STARTER SPECIFICATIONS
| Application | Specification |
|---|---|
| Brush Length (Minimum) | .43" (11.0 mm) |
| Brush Spring Tension | 3.1-4.0 (1.4-1.8) |
| Commutator Diameter (Minimum) | 1.08" (27.5 mm) |
| Commutator Mica Depth (Minimum) | .006" (.15 mm) |
| Commutator Runout (Maximum) | .002" (.05 mm) |
STARTER SPECIFICATIONS (MITSUBA)
| Application | Specification |
|---|---|
| Brush Length (Minimum) | .35" (9.0 mm) |
| Commutator Diameter (Minimum) | 1.06" (27.0 mm) |
| Commutator Mica Depth (Minimum) | .008" (.20 mm) |
| Commutator Runout (Maximum) | .002" (.05 mm) |
STARTER SPECIFICATIONS (NIPPONDENSO)
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Starter Mounting Bolts | 33 (45) |
TORQUE SPECIFICATIONS
