Honda Civic VIII (2005-2009) Ground distribution circuit, hybrid

ABS MODULATOR CONTROL UNIT BATTERY BCM MODULE BLK WIRE BRAIDED WIRE BRAKE POWER UNIT BRN WIRE CKP SENSOR CMP SENSOR DATA LINK CONNECTOR DC-DC CONVERTER EGR VALVE/ EGR VALVE POSITION SENSOR ENGINE EPS CONTROL UNIT EPS TORQUE SENSOR FRONT IGNITION COIL 1 FRONT IGNITION COIL 2 FRONT IGNITION COIL 3 FRONT IGNITION COIL 4 IMA SYSTEM SHIELD IMMOBILIZER KEYLESS CONTROL UNIT IPU MODULE FAN A/C COMPRESSOR DRIVER KNOCK SENSOR SHIELD MCM PCM REAR IGNITION COIL 1 REAR IGNITION COIL 2 REAR IGNITION COIL 3 ROCKER ARM OIL CONTROL SOLENOID 1 REAR IGNITION COIL 4 ROCKER ARM OIL CONTROL SOLENOID 2 ROCKER ARM OIL PRESSURE SWITCH SECONDARY SERVO UNIT SHIELD TRANSMISSION TRANSMISSION RANGE SWITCH UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) YEL WIRE

A/C CONDENSER FAN MOTOR AUXILIARY ELECTRIC WATER PUMP BLK WIRE BLK/WHT WIRE BLOWER MOTOR RELAY BLOWER POWER TRANSISTOR BRAKE FLUID LEVEL SWITCH BRN WIRE CANADA CONSOLE ACCESSORY POWER SOCKET RELAY GAUGE CONTROL MODULE (TACH) DASH LIGHTS BRIGHTNESS CONTROLLER DATA LINK CONNECTOR DRIVER'S DOOR LOCK ACTUATOR/KNOB SWITCH ELD UNIT FAN CONTROL RELAY FRONT ACCESSORY POWER SOCKET FRONT ACCESSORY POWER SOCKET RELAY LEFT FRONT SIDE MARKER/ PARKING/TURN SIGNAL LIGHT LEFT HEADLIGHT LEFT POWER MIRROR LOW BEAM HIGH BEAM MES CONNECTOR MICU P-GND POWER MIRROR SWITCH POWER WINDOW MASTER SWITCH PPL RIGHT FRONT SIDE MARKER/ PARKING/TURN SIGNAL LIGHT RIGHT HEADLIGHT RIGHT POWER MIRROR SECURITY HOOD SWITCH SRS UNIT WINDSHIELD WASHER MOTOR WINDSHIELD WIPER MOTOR

A/T GEAR POSITION INDICATOR PANEL LIGHT/PARK-PIN SWITCH BLK WIRE CABLE REEL CANADA CLIMATE CONTROL UNIT CONSOLE ACCESSORY POWER SOCKET DRIVER'S SEAT BELT BUCKLE SWITCH FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 2 OF 3) FRONT PASSENGER'S DOOR LOCK ACTUATOR/KNOB SWITCH FRONT PASSENGER'S POWER WINDOW SWITCH FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH FUEL TANK UNIT GAUGE CONTROL MODULE (SPEEDO) GAUGE CONTROL MODULE (TACH) GRY WIRE HIGH MOUNT BRAKE LIGHT TRUNK LATCH SWITCH IGNITION KEY SWITCH LEFT BACK-UP LIGHT LEFT BRAKE LIGHT/ TAILLIGHT LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH LEFT REAR SIDE MARKER LIGHT LEFT LICENSE PLATE LIGHT LEFT REAR TURN SIGNAL LIGHT LT GRN WIRE MICU MICU SERVICE CHECK CONNECTOR NOISE REDUCTION CONDENSER ODS UNIT PARK PIN SWITCH REAR WINDOW DEFOGGER RIGHT BACK-UP LIGHT RIGHT BRAKE LIGHT/ TAILLIGHT RIGHT INNER TAILLIGHT LEFT INNER TAILLIGHT RIGHT LICENSE PLATE LIGHT RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH RIGHT REAR SIDE MARKER LIGHT S GND STEERING WHEEL CRUISE CONTROL COMBINATION SWITCH TRUNK KEY CYLINDER SWITCH RIGHT REAR TURN SIGNAL LIGHT TRUNK LID OPENER SOLENOID/ LATCH SWITCH USA WHT/BLK WIRE YEL WIRE
