "start" (III), battery voltage is applied to the seat belt reminder light. When the seat belt is not buckled, the seat belt reminder/key-on beeper circuit in the integrated control unit senses ground through the closed seat belt switch. The seat belt reminder light comes on and stays on, and the beeper beeps for 6 seconds. The reminder light and beeper will stop when the seat belt is buckled or the timer circuit deactivates them.
IGNITION KEY REMINDER
Battery voltage is supplied at all times to the seat belt reminder/key-on beeper circuit in the integrated control unit. When you turn on the ignition key switch the integrated control unit senses ground. If you open the drivers door, the door switch closes, causing the beeper to sound until the door is closed.
Park/Off
When you turn the wiper switch "off" the integrated control unit (park input) grounds the wiper motor through the BLU/WHT wire. The cam switch on the motor signals the integrated control unit that the wipers are in the park position, the control unit then removes ground from the motor, and the wipers stop in the park position.
Intermittent
When you move the front wiper/washer switch to INT, battery voltage is applied through the YEL/BLU wire to the integrated control unit (intermittent wiper on input). The integrated control unit (intermittent/park wiper control) grounds the low speed windings of the wiper motor, and the wipers make a single sweep every few seconds. When the wipers return to the park position, the park switch applies battery voltage through the BLU/WHT wire to the integrated control unit (park input), and the wipers stop in the park position.
Washer
When you pull the wiper switch toward you to turn on the washer switch, battery voltage is applied to the washer motor. The motor pumps fluid onto the windshield until you release the lever, the integrated control unit (windshield washer on input) senses power at the WHT/BLK wire terminal and runs the wipers whenever the washer motor runs.
All Systems
For connector terminal identification see scheme 7or see scheme 8. For input test (Scheme 13)or (Scheme 14).
Scheme 13
Scheme 14
Intermittent Wiper System
For connector terminal identification see scheme 7or see scheme 8. For input test (Scheme 15)or (Scheme 16).
Scheme 15
Scheme 16
Key-In/Seat Belt Reminder, Lights-On Reminder System
For connector terminal identification see scheme 7or see scheme 8. For input test (Scheme 17)or (Scheme 18).
Scheme 17
Scheme 18
Bulb Check System (Brake System Light)
For connector terminal identification see scheme 7or see scheme 8. For input test (Scheme 19)or (Scheme 20).
Scheme 19
Scheme 20
Rear Window Intermittent Wiper System (1998-01)
For connector terminal identification see scheme 8 For input test (Scheme 21)
Scheme 21
Ignition Key Light Timer System (1998-01)
For connector terminal identification see scheme 8 For input test (Scheme 22)
